Kenmore Elite 79578559800 refrigerator Parts

To raise your Kenmore Elite refrigerator model 79578559800 off the floor, we adjust the front leveling legs to lift the front of the cabinet. This is done after removing the base cover; the manual notes the front should sit slightly higher than the back for proper door closing.

How to raise the front (leveling legs)

1. Move the refrigerator into its final position.
2. Open the freezer drawer to access the screws, then remove the base cover.
3. Use an 11/32-inch (8 mm) wrench or a flat-blade screwdriver on the leveling leg adjusters.
4. Turn both front leveling legs the same amount to keep the cabinet square.

• Turn the leveling legs counterclockwise (CCW) to raise the front.
• Turn the leveling legs clockwise (CW) to lower the front.
• Have someone gently push backward on the top of the refrigerator to reduce weight on the legs.
• Recheck that both fresh food doors close easily.
• Reinstall the base cover when finished.

For the exact procedure and illustrations, follow the owner's manual.

Door closing and alignment tips

If you are raising the refrigerator to help doors close better, the manual recommends a slight rearward tilt.

What you notice	What to adjust	What to expect
Doors do not close easily	Raise the front slightly (CCW)	Doors close more smoothly
Refrigerator feels unsteady	Level side-to-side using both legs	Cabinet stops rocking
Gap between doors is uneven	Use the snap rings at the middle hinge	Doors align evenly

Why it matters

Correct leveling helps the doors seal, prevents warm air leaks, and supports proper airflow between the freezer and fresh food sections. It also reduces strain on hinges and helps avoid moisture and frost issues.

Last updated: February 2026

To adjust door height on your Kenmore Elite refrigerator model 79578559800, we level the cabinet first using the front leveling legs, then fine-tune door alignment. If the gap between the two fresh food doors is uneven, we raise the low door by adding snap rings at the middle hinge (as described in the owner's manual).

Step 1: Level the refrigerator (this affects door height)

A refrigerator that leans left, right, or forward can make one door look “lower” and can prevent proper closing.

• Unplug the refrigerator if you will be working near wiring; otherwise keep hands clear of moving parts.
• Open the freezer drawer and remove the base cover (screws are accessible with the drawer open).
• Use an 11/32-inch (8 mm) wrench or a flat-blade screwdriver on the leveling legs.
• Turn the leveling leg clockwise to raise that side; counterclockwise to lower it.
• Keep the front slightly higher than the back so the doors close more easily.

Step 2: Align the doors using snap rings (hinge height adjustment)

If the space between the two doors is uneven after leveling, we adjust the door height at the hinge.

• Lift up the door you want to raise at the middle hinge.
• Use pliers to insert a snap ring onto the hinge pin (per the manual’s diagram).
• Add additional snap rings until the doors line up evenly.
• Recheck door closing and gasket contact along the full perimeter.

Quick comparison: leveling legs vs. snap rings

Adjustment method	What it changes	Best for
Leveling legs	Cabinet tilt and overall door swing	Doors not closing easily, refrigerator feels unsteady
Snap rings at middle hinge	One door’s height relative to the other	Uneven gap between the two fresh food doors

Why it matters

Proper leveling and door alignment helps the doors seal correctly, prevents warm air leaks, reduces frost buildup, and keeps temperatures stable in both the refrigerator and freezer compartments.

Last updated: February 2026

On Kenmore Elite model 79578559800, a bottom freezer that is not freezing is usually caused by interrupted airflow (blocked vents or overpacked drawers), warm air leaking past the door gasket, or a control setting that is not cold enough. Start with airflow and temperature settings in the 79578559800 owner's manual.

Quick checks that fix most “not freezing” complaints

• Set the freezer to 0°F (-18°C) and wait 24 hours for temperatures to stabilize.
• Make sure packages are not blocking the cool air vents; blocked vents stop circulation.
• Avoid overpacking; leave space for air to move from the top vent down through the freezer.
• Confirm the freezer door closes fully; frost and weak freezing often follow frequent openings.
• If you recently added a lot of food, use the Ultra Ice feature for faster pull-down.

Step-by-step troubleshooting (in order)

1) Verify control settings and stabilization time

Your refrigerator uses separate refrigerator and freezer controls; the freezer control affects how much cold air stays in the freezer. Make one change at a time, then wait 24 hours before rechecking.

2) Restore proper airflow

Air enters at the top of the freezer, circulates down, then returns upward to the refrigerator. If vents are blocked, the freezer warms and food softens.

3) Check for door sealing problems

Warm, humid air entering the freezer creates frost and reduces freezing performance.

What you’ll typically observe (symptom guide)

What you notice	Most likely cause	What to do first
Freezer is cool but food is soft	Vents blocked or overpacked	Clear vents, reorganize
Frost buildup, icy packages	Door not sealing or opened often	Inspect gasket, reduce openings
Ice cream soft, temps fluctuate	Settings changed too often	Set to 0°F, wait 24 hours
Slow recovery after loading groceries	Normal load pull-down	Use Ultra Ice for 24 hours

Why it matters

Freezer cooling on this model depends on steady airflow between compartments. When vents are blocked or warm air leaks in, the compressor can run longer but the freezer still cannot hold 0°F, which risks food quality and safety.

Last updated: February 2026

On the Kenmore Elite refrigerator model 79578559800, the model and serial number are printed on an identification label inside the fresh food (refrigerator) compartment; it’s located on the right-hand side wall. Use that exact model number when ordering parts or checking troubleshooting info in the owner's manual.

Quick places to check first

• Open the refrigerator door and look on the right interior wall of the refrigerator compartment.
• Look for a rating/ID label with both model and serial numbers.
• Wipe the area with a damp cloth if the label is dusty or hard to read.
• Use a flashlight; labels are often easier to read at an angle.
• Write the full model number exactly as shown (including all digits).

Why the model number matters

Kenmore 795-series bottom-mount refrigerators can share similar styling but use different parts (door switch, defrost heater, sensors, bins). The correct model number ensures you get the right replacement part and the right procedure in the manual.

Common label details you’ll see

Label item	What it’s used for	Example for this unit
Model number	Parts lookup, manual match	79578559800
Serial number	Production info, service history	Varies by unit

If you’re ordering a part after you find the model number

Match the part to your exact model, then compare the part ID and name. Examples of parts listed for this model include:

• Lg refrigerator door switch 6600JB1010A (door light and door-closed signal)
• Refrigerator defrost heater 5300JK1005D (melts frost off the evaporator)
• Refrigerator door basket AAP73871501 (door storage bin)

Why it matters (symptoms tied to the right model)

A wrong model number can lead to parts that do not fit, wiring connectors that do not match, or troubleshooting steps that do not apply, especially for dispenser, icemaker, and defrost-system issues.

Last updated: February 2026

Common issues on the Kenmore Elite 79578559800 bottom-mount refrigerator include warm temperatures from airflow or defrost problems, water leaks (often tied to drain or water line issues), ice maker and dispenser troubles, door sealing and alignment problems, and normal-to-loud operating noises. Our owner's manual troubleshooting and care sections cover many of these symptoms and the first checks to make.

Most common symptoms and what usually causes them

• Not cooling or temps drifting: blocked air vents, controls set incorrectly, dirty condenser coils, failed fan motor, or a defrost system problem.
• Freezer too warm or slow ice production: frequent door openings, heavy ice use, blocked vents, or settings needing adjustment.
• Water on the floor or in the fridge: a clogged/iced drain, cracked drain tube, or a leaking water line connection.
• Ice tastes bad or smells: old ice, unwrapped food odors, dirty bin, or water quality issues.
• Lights not working: loose/burned-out bulb or a door switch issue.

Quick checks we recommend first (no parts swapping)

• Confirm the refrigerator is plugged in and the breaker is on; allow about 30 minutes if it is in a defrost cycle.
• Adjust temperatures in small steps and wait 24 hours between adjustments before judging results.
• Make sure packages are not blocking interior air vents.
• Clean condenser coils as part of routine maintenance.
• Inspect door gaskets for dirt or sticking; clean the gasket and mating surface.

Parts that commonly solve these problems

If symptoms point to a specific failure, these model-matched parts are common fixes:

Symptom	Common suspect part	Example part on this model page
Lights stay off or act erratic	Door switch	Lg refrigerator door switch 6600JB1010A
Water leaking inside or under unit	Drain tube	Refrigerator drain tube 5251JA3003D
No water at dispenser or no ice fill	Water inlet valve	Lg refrigerator water inlet valve 5221JB2006K
Frost buildup, warm temps after a few days	Defrost heater or sensor	Lg refrigerator defrost heater 5300JK1005D, refrigerator defrost sensor assembly 6615JB2005H

Why it matters

Catching airflow, defrost, and water-leak issues early helps protect food temperatures, prevents ice buildup that restricts circulation, and reduces the chance of floor damage from recurring leaks.

Last updated: February 2026
