LG LFX25971SB/01 refrigerator Parts

LG refrigerator legs are model-specific leveling feet, so the correct price depends on the exact leg part used on your LG LFX25971SB refrigerator and whether you need the front or rear. Use the parts diagram in the LFX25971SB owner's manual to identify the exact leg, then match it to the correct replacement part.

How to find the right “leg” (leveling foot) for LFX25971SB

We recommend identifying the part first, then shopping by the exact part ID or part number.

• Look up the leveling foot (often listed as “leveling leg” or “leveling foot”) in the cabinet or base section
• Confirm whether you need left or right (some designs differ)
• Check if the leg includes a bracket, roller, or mounting hardware
• Compare the old part to the diagram and mounting points
• Order by the exact part number to avoid fit issues

Typical price range (what to expect)

For most LG French door and bottom-mount refrigerators, leveling legs usually fall into a common range depending on design.

Part type	Typical price range	Notes
Basic leveling foot	$10 to $30	Most common style; foot only
Leveling leg with bracket/roller	$25 to $75	More hardware, higher cost
Base/leveling assembly	$50 to $150+	Less common; larger assembly

Quick checks before you buy

A “bad leg” is sometimes a different issue. Check these first:

• The leg is stripped and will not raise or lower
• The refrigerator rocks even after adjustment
• The cabinet is level but doors do not align (hinge or floor issue)
• The leg is fine but the floor is uneven (use a shim rated for appliance weight)

Why it matters

Correct leveling helps the doors seal properly, reduces vibration noise, and can prevent water or ice maker issues caused by poor door closure.

Last updated: January 2026

A leak from the bottom of an LG LFX25971SB refrigerator is usually caused by a clogged defrost drain that overflows into the base, or a water supply issue such as a cracked/loose water line or a seeping inlet valve. Start by checking for ice or debris in the drain path and inspecting the water tubing connections.

Most common causes (and what to look for)

• Clogged defrost drain: Water backs up, then spills into the bottom and onto the floor.
• Frozen drain trough: Ice blocks meltwater from reaching the drain tube.
• Leaking water tubing: Drips at fittings or a pinhole leak in the line.
• Water inlet valve seep: Slow leak even when not dispensing water.
• Door gasket leak: Warm air causes excess frost, which creates more defrost water than the drain can handle (the manual notes gasket leaks can affect run time and performance).

Quick checks we recommend (10 to 20 minutes)

1. Unplug the refrigerator before accessing the rear or lower areas (see safety notes in the LFX25971SB owner's manual).
2. Pull the unit out and look for water trails from the back down to the floor.
3. Check the water line fittings for moisture and make sure the tubing is fully seated.
4. Look inside the freezer for ice buildup on the floor or back panel (a clue the defrost drain is blocked).
5. Inspect door gaskets for gaps, tears, or areas that do not seal flat.

Parts that commonly solve bottom leaks on this model

Symptom you see	Likely area	Part to inspect/replace
Water only when ice maker/dispenser runs	Supply circuit	Refrigerator water tubing MJU62070602
Slow drip behind unit all the time	Valve area	LG refrigerator water inlet valve MJX41178908
Puddle after defrost cycle, ice in freezer bottom	Drain system	Refrigerator drain tube 5251JA3003D

Why it matters

Water at the bottom can damage flooring and also lead to ice buildup in the freezer compartment, which reduces airflow and cooling performance. Fixing the drain path or stopping a small supply leak early prevents bigger cooling and ice maker problems.

Helpful DIY guidance

• How to get rid of refrigerator puddles
• How to diagnose a faulty refrigerator water inlet valve

Last updated: January 2026

For the LG LFX25971SB, the most common service complaint we see across LG refrigerators is a cooling problem (warm fridge or freezer). Cooling issues are often tied to airflow, defrost, or sealed-system components, so we start with basic checks before replacing major parts. See the LFX25971SB owner's manual for model-specific troubleshooting steps.

Quick checks we recommend first

• Confirm the refrigerator is not in a defrost cycle and the controls are set correctly.
• Make sure the doors fully close and the gaskets seal all the way around.
• Verify vents inside the fresh food section are not blocked by food packages.
• Clean dust from the condenser area to improve heat release.
• Listen for the evaporator fan; if it is not running, airflow will be weak.

Common symptoms and what they usually point to

Symptom	Most likely area	What to check next
Fridge warm, freezer OK	Airflow from freezer to fridge	Vents blocked, evaporator fan noise/operation
Both sections warm	Sealed system or condenser cooling	Condenser fan, condenser coil cleanliness
Frost buildup, temps drift	Defrost system	Defrost heater, defrost pattern, door left ajar
Clicking, lights work but poor cooling	Compressor start/cooling system	Basic power checks, then sealed-system diagnosis

Parts that commonly relate to cooling and airflow complaints

If your symptoms match, these model-compatible parts are often involved in diagnosis or repair:

• Refrigerator evaporator fan motor 4681JB1027C (moves cold air through the compartments)
• LG refrigerator defrost heater 5300JK1005D (melts frost off the evaporator during defrost)
• Refrigerator condenser coil ACG73964501 (releases heat so the system can cool properly)

Why it matters

A refrigerator can look “on” (lights and display working) but still not cool if airflow is restricted or frost blocks the evaporator. Catching those issues early helps protect food and can prevent longer run times and temperature swings.

Helpful DIY resources

• LG bottom freezer refrigerator error codes
• How to fix your evaporator cooling fan

Last updated: January 2026
