Kenmore 79691383410 dryer Parts

For Kenmore dryer model 79691383410, the drying capacity is 7.4 cu. ft. (IEC). If you are asking about a different “Series 500” Kenmore dryer, capacity can vary by model, so we recommend matching the exact model number to the spec table in the 79691383410 owner's manual.

Capacity for model 79691383410 (what to expect)

This Kenmore dryer is a full-size 27-inch platform, so 7.4 cu. ft. is designed for larger everyday loads like towels, jeans, and bedding.

• Capacity listed in the manual: 7.4 cu. ft. (IEC)
• Typical use: medium to large family loads
• Best results: avoid overpacking so air can circulate
• If loads feel “too small” or “too big”: cycle choice and venting usually matter more than capacity

Quick spec snapshot (from the manual)

Spec	Value
Drying capacity	7.4 cu. ft. (IEC)
Width	27 in.
Depth	30 1/4 in.
Height	38 11/16 in.

Why “Series 500” can be confusing

“Series 500” is often used as a retail or lineup label, not a single fixed-capacity product. Kenmore dryer capacity is tied to the exact model number on the ID plate inside the dryer door.

• If your model number matches 79691383410, use 7.4 cu. ft. (IEC)
• If your model number is different, use the capacity listed for that exact model
• If you see multiple capacities online, prioritize the manual spec for your model

Why it matters

Capacity affects how you load the drum and choose cycles, but drying performance is heavily influenced by airflow. A restricted exhaust can make even a large-capacity dryer dry slowly.

Last updated: February 2026

On Kenmore dryer model 79691383410, the model number is printed on the identification plate located inside the dryer door. Open the door and look along the door opening on the cabinet frame for the label; it lists the model and serial number (useful for parts and service). See the 79691383410 owner's manual.

Where to look first (fast checklist)

• Open the dryer door and inspect the cabinet frame around the door opening.
• Look for a rectangular identification plate or sticker with MODEL and SERIAL.
• Check the upper area of the door opening first; labels are often easiest to spot there.
• Wipe lint and dust off the label so the numbers are readable.
• Write down the full model number exactly as shown (all digits).

Other common label locations (if the door label is missing)

If the inside-door label is damaged or unreadable, many dryers also have a rating label:

• On the back of the cabinet near the top
• On a side panel near the rear edge
• Behind the control panel area (less common)

What the label typically shows

Label item	What it’s used for
Model number	Matching the correct parts diagrams and replacement parts
Serial number	Identifying production details for service and support
Electrical or gas info	Confirming power supply requirements and safe installation

Why it matters

We use the exact model number to match the correct Kenmore parts for your dryer, such as a dryer drum belt 4400EL2001F or a dryer door switch EBF61496102. Even one wrong digit can lead to ordering a part that does not fit.

Last updated: February 2026

On Kenmore dryer model 79691383410, the F01 (F1) error code points to a temperature-sensing problem, most commonly the thermistor circuit (the dryer is not reading temperature correctly). This can stop the cycle, trigger beeps, or cause poor drying until the sensing issue is corrected.

What to check first (fast, no parts swapping)

• Unplug the dryer (or switch off the breaker) for 2 minutes, then restore power and retry a cycle.
• Clean the lint filter and confirm strong airflow at the outside vent hood.
• Check that the exhaust duct is not crushed, kinked, or packed with lint.
• Run a timed dry cycle; if it heats briefly then shuts down, suspect an overheating or sensing issue.
• Review the troubleshooting steps and any model-specific indicators in the 79691383410 owner’s manual.

Likely causes and the most common fixes

F01 is usually tied to temperature feedback. These parts are common suspects on this Kenmore dryer platform:

Symptom you notice	Most likely area	Part examples for this model
Stops early, erratic heat, clothes still damp	Temperature sensing	Dryer thermistor AGM30045804
Overheats, shuts down, long dry times	Restricted venting or safety thermostat opening	Dryer high-limit thermostat 6931EL3003C, dryer blower thermostat 6931EL3002M
Long dry times with normal heat	Airflow restriction (not always an error-code part)	Lint filter, duct, vent hood

Why it matters

The thermistor helps the control board regulate heat. When the dryer cannot trust that temperature signal, it may shut the heater down to protect the appliance and your laundry, which shows up as F01 and poor performance.

Helpful DIY reference

If you want to compare error-code behavior across Kenmore 796 dryers, use our Kenmore 796 model dryer error codes guide alongside the manual.

Last updated: February 2026

To hard reset your Kenmore dryer model 79691383410, press POWER to turn it off, then unplug the dryer (or switch off the breaker) for 1 to 5 minutes and restore power. This clears many temporary control glitches; you will need to reselect your cycle afterward (see the 79691383410 owner's manual).

Hard reset steps (recommended)

• Press POWER to turn the dryer off.
• Unplug the power cord (or turn the dedicated breaker off).
• Wait 1 to 5 minutes.
• Restore power.
• Press POWER, select a cycle with the cycle knob, then press START/PAUSE.

If the panel is still unresponsive

• Confirm the dryer has power (outlet, breaker, and cord connection).
• Open and firmly close the door; a failed door switch can prevent starting.
• Clean the lint screen and check the exhaust duct for crushing or restrictions.
• If drying performance is poor, run the manual’s heating and airflow checks.
• If the dryer stops early on sensor cycles, clean the moisture sensor bars and inspect the harness.

Symptom after reset	Most likely area to check	Example related part for this model
Won’t start at all	Door switch, power supply	Dryer door switch EBF61496102
Runs but no heat (gas models)	Igniter, thermostats, airflow	Lg dryer burner igniter 5318EL3001A
Long dry times, “check vent” behavior	Venting, blower wheel, lint housing	Dryer blower wheel 5835EL1002A
Stops early on Auto/Sensor	Moisture sensor, wiring	Dryer moisture sensor 6500EL3001A

Why it matters

A hard reset restores the control to a clean startup state. It helps separate a one-time electronic glitch from a real failure such as restricted venting, a bad door switch, or a heating component problem.

Last updated: February 2026
