Kenmore Elite 79572059112 refrigerator Parts

Common problems on the Kenmore Elite 79572059112 bottom-mount refrigerator include warm temperatures from restricted airflow (dirty condenser area, frost on the evaporator), ice maker or dispenser issues (no ice, slow water, leaks), unusual noises from fans, and water puddles from a clogged defrost drain. Use the 79572059112 owner's manual troubleshooting section to match symptoms to the right checks.

Most common symptoms and what they usually point to

• Not cooling or weak cooling: dirty condenser area, failed compressor, or frost-packed evaporator
• Frost buildup on the back wall or freezer: defrost system problem (sensor, heater circuit, control)
• Loud buzzing, rattling, or clicking: condenser fan or evaporator fan noise, or compressor/start components
• Water leaking or puddles: clogged/iced defrost drain, loose water line, or inlet valve seepage
• No ice or no water from dispenser: clogged filter, frozen water line, or a failing inlet valve

Quick checks we recommend before replacing parts

1. Confirm settings: refrigerator about 37°F and freezer about 0°F.
2. Make sure doors seal and close fully; overloaded bins can hold doors open.
3. Clean dust from the condenser area (unplug first); airflow problems are a top cause of warm temps.
4. If you see heavy frost on the evaporator cover, plan on defrost-system troubleshooting.
5. For dispenser issues, replace the water filter first and purge air from the line.

Parts that commonly solve these problems (when diagnosis confirms)

Symptom	Commonly involved part	Example part for this model
Slow water, bad taste, low flow	Water filter	Genuine Kenmore refrigerator water filter 9690 AGF80300801
No water to ice maker/dispenser	Water inlet valve	Refrigerator water inlet valve AJU74532703
Warm temps, poor heat removal	Condenser coil	Refrigerator condenser coil ACG73645004
Frost-related cooling loss	Defrost sensor	Refrigerator defrost sensor assembly 6615JB2005R
Door not registering closed	Door switch	Refrigerator door switch 6600JB1010A

Why it matters

Most “not cooling” complaints are really airflow problems: if the condenser cannot shed heat or the evaporator is blocked by frost, the refrigerator section warms up even though the unit still runs. Catching that early helps prevent food spoilage and reduces compressor run time.

For model-specific troubleshooting steps and error indications, we also use the Kenmore 795 model bottom freezer refrigerator error codes guide.

You can order replacement parts for your Kenmore Elite 79572059112 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

To raise a Kenmore Elite refrigerator model 79572059112 off the floor, we adjust the two front leveling legs. Turn a leveling leg left to raise that side and right to lower it; raising the front slightly also helps the doors close properly. See the owner's manual for the exact leveling and door-alignment procedure.

Quick steps (leveling legs)

• Unload heavy items from the doors to reduce weight.
• Have someone push back gently on the top of the refrigerator to take pressure off the legs.
• Use an 11/16-inch wrench or a flat-blade screwdriver (as specified for this model).
• Turn both front leveling legs the same amount to keep the cabinet square.
• Recheck door closing; a slight rearward tilt often improves self-closing.
• Confirm the refrigerator feels stable and does not rock.

How much height can we get?

Leveling legs are designed for minor height and tilt adjustments, not for lifting the refrigerator several inches.

Goal	Best method	Notes
Stop rocking, improve door closing	Adjust leveling legs	Most common fix after installation or moving
Raise front slightly for easier rolling	Retract legs a bit, then roll carefully	Use caution to avoid floor damage
Add significant height	Use a properly rated platform (if needed)	Keep airflow clear and the unit stable

Door alignment tip (often needed after raising)

If the gap between the two fresh food doors becomes uneven after you raise the cabinet, this model uses an adjustable nut at the bottom hinge to raise or lower each door for alignment. The manual describes which direction to turn the nut.

Why it matters

Correct leveling helps the doors seal, prevents warm air leaks, reduces frost and moisture issues, and keeps the compressor from running longer than necessary.

If you need replacement parts while you are working on leveling or door closing, you can order model 79572059112 parts from the list for this model or search by model number on Sears PartsDirect.

Last updated: February 2026

A bottom-mount refrigerator (also called a bottom freezer refrigerator) keeps the fresh-food section on top at eye level and puts the freezer compartment in a pullout drawer at the bottom. Your Kenmore Elite 79572059112 is a bottom freezer style, as shown in the owner's manual.

How a bottom-mount design is laid out

Most bottom-mount units, including the Kenmore Elite 79572059112, are organized like this:

• Upper compartment: refrigerator section for everyday items
• Lower compartment: freezer section with one or more pullout drawers
• Common features: door bins, shelves, crispers, and an ice compartment (model dependent)
• Often included: water filter and water dispenser components (if equipped)

Bottom mount vs. top freezer: quick comparison

Feature	Bottom mount (bottom freezer)	Top freezer
Fresh food access	Easier (at eye level)	Requires bending more often
Freezer access	Requires bending	Easier (at chest level)
Freezer storage	Pullout drawers, wide bins	Shelves, smaller door bins
Best for	People who use fresh food most	People who use freezer most

Why it matters for daily use and maintenance

The layout affects how you load food, how cold air circulates, and what you service most often. For example, bottom-mount models commonly use a pullout freezer drawer system and may use a replaceable water filter for the dispenser.

Helpful tips for owners of model 79572059112

• Keep frequently used refrigerated items on the middle shelves to reduce door-open time.
• Avoid blocking air vents with high-moisture foods; it can contribute to freezing in the refrigerator section.
• If your unit has a water dispenser, replace the filter on schedule; the genuine Kenmore refrigerator water filter 9690 AGF80300801 is a common maintenance item for this model.
• If doors do not close easily, follow the leveling and door alignment steps in the manual.

You can order replacement parts for your Kenmore Elite 79572059112 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

On a Kenmore Elite bottom-mount refrigerator like model 79572059112, the model number is printed on the appliance ID label inside the fresh food section or freezer area. We most often see it on an inside wall, along a door frame, behind the crisper drawers, or near the lower kickplate area; confirm the exact location in the owner's manual.

Common places to check

Look for a paper or metal tag that lists the model number and usually the serial number.

• Inside the refrigerator compartment on a side wall (near the crisper area)
• On the inside door frame (open the door and check the vertical frame)
• Behind or just above the lower crisper drawers (remove drawers to see the back wall)
• Inside the freezer compartment on a side wall or near the drawer opening
• Near the front bottom area by the kickplate (you may need a flashlight)

Quick tips to find it faster

• Use a flashlight and check flat surfaces first; labels are often low and easy to miss
• Wipe condensation or dust off the label so the numbers are readable
• Write the model number exactly as shown; for this series you may also see a color suffix (for example, 795.7205* in the guide)

Why it matters

We use the exact model number to match the right Kenmore parts and diagrams for your refrigerator. That helps avoid ordering the wrong item, especially for model-specific components like the genuine Kenmore refrigerator water filter 9690 AGF80300801.

What you can do once you have the model number

Task	What to do	Example for this model
Look up parts	Use the model number to match diagrams and part listings	79572059112
Check maintenance steps	Follow the Use and Care instructions	Filter changes, cleaning
Confirm compatibility	Match part ID and description before ordering	AGF80300801

If you are ordering parts, start with the parts list for model 79572059112, or search by model on Sears PartsDirect.

Last updated: February 2026

Ice building up on the freezer floor is almost always caused by a clogged or frozen defrost drain; during defrost, water can’t flow to the drain pan so it refreezes at the bottom. On Kenmore Elite model 79572059112, clearing the drain and correcting door-seal or airflow issues stops the repeat icing (see the 79572059112 owner's manual).

What to check first (fast, high-success steps)

• Unplug the refrigerator before working around fans, heaters, or wiring.
• Remove the freezer drawer/bins so you can see the ice sheet and the rear floor area.
• Melt the ice with a hair dryer on low or by placing towels and letting it thaw.
• Flush the drain with hot water; a common mix is 1 teaspoon baking soda in 2 cups hot water to help break up slime.
• Confirm the doors close tightly; frequent openings and warm, humid air increase frost and ice buildup.

Why the drain clogs on bottom-mount freezers

When the defrost system runs, meltwater is supposed to travel through a drain hole and tube to an external drain pan. If the drain is restricted, water backs up and freezes into a slab on the freezer floor.

Common causes

Cause	What you’ll notice	What fixes it
Drain hole iced over	Ice sheet returns in days	Thaw and flush drain thoroughly
Food debris or sludge in drain	Slow draining, musty odor	Hot-water flush; repeat until clear
Door not sealing or left ajar	Frost on packages, condensation	Clean/inspect gasket; improve closing
Heavy door openings	More frost and ice	Reduce open time; organize freezer

Parts that can be involved (when symptoms point there)

If the drain keeps freezing because the unit is over-frosting, a failed defrost sensor can contribute. For this model, a common related part is the refrigerator defrost sensor assembly 6615JB2005R.

Why it matters

A blocked drain can lead to recurring ice sheets, poor airflow, warmer freezer temperatures, and water leaks when the ice melts. Fixing the drain early protects food quality and helps the refrigerator run efficiently.

Last updated: February 2026
