Where is the model number on Kenmore Elite dryer?
On a Kenmore Elite dryer like model 79681722000, the model number is printed on the rating label, most often on the door opening area (door jamb) or just inside the door on the cabinet frame. Some units also place the label on the back panel near the top.
Where to look first (fastest checks)
- Open the dryer door and check the cabinet frame around the opening (door jamb area).
- Look just inside the door opening on the front panel edge.
- Check the back of the dryer near the top (especially if the front label is worn).
- If you have a pedestal or tight closet install, use a flashlight and phone camera to read the label.
What the label looks like and what to write down
The rating label usually includes the model number and serial number. For parts ordering and troubleshooting, we recommend recording:
- Model number (example: 79681722000)
- Serial number
- Power type (electric or gas)
- Any option codes listed on the tag
| What you need | Why we ask for it | Example |
|---|---|---|
| Model number | Ensures correct part fit | 79681722000 |
| Serial number | Helps match production changes | (varies) |
| Fuel type | Changes heating parts and wiring | Electric or gas |
Why it matters
Kenmore Elite dryers can look similar across multiple 796-series models, but parts like the heating element, thermostats, belt, and door switch can vary by model and production run. Using the exact model number helps us match the correct replacement part the first time.
Helpful references
- Use the diagrams and identification notes in the 79681722000 owner’s manual to confirm the label location and record the correct model and serial information.
- If you’re diagnosing a display message after you find the model number, use the Kenmore elite dryer error codes guide to narrow down likely causes.
Last updated: January 2026
How to hard reset a Kenmore dryer?
To hard reset your Kenmore Elite dryer model 79681722000, unplug the power cord (or switch the breaker off) for 5 minutes, then restore power and start a cycle. This clears many temporary control glitches; if the dryer still will not run or heat, a safety device or airflow problem is usually the real cause. See the 79681722000 owner's manual for the exact reset and cycle-start steps.
Hard reset steps (safe and effective)
- Turn the dryer OFF.
- Unplug the dryer; if you cannot access the plug, turn OFF the dryer breaker.
- Wait 5 minutes (1 minute often works, 5 minutes is more thorough).
- Restore power.
- Open and close the door once, then press Power and start a normal cycle.
- If an error code returns, use the Kenmore elite dryer error codes guide to match the code to a fix.
If the reset does not work, check these common causes
A hard reset will not fix a failed part or a safety shutdown. These checks solve most “won’t start” and “no heat” complaints.
- Airflow restriction: clean the lint screen, lint duct, and vent run; confirm strong airflow outside.
- Door not registering closed: a bad door switch can prevent starting.
- Overheat protection tripped: restricted venting can trigger thermostats and stop heat.
- Moisture sensor issues: sensor bars can misread dampness and end cycles early.
- Drive system problem: a broken belt can stop the drum from turning.
Quick symptom-to-part map
| Symptom | Most likely area | Example part for this model |
|---|---|---|
| Dryer runs but no heat | Heating circuit, airflow | Lg dryer heating element 5301EL1001H |
| Dryer shuts off or overheats | Venting, thermostats | Dryer high-limit thermostat 6931EL3003D |
| Drum will not turn | Belt, idler, rollers | Dryer drum belt 4400EL2001F |
| Cycle ends too soon | Moisture sensing | Dryer moisture sensor 6500EL3001A |
Why it matters
Resetting clears the control board’s temporary state, but dryers also stop for safety when they detect overheating, a door-open condition, or a drive problem. Fixing airflow and the underlying part issue prevents repeat shutdowns and improves drying time.
Last updated: January 2026
What is the lifespan of a Kenmore dryer?
A Kenmore dryer like model 79681722000 typically lasts 10 to 13 years. With consistent airflow maintenance and timely replacement of wear items (belt, rollers, thermostats), it’s common for an Elite dryer to reach the upper end of that range.
Typical lifespan and what changes it
Most dryers fail early due to heat stress and restricted venting, not because the cabinet or drum “wears out.” We recommend using the 79681722000 owner's manual for the maintenance schedule and cleaning guidance.
Big factors that shorten dryer life:
- Clogged lint screen or lint buildup in the housing
- Long, crushed, or partially blocked vent duct
- Frequent overloading (extra strain on the drum belt and motor)
- Overheating from poor airflow (stresses thermostats and the heating element)
- Ignoring squealing, thumping, or burning smells
Parts that commonly determine “end of life”
If the dryer still tumbles and heats correctly after replacing common wear parts, the machine usually has plenty of life left.
| Symptom | Common wear area | Example part for this model |
|---|---|---|
| Drum not turning | Belt or idler system | Dryer drum belt 4400EL2001F |
| Squealing or thumping | Drum support rollers | Dryer drum support roller |
| No heat or overheating | Heating circuit safety parts | Dryer high-limit thermostat |
Maintenance that adds years (practical checklist)
- Clean the lint screen every load; wash it with mild soap monthly to remove residue.
- Check airflow: strong exhaust outside means faster drying and less heat stress.
- Clean the vent duct at least yearly (more often with pets or heavy use).
- Avoid overloading; heavy loads stretch the belt and strain the motor.
- Stop using the dryer if you smell burning; inspect lint buildup and venting first.
Why it matters
A dryer that runs hot because of restricted airflow wears out expensive components faster (heating element, thermostats, motor) and also dries slower, which increases energy use.
Last updated: January 2026
How much does it cost to replace a heating element in a Kenmore dryer?
For Kenmore Elite dryer model 79681722000, the total cost to replace the heating element is typically $120 to $350 when you hire service (part plus labor). If you do it yourself, you usually pay the part cost only, which commonly falls in the $30 to $120 range for many Kenmore and LG-built electric dryers. Use the 79681722000 manual for safety and access steps.
Typical cost breakdown
- Heating element part: often $30 to $120 (varies by exact kit vs element-only)
- Labor: often $90 to $230 (service call plus installation)
- Common extras: vent cleaning, a thermostat, or a thermal cutoff if testing shows a failure
| Scenario | What you pay for | Typical total |
|---|---|---|
| DIY replacement | Part only | $30 to $120 |
| Pro replacement | Part + labor | $120 to $350 |
| Pro plus airflow service | Part + labor + vent work | $170 to $450 |
What changes the price the most
- How the element is sold: element-only vs a kit that includes thermostats
- Airflow restrictions: clogged lint screen housing, crushed vent, long vent run
- Extra failed heat-safety parts: high-limit thermostat, blower thermostat, thermal cutoff
- Diagnosis time: verifying 240 VAC supply, wiring, and control operation
Parts we commonly check when a dryer will not heat
If the drum tumbles but there is no heat, we typically test the heater circuit components together:
- Lg dryer heating element 5301EL1001H
- Dryer high-limit thermostat 6931EL3003D
- Dryer blower thermostat 6931EL3002M
Why it matters
A heating element often fails after repeated overheating from poor airflow. Fixing venting and replacing any weak thermostats helps the new element last longer and restores normal drying time.
