No. On Whirlpool model WRX735SDHW00, the cardboard-like panel at the bottom rear is a protective cover and airflow guide for the condenser area; it should stay in place during normal use. Use the WRX735SDHW00 owner's manual for the correct packing-material removal steps.

What to remove vs. what to leave

Remove only shipping materials that are clearly temporary; leave any fixed covers or panels.

• Remove exterior tape, stretch wrap, and foam blocks
• Remove cardboard spacers used to protect doors and shelves in the box
• Remove any film on stainless or plastic trim (if present)
• Leave the bottom rear cover (often looks like cardboard or fiberboard)
• Leave any screwed-in or clipped-in panels and guards

Quick check: is it packaging or a permanent cover?

Use this checklist before pulling anything off the bottom.

What you see	Usually means	What we recommend
Panel is screwed on or clipped into a frame	Permanent condenser/airflow cover	Leave it installed
Panel has wiring or tubing routed near it	Component protection	Leave it installed
Loose cardboard pieces inside the cabinet	Shipping protection	Remove it
Printed “remove” instructions on a tag/tape	Shipping material	Remove it

Why it matters

That bottom cover helps protect components and supports proper airflow across the condenser. Removing it can reduce cooling efficiency, increase run time, and make the refrigerator more prone to dust buildup around the condenser area.

If you already removed it

• Reinstall the cover if it is intact and you still have the fasteners
• Vacuum dust from the condenser area carefully (avoid bending coils)
• Confirm the refrigerator is level and has adequate clearance for airflow

Last updated: February 2026

Most Whirlpool refrigerators, including the Whirlpool WRX735SDHW00 bottom-mount refrigerator, typically last 10 to 15 years with normal household use. With consistent maintenance (cleaning coils, keeping door seals tight, and changing filters on schedule), it’s common to reach the upper end of that range.

Typical lifespan and what affects it

A refrigerator’s life depends more on operating conditions and maintenance than the badge on the door.

• Heat and airflow: Poor ventilation around the cabinet makes the compressor work harder.
• Dirty condenser coils: Dust buildup raises run time and wear.
• Door gasket condition: Air leaks cause longer run cycles and temperature swings.
• Water and ice system upkeep: Clogged filters and low water flow can strain valves and the ice maker.
• Usage habits: Frequent door openings and overpacking reduce efficiency.

Maintenance checklist that helps you get the full lifespan

Use these as your baseline for WRX735SDHW00 care; for model-specific care and intervals, follow the owner's manual.

• Vacuum condenser area and clean coils periodically.
• Keep doors closing squarely; avoid storing items that prevent full closure.
• Replace the water filter on schedule (a common fit is refrigerator water filter EDR4RXD1).
• Confirm freezer and fresh food temps stay stable (about 0°F freezer, 37°F fresh food).
• Address puddles, frost, or warm spots quickly to prevent secondary damage.

Quick guide: “repair or replace” decision

What you’re seeing	What it usually means	Best next step
Temps drift, food spoils	Airflow, sensor, or sealed-system strain	Check coils, vents, gasket; review Whirlpool refrigerator error codes
Ice maker stops or is slow	Water flow or ice maker issue	Check filter and water supply; inspect ice maker
Water dispenser slow	Filter restriction or valve issue	Replace filter; test inlet valve
Loud fan noise	Fan blade/ice buildup	Clear ice; inspect fan area

Why it matters

A refrigerator that runs longer than it should uses more energy and wears out key components faster (compressor, fans, and controls). Simple upkeep often prevents the “slow decline” that shortens lifespan.

Last updated: February 2026

The most common Whirlpool refrigerator problem is a cooling complaint (warm fridge, soft ice, or temperature swings). On the Whirlpool WRX735SDHW00 bottom-mount refrigerator, the most frequent root causes are airflow and maintenance issues such as dirty condenser coils, a door not sealing, or a restricted defrost drain; water and ice issues are also common.

Most common symptoms we see

• Refrigerator section too warm while freezer seems OK
• Freezer temperature swings or soft ice
• Unit runs constantly or is louder than normal
• Water dispenser slows down or tastes off
• Ice maker stops producing or makes small/hollow cubes

Quick checks that fix many “not cooling” calls

1. Clean the condenser coils (dust buildup reduces heat removal and raises temps).
2. Confirm doors seal tightly; check for gaps, torn gasket areas, or items blocking closure.
3. Verify airflow; do not pack food tightly against vents in the fresh food section.
4. Check for water under crispers; this often points to a partially clogged defrost drain.
5. Confirm control settings; return to recommended temps in the owner's manual.

Parts that commonly relate to these problems (for WRX735SDHW00)

Symptom	Common cause	Example part on this model
Warm temps or temp swings	Sensor reading off	Refrigerator thermistor W10316760
Frost buildup, poor airflow	Door not sealing	Whirlpool refrigerator door gasket (gray) W10830274
No ice or slow fill	Water supply issue or valve not opening fully	Valve-dual w W11043013
Bad-tasting water, slow flow	Clogged filter	Refrigerator water filter EDR4RXD1

Why it matters

Cooling and ice maker problems often start as simple airflow or water-flow restrictions. Fixing those early helps prevent food spoilage, reduces run time, and avoids extra strain on the compressor and controls.

Helpful DIY guidance

• Use our Whirlpool refrigerator error codes reference if your display shows an error.
• For dispenser and ice performance, follow the prevention tips in how to prevent water dispenser and ice maker problems.

Last updated: February 2026

Yes. A bottom-mount refrigerator like the Whirlpool WRX735SDHW00 is a great choice for most kitchens because the fresh-food section sits at eye level, so you reach for everyday items with less bending. The tradeoff is slightly less freezer visibility and, in many lineups, a higher price than basic top-freezer models.

Why many people prefer bottom-mount designs

Bottom-mount (often French door with a lower freezer drawer) layouts are built around how most households use a refrigerator: you access the refrigerator compartment far more often than the freezer.

Common benefits

• Less bending for milk, produce, and leftovers (fresh-food section is higher)
• Wider refrigerator shelves for platters and meal prep containers
• Freezer drawer can hold bulky items (bags of frozen food, pizza boxes)
• Often includes premium features like in-door ice and water

What to consider before you buy or keep one

Bottom-mount is “good” when it matches your habits and space.

Potential downsides

• Freezer items can stack in a drawer, so organization matters
• Heavier freezer drawer to pull out when fully loaded
• More door bins and seals to keep clean and sealing well
• Repairs can be more feature-related (ice maker, dispenser, controls)

Quick comparison

Feature	Bottom-mount refrigerator	Top-freezer refrigerator
Everyday access	Best (fresh food at eye level)	Good (more bending)
Freezer access	Drawer, lower	Door, upper
Organization	Great in fridge; freezer needs bins	Simple, easy freezer visibility
Typical cost	Higher	Lower

Why it matters

Choosing the right layout reduces daily strain and food waste. If you open the refrigerator dozens of times a day, keeping fresh food at a comfortable height is a real quality-of-life upgrade.

Model-specific tip for WRX735SDHW00 owners

For best performance and fewer “it’s not cooling right” complaints, keep airflow paths clear (do not pack items tightly against vents) and follow the temperature and loading guidance in the owner's manual.
