Craftsman 917259567 tractor Parts

For Craftsman tractor model 917259567, contact Sears PartsDirect support for product and parts assistance. Using the diagrams and part lists for 917259567 helps match the correct replacement parts the first time, especially for belts, blades, and deck hardware.

What to have ready before you contact us

Having the right details helps us match the correct Craftsman replacement parts the first time:

• Model number: 917259567 (from the tractor ID tag)
• The part description you need (blade, belt, mandrel, hub cap)
• Any symptoms (blades not engaging, tractor not moving, uneven cut)
• Deck information (cutting width and belt routing style)
• The diagram reference or part number from the 917259567 owner's manual

Common parts customers ask about for this model

These are frequent wear items for a front-engine riding mower and tractor like the 917259567:

Part type	Example part (from this model’s parts list)	What it affects
Mulching blade	Husqvarna lawn tractor mulching blade, 21-in 532134149	Cut quality and mulching
Ground drive belt	V-belt 532138255	Tractor movement
Blade drive belt	Lawn tractor drive belt 532144200	Blade engagement

Why it matters

Using the model-specific diagrams in the manual reduces wrong-part orders, especially for belts and blades where length, width, and routing must match the exact Craftsman configuration.

Last updated: March 2026

For a Craftsman front-engine lawn tractor like model 917259567, a complete engine replacement (engine plus labor) typically costs $800 to $2,500. Most shops bill about 4 to 8 labor hours for removal, installation, wiring and linkage hookup, and final adjustments; use the 917259567 owner's manual to identify your exact engine model number before pricing.

What drives the total price

• Engine choice: new, rebuilt, or used replacement engine
• Labor rate and minimum shop charges in your area
• Extra parts needed during the swap (fuel line, clamps, battery cables, hardware)
• Condition of drive and deck components (belts, pulleys, idlers) discovered during teardown
• Setup and verification time (throttle/choke linkage, charging system check, test run)

Typical cost ranges (parts and labor)

Scenario	What you pay for	Typical total
Budget repair	Used or rebuilt engine + basic install	$500 to $1,500
Most common	New replacement engine + standard install	$800 to $2,500
Extensive refresh	New engine + multiple worn items replaced	$1,500 to $3,500

Before you replace the engine, rule out common “no start” causes

Many “dead engine” quotes trace back to starting, safety, or fuel issues.

• Weak battery, dirty terminals, or bad ground connection
• Starter solenoid, starter motor, or loose wiring
• Safety interlock switch problem (seat, brake, PTO)
• Old fuel, clogged fuel filter, dirty carburetor
• Ignition issue (spark plug, ignition coil)

If the engine cranks but will not fire, follow riding lawn mower engine spins but wont start video to narrow it down before committing to an engine swap.

Why it matters

An engine swap is one of the highest-cost repairs on a riding mower. Confirming the engine is truly failed (for example, low compression, heavy smoking, metal in the oil) prevents spending engine-level money when a tune-up or electrical repair restores normal operation.

Last updated: February 2026

For the Craftsman riding lawn tractor model 917259567, the model number is printed on the tractor’s model plate located under the seat. Lift the seat and read the plate; record the model and serial number so you can match the correct parts and owner’s manual.

Where to find the model and serial number

On this Craftsman tractor, we use the identification plate under the seat for the tractor’s model and serial.

• Park on a flat surface, set the parking brake, and remove the key
• Lift the seat up and look for the model/serial plate on the frame beneath it
• Write down the model number and serial number exactly as shown
• Use the model number to look up diagrams and parts; use the serial number to confirm production details
• Keep the info with your paperwork for future repairs and maintenance

Tractor model number vs. engine model number

Your tractor and engine have separate model numbers. This matters when ordering engine-specific parts (like ignition or carburetion items).

What you are identifying	Where to look	Example for this tractor
Tractor model number	Plate under the seat	917259567
Engine model number	Engine blower housing	42E707-2631-E1

Why it matters

Using the correct model number prevents ordering the wrong deck, belt, blade, or steering parts. It also ensures you follow the right maintenance and safety instructions for your exact Craftsman tractor.

Helpful reference

For diagrams, maintenance schedules, and the exact identification location, use the 917259567 owner’s manual.

Last updated: February 2026

If you’re trying to identify your Craftsman riding mower, use the product identification label to confirm the exact model number; for this Sears PartsDirect page, the mower is a Craftsman model 917259567. The label location and the model format are shown in the 917259567 owner's manual.

Where to find the model number on the tractor

On Craftsman front-engine lawn tractors like model 917259567, the model number is on the product identification label. Common places to check include:

• Under the seat (often on the underside of the seat pan or on the frame beneath the seat)
• On the rear fender area near the seat mounting points
• On the frame rail near the engine compartment
• Near the transaxle area on the rear frame

How to confirm you have the right model

Once you find the label, match the model number exactly (all digits). Then use the manual and parts diagrams for that model.

• Match the full model number: 917259567
• Use the correct parts list for your deck and chassis
• Verify deck size and configuration (many tractors use a 42-inch deck)
• Cross-check common wear parts like belts, blades, and tires

Quick check: common parts you might see on this model

System	Example part type	Example part on this model page
Mower deck	Mulching blade	Husqvarna lawn tractor mulching blade, 21-in 532134149
Ground drive	Ground drive belt	V-belt 532138255
Blade drive	Blade drive belt	Lawn tractor drive belt 532144200

Why it matters

Using the exact model number prevents ordering the wrong Craftsman parts (especially belts, mandrel parts, and deck components). It also ensures you follow the correct maintenance and safety instructions for your tractor.

Last updated: February 2026

Craftsman riding mowers and lawn tractors use engines from several manufacturers depending on the specific model and production year. For Craftsman model 917259567, the decals list includes a “B&S” (Briggs & Stratton) panel-side decal and an engine decal indicating 19.5 HP, which points to a Briggs & Stratton-equipped configuration; confirm the exact engine ID on the engine label using the 917259567 owner's manual.

What you will see on the tractor to confirm the engine brand

Use the engine’s ID tag and the tractor decals to identify the manufacturer.

• Check the engine shroud or valve cover for the engine maker name (Briggs & Stratton, Kohler, Kawasaki, etc.)
• Record the engine model, type, and code (or spec number) from the engine label
• Look for “B&S” markings or decals on the hood/side panels
• Match the engine information to the specifications section in the manual
• Use the engine model/type to buy the correct tune-up parts (air filter, spark plug, fuel filter)

Common engine brands used on Craftsman tractors

Craftsman has commonly sourced engines from these brands across different tractor lines:

Engine brand	Where you will typically find it	What to look for
Briggs & Stratton	Many Craftsman lawn tractors	“Briggs & Stratton” label; model/type/code tag
Kohler	Some mid to higher HP tractors	“Kohler” tag; spec number
Kawasaki	Some premium models	“Kawasaki” tag; model/spec

Why it matters

Engine brand and engine ID determine the correct maintenance parts and settings (spark plug type, air filter style, oil capacity, and tune-up intervals). Using the engine label prevents ordering the wrong parts even when the tractor model number is correct.

Last updated: February 2026

For Craftsman riding mower model 917259567, the engine is identified in the tractor documentation as a Briggs & Stratton engine (the manual references B&S labeling/decals). For the exact engine family, displacement, and spec number for your tractor, we match it using the engine ID label shown in the 917259567 owner's manual.

How to identify the exact engine on your 917259567

Use these quick checks so you get the right tune-up and repair parts:

• Look for the engine ID label on the blower housing, valve cover, or near the starter
• Record the model, type, and code (Briggs & Stratton format)
• Compare the label info to the engine section and decals list in the 917259567 owner's manual
• If the hood or side panel decals are missing, rely on the engine ID label, not the decal
• Use the engine ID when buying spark plugs, air filters, fuel filters, and carburetor parts

What the manual tells you (and what it does not)

The tractor manual content for model 917259567 includes references to Briggs & Stratton (B&S) decals and labeling, which confirms the tractor was configured with a B&S engine family. The engine ID label is still the most accurate way to pinpoint the exact engine spec.

Common engine ID fields (Briggs & Stratton)

Label field	What it means	Why you need it
Model	Engine family/series	Identifies the correct parts breakdown
Type	Configuration	Differentiates carburetion, governor, muffler, etc.
Code	Build date	Helps match revisions and service bulletins

Why it matters

Two Craftsman tractors can share the same deck size and horsepower class but use different Briggs & Stratton engine variants. Using the engine ID label prevents wrong-part returns and helps ensure correct starting, charging, and mowing performance.

Last updated: February 2026

For the Craftsman lawn tractor model 917259567, use SAE 30 engine oil when temperatures are above 32°F, and SAE 5W-30 when temperatures are below 32°F. The engine oil capacity is 3.0 pints; confirm the fill and change procedure in the 917259567 owner's manual.

Oil type and temperature chart

Use the oil viscosity that matches your starting temperature.

Outdoor temperature	Recommended oil type	When to use it
Above 32°F	SAE 30	Best for warm-weather mowing
Below 32°F	SAE 5W-30	Easier cold starts and better cold-flow

How we recommend checking and changing oil

Follow the maintenance schedule and always work on a cool engine when possible.

• Park on a level surface, set the parking brake, and remove the key.
• Check the oil level before each use; top off only as needed.
• Change oil more often when mowing in high heat, heavy load, or dusty conditions.
• Refill slowly, then recheck the dipstick to avoid overfilling.
• Wipe up spills immediately; oil on belts and pulleys can cause slipping.

Related specs for this model

These specs help when you are doing a tune-up at the same time.

• Oil capacity: 3.0 pints
• Fuel type: unleaded regular (3.5-gallon capacity)
• Spark plug: Champion RJ19LM (gap .030 in.)

Why it matters

Using the correct viscosity helps your 4-cycle engine maintain oil pressure and lubrication at startup and under load. That reduces wear, keeps operating temperatures under control, and supports longer engine life.

Last updated: February 2026

The Craftsman tractor model 917259567 does not have a single built-in “model year” like a car; the year is identified from the manufacturing date code on the tractor (typically on the product ID label). Use the date-code format shown in the 917259567 owner's manual to translate the code into the correct year.

Where to find the year on model 917259567

On Craftsman riding mowers, the year is normally determined from the product ID label (not the parts list pages). Check these common locations:

• Under the seat pan or on the seat support
• On the rear fender pan near the seat
• On the frame rail near the engine
• Under the hood near the dash tower
• Near the transaxle area on the frame

How the date code is usually read

Many Craftsman-built tractors use a 6-digit date code that reads as:

• MM = month
• DD = day
• YY = year

Example

Date code	Interprets as	Year
072811	July 28, 2011	2011
031205	March 12, 2005	2005

If your label shows 072811, that tractor was built on July 28, 2011.

Why it matters

Knowing the build year helps us match the right Craftsman parts and specs for your 917259567, especially for wear items like belts, steering parts, and deck components that can vary by production run.

Last updated: February 2026
