On the Kenmore gas dryer model 11071402311, a blown thermal fuse commonly shows up as a dryer that will not start or runs but won’t heat. The sure way to confirm is a continuity test with a multimeter after disconnecting power.

Quick symptoms to look for

• Dryer won’t start even though the door is closed and a cycle is selected
• Motor hums briefly, then stops (some failures present this way)
• Drum tumbles but there’s no heat (gas burner never lights)
• Cycle ends with clothes still damp and cool
• You recently had poor airflow (clogged lint screen or crushed vent)

How we test the thermal fuse (safe, reliable method)

1. Unplug the dryer (or switch off the breaker). The installation instructions stress using a properly grounded outlet and avoiding extension cords. See the 11071402311 installation guide.
2. Access the fuse (location varies by design; it’s often on the blower housing or exhaust duct).
3. Pull the wires off the fuse terminals.
4. Set a multimeter to continuity or lowest ohms.
5. Touch probes to the fuse terminals.

Interpreting the meter

Meter result	What it means	What to do next
Beep or near 0 ohms	Fuse is good	Keep troubleshooting heat or start circuit
No beep or OL/infinite	Fuse is blown	Replace the fuse and fix the airflow problem

Why the fuse blew (and what to correct)

A thermal fuse opens when the dryer overheats, and overheating is usually caused by restricted airflow.

• Clean the lint screen and lint chute
• Inspect venting for kinks, crushing, or long runs
• Clear lint buildup at the blower housing
• Confirm the outside vent hood opens freely
• After reassembly, run a timed heat cycle and check for strong exhaust airflow

Related heat checks for a gas dryer

If the fuse tests good but you still have no heat, confirm the gas shutoff valve is open and follow the heat-check steps in the 11071402311 installation guide. For burner ignition problems, the dryer valve coil kit 279834 is a common repair item on many Kenmore gas dryers.

Why it matters

A blown thermal fuse is a safety cutoff; replacing it without correcting vent restriction often leads to repeat failures, longer dry times, and overheating.

Last updated: February 2026

To reset your Kenmore gas dryer model 11071402311, we recommend a simple hard reset: unplug the dryer (or switch off the breaker) for 1 minute, then restore power and try a timed dry cycle. This clears many control glitches and helps you re-check basic start conditions.

Quick reset steps (safe and effective)

• Turn the dryer OFF.
• Unplug the power cord (or turn the circuit breaker OFF).
• Wait 60 seconds.
• Restore power.
• Close the door firmly and press Start.
• If the dryer still will not start, follow the start-check items in the 11071402311 installation guide.

If it still will not start after resetting

The installation checklist for this model points to a few basics that stop the dryer from running even when the control is fine.

• Confirm the dryer is plugged into a grounded 3-prong outlet.
• Check the house fuse/circuit breaker.
• Make sure the dryer door is closed.
• Try a full heat cycle (not Air/Fluff) to confirm operation.
• If the motor hums but the drum will not turn, inspect the belt and idler.

Common parts involved (when symptoms match)

Symptom	What it often points to	Example part for this model
Motor runs, drum does not tumble	Broken/slipping belt	Belt 341241
Squealing, thumping, poor tumbling	Worn idler/rollers (mechanical drag)	Dryer idler pulley WP691366
Clicks but no ignition/heat (gas model)	Weak gas valve coils	Dryer valve coil kit 279834

Why it matters

A reset fixes temporary electronic lockups, but it will not bypass a safety condition. On gas dryers, no-start and no-heat problems are often caused by power supply, door switch issues, airflow restrictions, or ignition and gas valve components.

Last updated: February 2026

For the Kenmore gas dryer model 11071402311, you typically do not replace a “heating element” like you would on an electric dryer. Heating is produced by the gas burner system, so costs usually fall into $25 to $310 for common heat-related parts, plus labor if you hire service.

Typical cost ranges for “no heat” repairs on this model

Parts pricing varies by what failed. Here are common heat-related parts available for this Kenmore model:

What’s replaced	What it does	Typical part cost range
Gas valve coils	Opens the gas valve during heating	$25 to $40
Igniter	Lights the burner	$25 to $60
Radiant sensor	Confirms flame/heat at the burner	$20 to $50
Gas valve or burner assembly	Controls gas flow and burner operation	$250 to $310

Model-matched examples from our parts list include the dryer valve coil kit 279834, igniter 279311, and dryer radiant sensor WP338906.

What we check first (before buying parts)

We follow the same basic heat check used during setup and troubleshooting:

• Run the dryer for 5 minutes, then open the door and feel for heat
• Confirm the gas shutoff valve is open
• Make sure the door fully closes
• Verify power is correct and the breaker is not tripped
• If the shutoff valve is open and there’s still no heat, we move to burner-system diagnosis

For the exact steps and safety requirements, use the 11071402311 installation guide.

Labor cost expectations

If you hire a technician, total repair cost commonly lands in the $150 to $400 range depending on diagnosis time and which component is replaced (simple coil/igniter swap vs. gas valve or burner assembly).

Why it matters

Gas dryers like the Kenmore 11071402311 heat differently than electric models. Pricing a “heating element” replacement can send you toward the wrong part; focusing on the ignition and gas valve system gets you to the correct fix faster.

Last updated: February 2026

For the Kenmore gas dryer model 11071402311, the dryer uses a standard 120-volt (often called 110/120V), 60 Hz grounded outlet on a dedicated 15- or 20-amp circuit. The gas line supplies heat; the electricity runs the motor, controls, and igniter. See the installation guide for the exact electrical requirements.

What to expect for power and hookups

• Gas dryer (this model): 120V, grounded 3-prong outlet; dedicated 15 or 20 amp circuit recommended
• Electric dryer: typically 240V (often called 220/240V) on a dedicated 30 amp circuit
• Do not use an extension cord or adapter with a dryer outlet
• Keep the outlet within about 2 ft of either side of the dryer when using a power cord
• Gas dryers also require a properly installed gas shutoff valve and approved gas supply connection

Quick comparison

Dryer type	Outlet voltage	Typical circuit	What provides heat
Gas dryer (Kenmore 11071402311)	120V	15 or 20 amp	Natural gas or LP (converted by a qualified technician)
Electric dryer	240V	30 amp	Electric heating element

Why it matters

Using the correct voltage and a dedicated circuit helps prevent nuisance breaker trips, poor performance, and unsafe wiring. On a gas dryer, the 120V supply is still critical because the igniter, gas valve coils, and motor all depend on it.

If you are unsure what you have in the laundry room

1. Check the receptacle type: a standard 3-prong household outlet indicates 120V.
2. Confirm the dryer type on the rating plate in the door area (gas vs. electric).
3. If the outlet does not match the dryer plug, have a qualified electrician install the correct outlet.

Last updated: February 2026

The Kenmore gas dryer model 11071402311 is approximately 27 inches wide, 27 3/4 inches deep, and 43 3/8 inches tall. For installation planning, we also account for required vent clearance behind the dryer; see the 11071402311 installation guide.

Dimensions and space you should plan for

These are the cabinet dimensions shown for this model:

Measurement	Approx. size
Width	27 in.
Depth	27 3/4 in.
Height	43 3/8 in.

Most installations also need at least 5 1/2 inches of clearance behind the dryer to accommodate the exhaust vent and elbow.

Quick measuring checklist (before you buy a pedestal, pan, or stack area)

• Measure the width of the opening at the front and back.
• Measure depth from the back wall to the front edge of the space (include baseboards).
• Confirm height clearance to shelves, cabinets, or a door frame.
• Plan for door swing so the dryer door can open fully.
• Leave room for the gas line connection and shutoff valve access.
• Include space for the exhaust duct path (straighter is better for airflow).

Why it matters

Correct sizing prevents crushed venting, kinked gas lines, and poor airflow. Good airflow helps drying performance and helps protect key components like the operating thermostat and high-limit thermostat from overheating.

Related installation notes we follow for this model

Item	What to plan for
Circuit (gas dryer)	Separate 15 or 20 amp circuit
Cold conditions	Do not operate below 45°F
Venting	Avoid long runs and excessive elbows

Last updated: February 2026

If your dryer’s model number is 11071402311, you have a Kenmore gas dryer. The fastest way to confirm the exact type is to match the full model number on the rating plate (usually in the door opening) to the model number used for parts and manuals.

How to identify your Kenmore dryer type (in minutes)

• Open the dryer door and look in the door opening for the model/serial rating plate.
• Confirm the model number matches 11071402311 exactly.
• Check the rating plate for gas type information (Natural gas or LP conversion info is typically listed).
• If your home uses LP (propane), do not convert the dryer yourself; follow the guidance in the installation guide.
• Use the model number to choose correct replacement parts like a belt, thermostat, or igniter.

What the “110” model prefix means

Many Kenmore dryers that start with 110 are built on a Whirlpool-manufactured platform. That matters because it helps you narrow down compatible parts and common repair procedures for this style of Kenmore gas dryer.

Quick reference: what to look for on the rating plate

What you see	What it tells you	Why it matters
Model number: 11071402311	Exact dryer identity	Ensures correct parts and diagrams
Gas information (Natural gas / LP notes)	Fuel type setup	Prevents ignition and heating issues
Electrical requirements (15 or 20 amp circuit typical for gas dryers)	Power needs	Helps avoid nuisance trips and no-start symptoms

Why it matters

Using the exact model number (not just “Kenmore gas dryer”) prevents wrong-part returns and speeds up troubleshooting. For example, common wear items on this model family include the belt 341241 and gas ignition components.

Last updated: February 2026

On Kenmore gas dryer model 11071402311, the model and serial information (used to identify the correct replacement parts) is typically on a rating label around the door opening, most often on the door frame. Use that label info when ordering parts.

What to look for on the label

Use the rating label to capture the exact identifiers before you search for parts or diagrams.

• Model number (example: 11071402311)
• Serial number (helps confirm production series)
• Type (gas dryer) and electrical details
• Sometimes a manufacturing code or additional ID line

For the exact label location and how it’s referenced for service, check the 11071402311 installation guide.

Common label locations on Kenmore dryers

Most Kenmore dryers place the rating label in one of these spots:

• Door opening on the cabinet front (door frame area)
• Inside the door opening on the front panel edge
• On the rear panel (less common)
• Inside the cabinet (usually only visible after disassembly)

Quick “find it fast” checklist

1. Open the dryer door and inspect the door frame on the cabinet.
2. Check the front panel edge just inside the opening.
3. If you still do not see it, inspect the rear panel.
4. Write down the model and serial exactly as shown (letters and numbers).

Why it matters

Kenmore model numbers can share similar designs, but parts like a belt, thermostat, or gas ignition components can vary by production series. Using the rating label info helps us match the correct part the first time.

What you have	What it’s used for	Example for this dryer
Model number	Matches diagrams and part lists	11071402311
Serial number	Confirms version/series	(from your label)
