Kenmore refrigerator water filters

Kenmore refrigerator water filters are certified by the NSF to remove chlorine taste and odor (NSF standard 42). Many Kenmore water filters also can remove lead and cysts (NSF standard 53), and some have passed additional NSF certification tests and are certified to remove volatile organic compounds, pharmaceuticals and some pesticides (NSF standard 401). Learn more about NSF certification here.

To ensure your water filter can trap all the impurities and contaminants it’s been proven to remove, replace your refrigerator water filter every 6 months. We can send you your Kenmore water filter replacement automatically, so you don’t have to remember to reorder.

Not sure which is the right filter for your refrigerator? Use our Refrigerator Water Filter Finder for help. For video on how to install your water filter, check out our What type of water filter is in your Kenmore refrigerator? article.


Water filter bypass plugs

Some Kenmore refrigerators use bypass plugs to prevent water leaks when the filter is removed.

Here are common Kenmore water filter bypass plugs.

Sears PartsDirect sells every type of Kenmore refrigerator water filter

Filter 9130

Filter 9130 fits Kenmore and Kenmore Elite 111-series French door refrigerators. Kenmore and Kenmore Elite refrigerators with model numbers that start will 111 have their water filter located in the top right corner of the refrigerator section.

To replace the filter:

  1. Pull the filter cover toward you and down.
  2. Twist the existing filter counterclockwise ½ turn and pull it out.
  3. Insert the new water filter and rotate it ½ turn clockwise to lock it in place.
  4. Close the filter cover.
  5. Dispense 1 gallon of water through the dispenser to purge air from the water filter and dispenser line.

Filter 9130 replaces these Kenmore water filters:

  • 60199-0006802-00
  • 60199-0006803-00
  • 46-1173152-3

Filter 9690

Filter 9690 fits select Kenmore and Kenmore Elite 795-series French door refrigerators and is compatible with LG filter LT700P® that fits select LG French door refrigerators.

Kenmore water filter 9690 replaces the following filters:

To replace filter 9690, open the water filter cover then pull the filter down until it stops. Pull the filter out and replace it with the new one. Lift the filter up and close the water filter cover. Run 2 gallons of water through the water dispenser to purge air and residue.

Filter 9083

Filter 9083 fits select Kenmore and Kenmore Elite 106-series side-by-side refrigerators. This filter fits in the bottom grill of the refrigerator below the freezer door. Push the ejection button to release and remove the filter. Transfer the decorative cap from the old filter to the new one. Push the new filter into the housing until it clicks. Sears PartsDirect has replacement decorative caps for the 9083 filter. The black cap is part WP2260518B and the white cap is part WP2260518W.

Kenmore filter 9083 replaces these previous and current filter versions:

  • 9020
  • 9020B
  • 9030
  • 9030B
  • EDR3RXD1
  • 9920
  • 9953
  • 4396710
  • 4396711
  • 4396841
  • 4396842
  • 8212650
  • 4396710B
  • 4396841B
  • W10121145
  • W10121146
  • W10754687
  • W10776411
