An F30 error on the Frigidaire FFEF3016TSD electric range points to a problem in the oven temperature sensing circuit (most often the oven temperature sensor or its wiring). We fix it by safely checking the sensor resistance, inspecting the harness connections, and replacing the failed part if readings or wiring are out of range.

What to do first (safe, fast checks)

• Turn the range off and disconnect power at the breaker (240V).
• Let the oven cool completely before touching any internal parts.
• Reseat the oven temperature sensor connector; a loose plug can trigger F30.
• Inspect the sensor wiring for heat damage, pinched insulation, or corrosion at terminals.
• If the code returns immediately after power is restored, move to electrical testing.

Test the oven temperature sensor (most common fix)

Use a multimeter to measure sensor resistance; the exact access steps and connector location are shown in the FFEF3016TSD owner’s manual.

Typical sensor readings for many Frigidaire electric ranges:

Oven temperature	Typical sensor resistance
Room temp (70°F)	~1050 to 1100 ohms
350°F	~1650 ohms
550°F	~2200 ohms

If the sensor reads open (infinite), shorted (near 0), or far outside these ranges at the measured temperature, replace the sensor.

Model-matched part: Frigidaire range oven temperature sensor 316490000

If the sensor tests good: check wiring and control

If resistance is normal, the issue is usually the wiring harness or the electronic oven control.

• Check continuity from the sensor connector back to the control (power still off).
• Look for burned or loose terminals at any inline connectors.
• If wiring is good and F30 persists, the control board can be the cause.

Why it matters

When the control cannot trust the temperature signal, it may shut down heating to prevent overheating or unsafe operation. Fixing the sensor circuit restores accurate baking and normal oven operation.

Last updated: January 2026

To reset your Frigidaire electric freestanding range model FFEF3016TSD, turn the range off and remove power for about 30 seconds, then restore power. This clears many control glitches; if the cooktop and oven still do not heat, focus next on power supply and wiring.

Quick reset steps

• Turn all surface element knobs to OFF.
• If the oven is running, press Cancel/Off.
• Unplug the range (or switch the range breaker OFF).
• Wait 30 seconds.
• Restore power and set the clock if needed.

If nothing heats after the reset

A reset will not fix a missing leg of power on a 240-volt range circuit. Check these common causes first:

• Tripped double-pole breaker (one side can trip)
• Loose power cord connections at the terminal block
• Burned wiring or a damaged harness
• Failed surface element receptacle or control switch

What to check (in order)

Check	What you might notice	What it points to
Breaker (double-pole)	Display works but no heat	Partial power (one leg missing)
Terminal block area	Burning smell, discoloration	Loose connection or heat damage
Surface element circuit	One burner dead	Switch, receptacle, or element issue

Parts that commonly relate to “no heat” symptoms

If only one burner is not heating (not the whole range), these model-matched parts are often involved:

• Range surface element receptacle 5303935058 (burned or loose connection at the coil element)
• Frigidaire range surface element control switch 316436001 (burner will not regulate or will not turn on)

Why it matters

Resetting is a safe first step for electronic control hiccups, but a range that will not heat can indicate a power supply problem that can overheat wiring if ignored. Confirming proper power and tight connections protects the control board, elements, and wiring.

For model-specific electrical access points and safety steps, follow the FFEF3016TSD owner’s manual and the FFEF3016TSD installation guide.

Last updated: January 2026

The most common issues we see with the Frigidaire FFEF3016TSD electric freestanding range are heating problems (oven not baking or broiling evenly), surface burner temperature control problems, and inaccurate oven temperatures. Many of these symptoms trace back to a failed heating element, a bad control switch, or a drifting temperature sensor.

Common symptoms and what they usually point to

• Oven not heating in Bake: failed or damaged bake element, wiring issue, or control problem (often the bake circuit)
• Broil not working: failed broil element or a control issue
• Oven temperature off (too hot or too cool): oven temperature sensor out of range, calibration needed, or control board issue
• Surface element stuck on high or won’t heat: surface element control switch failure
• Burner cycles erratically: incorrect switch for the burner size, loose terminal connections, or worn switch contacts

Parts that commonly fix these problems

If your symptoms match, these model-compatible parts are frequent solutions:

Symptom	Common fix	Example part on this model page
No bake heat	Replace bake element	Range bake element 316075103
No broil heat	Replace broil element	Range broil element 316203200
Oven temp inaccurate	Replace temperature sensor	Range oven temperature sensor 316490000
Burner won’t regulate	Replace control switch	Range surface element control switch 316436001

Quick checks we recommend before replacing parts

• Confirm the range has 240V power (a tripped double breaker can leave you with lights but weak or no heat).
• Inspect the element for blisters, cracks, or burn spots.
• For surface burners, check the element is fully seated in the receptacle and the drip pan is not deforming the fit.
• If the oven heats but is off by a consistent amount, check the temperature offset/calibration steps in the owner's manual.
• If you’re testing components, use safe meter practices; our how to use a multimeter to test electrical parts video helps with basic technique.

Why it matters

Heating and control issues can cause undercooked food, overheating, or repeated breaker trips. Matching the symptom to the correct component (element, sensor, switch, or control board) prevents repeat repairs and helps restore normal bake and broil performance.
