Kenmore 11062812101 electric dryer Parts

For Kenmore electric dryer model 11062812101, the most reliable “reset” is a hard reset: disconnect power, wait a few minutes, then restore power and start a cycle. This clears many control glitches; if the dryer still will not run, focus on start, door, and airflow checks in the 11062812101 owner's manual.

• Turn the cycle selector to OFF.
• Unplug the dryer (or switch the dryer breaker OFF).
• Wait 2 to 5 minutes.
• Restore power.
• Select a cycle and press PUSH TO START with the door fully closed.

These checks match the most common “no run” causes for this model style:

• Confirm the controls are set to an On/running position and a cycle is selected.
• Press PUSH TO START firmly (some timers need a solid push).
• Close the door tightly; a failed door switch can prevent starting.
• Check the house electrical supply (a tripped breaker or blown fuse can stop operation).
• Make sure the exhaust vent is not crushed or kinked; restricted airflow can lead to overheating and shutdowns.

A reset only clears temporary electrical or control-state issues. If the underlying problem is airflow restriction, a door-switch failure, or a worn drive system, the dryer will keep acting up until the root cause is corrected.

If troubleshooting points to a failed component, these are common matches for this model family:

• Dryer door switch WP3406107 (door must register closed)
• Dryer drum belt 341241 (drum may not turn if the belt is broken)
• Dryer thermal cut-off fuse kit 279816 (overheat protection that can stop operation)

You can order replacement parts for model 11062812101 from the parts list for this dryer, or search by model number on Sears PartsDirect.

Last updated: February 2026

For Kenmore electric dryer model 11062812101, replacing the heating element typically costs about $50 to $120 for the part, plus $0 if you DIY or about $150 to $300+ with professional labor. On this model, the heating element we list is dryer element 279838.

• Heating element part: usually $50 to $120 (varies by model and whether it is an element-only or assembly)
• Service call and labor: commonly $150 to $300+
• Optional related parts: $15 to $60 (if heat damage or airflow issues caused the failure)
• DIY tools/supplies: $0 to $25 (basic hand tools, vacuum, vent brush)

If your dryer overheated or had restricted airflow, we often see these replaced at the same time:

• Dryer thermal cut-off fuse kit 279816 (opens if temperatures get too high)
• Dryer high-limit thermostat WP3977767 (helps regulate heater temperature)
• Venting and lint path cleaning (not a part, but critical to prevent repeat failures)

Our installation instructions recommend verifying power and heat correctly before assuming the element is bad:

• Confirm the dryer is on a heat cycle and running for about 5 minutes
• Check that both house fuses are good or both breakers are on (many electric dryers use a 2-pole supply)
• If the drum tumbles but there is no heat, inspect for lint buildup and airflow restrictions
• Use the 11062812101 installation guide for the model-specific startup and no-heat checks

A failed heating element can be caused by normal wear, but poor airflow (clogged vent, lint buildup) can overheat the heater circuit and repeatedly blow thermal fuses. Fixing the airflow issue helps the new element last.

If you need to order parts beyond what is listed for this model, we also support model-based search on Sears PartsDirect.

Last updated: February 2026

On the Kenmore 11062812101 electric dryer, a blown thermal fuse typically stops the dryer from running at all; in some failure patterns the drum can still tumble but you get no heat. Either way, treat it as an overheat safety shutdown and fix the airflow cause before restarting. See the 11062812101 owner's manual for basic “won’t run” and “no heat” checks.

• Dryer will not start (no tumbling)
• Dryer runs but does not heat
• Cycle seems normal but clothes stay damp (often paired with poor vent airflow)
• Burning smell can occur when a heating element is first used, but persistent overheating symptoms point to airflow or control issues

1. Unplug the dryer (or switch off the breaker) before opening any panels.
2. Confirm the door closes and the switch clicks; a failed door switch can mimic a “dead” dryer (see dryer door switch WP3406107).
3. Check your home electrical supply; many electric dryers use two fuses or two breakers. If one trips/blows, the dryer can run but not heat.
4. Check venting for restriction (crushed, kinked, lint-clogged duct or hood).

Your dryer needs full 240V power for heat. If one house fuse is blown or one breaker is tripped, the motor may still run on 120V but the heater will not energize.

If testing confirms a heat-safety failure, these are common related items for this model:

• Dryer thermal cut-off fuse kit 279816 (often replaced as a set)
• Dryer high-limit thermostat WP3977767 (overheat protection)
• Dryer element 279838 (if heater is open or grounded)

A blown thermal fuse is a safety response to overheating. Replacing the fuse without correcting restricted airflow (lint screen, lint chute, vent duct, outside hood) can cause repeat failures and poor drying performance.

Last updated: February 2026
