LG LMXS30776S/02 refrigerator Parts

The LG LMXS30776S refrigerator has a total capacity of 29.7 cubic feet. For model-specific features and compartment details (including the CustomChill drawer and Door-in-Door storage), we recommend checking the LMXS30776S owner’s manual.

What that capacity means for everyday use

A 29.7 cu. ft. French door, bottom-mount refrigerator like the LG LMXS30776S is designed for high-volume storage and flexible organization across the fresh food section, freezer drawer, and specialty zones.

• More room for wide platters and party trays on adjustable shelves
• Better separation of fresh vs. frozen foods with a bottom freezer layout
• Flexible temperature storage using the CustomChill drawer
• Convenient access to frequently used items with Door-in-Door storage

Helpful specs to pair with capacity (from the manual)

The manual lists the overall exterior dimensions, which can matter as much as capacity when you are planning a kitchen fit.

Spec	Value
Total capacity	29.7 cu. ft.
Width	35 3/4 in.
Depth	38 1/8 in.
Height	70 1/4 in.

Why it matters

Capacity helps you compare refrigerators quickly, but usable space depends on shelf layout, bins, and specialty compartments. Using the manual’s storage and setup guidance can help you get the most out of the LMXS30776S without blocking air vents or overpacking.

Last updated: January 2026

On the LG LMXS30776S bottom-mount refrigerator, the most common “problem” customers report is uneven cooling: the fresh food section gets too warm while the freezer stays very cold. This is usually caused by restricted airflow, a fan issue, or a temperature-sensing/control problem; not a single universal defect.

Most common symptoms we see

• Refrigerator section warms up but freezer still freezes
• Temperature swings after heavy door openings or a full load of food
• Frost buildup that blocks vents and reduces airflow
• Loud or changing fan noise
• Ice maker or dispenser performance changes when temperatures drift

Quick checks you can do first (no tools)

Use these steps to narrow down the cause before replacing parts:

• Make sure air vents inside the refrigerator are not blocked by food containers
• Confirm doors close fully and gaskets seal all the way around
• Set temperatures back to normal targets (avoid extreme settings for long periods)
• Clean dust from the condenser area so heat can dissipate properly
• If the unit was just installed or moved, allow 24 hours to stabilize

For model-specific operating details (controls, filter indicators, ice maker notes), use the LMXS30776S owner’s manual.

Parts that commonly relate to uneven cooling

If basic checks do not help, these components are often involved on this model family:

What’s happening	Likely area to inspect	Example compatible part for this model
Fridge warm, freezer OK	Air movement in freezer or air ducting	Refrigerator evaporator fan motor EAU61524007
Temps drift or are inaccurate	Temperature sensing	Refrigerator temperature sensor 6500JB2002E
Poor heat removal, long run times	Condenser airflow	Refrigerator condenser fan motor assembly EAU62025701

Why it matters

When the refrigerator section runs warm, food safety and freshness are affected first. Catching airflow restrictions early can prevent longer run times, heavier frost buildup, and extra strain on the cooling system.

Last updated: January 2026

For the LG LMXS30776S refrigerator, the exact warranty coverage depends on the warranty statement that applies to your unit (it can vary by version, region, and purchase date). The model-specific place to verify coverage periods and exclusions is the Warranty section of the LMXS30776S owner’s manual.

What we can confirm for this model

The LMXS30776S documentation includes a dedicated Warranty section, but warranty terms are not a single universal number we can apply to every LMXS30776S without referencing your unit’s warranty statement.

Use the warranty section to confirm:

• Coverage length for the full refrigerator (parts and labor)
• Whether any components have extended coverage (for example, compressor or sealed system)
• What is excluded (filters, cosmetic items, installation issues, misuse)
• Proof-of-purchase requirements and start-date rules
• How warranty service is obtained (authorized service requirements)

Where to look in the manual

In the LMXS30776S owner’s manual, go to the Warranty pages near the end of the document.

What you need	Where it’s listed	Why it matters
Coverage periods	Warranty section	Confirms parts vs. labor timeframes
Exclusions	Warranty section	Prevents surprise out-of-pocket costs
Service instructions	Warranty section	Helps you follow the correct process

If you are asking because of a compressor issue

Warranty coverage and parts replacement are separate decisions. If you’re diagnosing a cooling problem and need the compatible compressor for this model, we list refrigerator compressor TCA38091801.

Quick checks before assuming a warranty compressor failure

• Verify the refrigerator is cooling and not in a display or demo mode
• Make sure condenser airflow is clear and the unit has proper clearance
• Confirm doors seal and close properly
• Check for error codes on the display
• Listen for the condenser fan and compressor operation

Why it matters

Warranty terms determine whether you should schedule authorized service first or proceed with DIY diagnosis and parts replacement. Confirming the exact coverage for your LMXS30776S helps avoid paying for repairs that may be covered.

Last updated: January 2026
