Kenmore 11060202990 electric dryer Parts

For Kenmore electric dryer model 11060202990, replacing the heating element typically costs $50 to $120 for the part plus $100 to $250 for labor if you hire service, so most total repairs land around $150 to $370 depending on access, venting condition, and what else is replaced.

• Heating element part: commonly $50 to $120 (this model’s listed element is dryer element 279838)
• Optional safety parts (often replaced together): cut-off kit 279816
• Labor (service call + installation): usually $100 to $250
• DIY supplies: $0 to $20 (vacuum, nut driver, terminals if needed)

• Restricted venting causing overheating (tech may recommend cleaning before replacing parts)
• Burned wiring/terminals at the heater connections (may need a wire/terminal kit)
• Multiple failed heat components (element plus thermostat or thermal cut-off)
• Hard-to-access installation (tight closet, stacked setup, long vent run)

A failed heating element stops heat, but overheating from poor airflow can also blow the thermal cut-off and shorten the life of the new element. Keeping airflow strong helps the dryer heat correctly and protects parts.

Use the 11060202990 owner’s manual to confirm basic operation and safety steps, then:

• Verify the cycle is set to a heated dry setting (not air dry)
• Clean the lint screen and check for strong airflow at the exhaust
• Inspect the vent for crushing or kinks behind the dryer
• If the dryer runs but won’t heat, plan to test the element and thermal cut-off circuit

Last updated: February 2026

The Kenmore electric dryer model 11060202990 is a 29-inch wide dryer. For the exact overall cabinet height and depth (which can vary by venting setup and leveling legs), we recommend confirming the dimensions in the 11060202990 owner's manual.

From the documentation for this Kenmore dryer, the key size identifier is the cabinet width.

• Cabinet width: 29 inches
• Type: Kenmore electric dryer
• Fit considerations: allow space for the power cord, exhaust vent, and rear clearance
• Leveling matters: the dryer should be leveled front-to-back and side-to-side for best operation

Most full-size 29-inch Kenmore and Whirlpool-built dryers are close to these planning ranges (measure your unit for exact numbers):

Use a tape measure and capture the largest points (not just the cabinet box).

• Measure width at the widest point across the front
• Measure height from the floor to the top (with the dryer leveled)
• Measure depth from the back to the front of the closed door (include the door curve)
• Add extra depth for the vent connection and elbow behind the dryer
• If installing in a closet, confirm required clearances in the manual

Correct dimensions help prevent a crushed or kinked vent, make hookups easier, and reduce vibration and noise. A tight fit can also make routine maintenance like lint removal harder.

Last updated: February 2026

Your Kenmore dryer’s model number is printed on the model and serial number plate; on model 11060202990, it’s typically found in the door opening area. Once you have that full model number, we can match the correct parts, wiring, and specifications for your exact dryer.

Check these common locations on Kenmore electric dryers like 11060202990:

• Inside the dryer door opening on the cabinet frame
• On the back panel of the dryer cabinet
• Near the lint screen housing area (depending on the design)
• On a metal plate or durable sticker labeled “Model” and “Serial”

For the exact location and how the plate is labeled, use the 11060202990 owner's manual.

Kenmore model numbers are usually a long string of digits. Write it down exactly as shown, including all numbers.

• Ensures you get the correct replacement parts (belt, heater, thermostat, switch)
• Helps confirm electrical requirements and wiring style
• Improves troubleshooting accuracy for “won’t start” or “no heat” symptoms
• Prevents ordering look-alike parts that do not fit

Once you confirm the model number, these are examples of parts commonly ordered for this model:

• Record both model and serial numbers from the same plate
• Take a clear photo of the plate before ordering parts
• If the plate is worn, clean it gently with a damp cloth and re-check the digits

Last updated: February 2026

A blown thermal fuse on your Kenmore electric dryer model 11060202990 usually shows up as a dryer that will not run at all, or a dryer that runs but will not heat. The sure way to confirm is a continuity test with the dryer unplugged.

• Dryer will not start (no motor run)
• Dryer tumbles but there is no heat
• Cycle seems normal but clothes stay damp
• You recently had poor airflow (kinked vent, clogged lint)
• You had a “no heat” situation even though the timer advances

1. Unplug the dryer (or switch off the breaker).
2. Access the fuse location using the disassembly steps in the 11060202990 owner's manual.
3. Pull the wires off the fuse terminals (note their positions).
4. Set a multimeter to continuity or lowest ohms.
5. Touch a probe to each terminal.

A thermal fuse is a one-time safety device that opens when the dryer overheats. Overheating is commonly caused by restricted airflow. Your manual’s troubleshooting guidance for poor drying points to checking airflow at the outside exhaust hood and correcting crushed or kinked venting, and it notes that a dryer can appear to run but not heat if a house fuse is blown or a breaker is tripped. Use the venting and troubleshooting sections in the 11060202990 owner's manual to correct the root cause before running the dryer again.

If overheating or “no heat” continues after airflow is corrected, these model-matched parts are commonly inspected or replaced during diagnosis:

• Cut-off kit 279816 (thermal cut-off components)
• Dryer operating thermostat WP3387134
• Dryer thermostat WP3977767 (high-limit thermostat)

Last updated: February 2026
