Kenmore 11070212990 gas dryer Parts

For a Kenmore dryer, replacing a heating element typically costs $20 to $120 for the part if it is an electric model, and about $150 to $350 total with professional labor. Your Kenmore 11070212990 is a gas dryer, so it usually does not use a heating element; “no heat” repairs more often involve ignition and thermostat parts.

What this means for Kenmore 11070212990 (gas dryer)

Gas dryers heat with a burner assembly, not an electric heater coil. If you were quoted for a “heating element,” confirm the tech is working on the correct appliance type.

Common no-heat parts on this model include:

• Igniter 279311 (starts the burner flame)
• Dryer gas valve coil kit 279834 (opens the gas valve during heating)
• Dryer operating thermostat WP3387134 (regulates drum temperature)
• Dryer high-limit thermostat W11050897 (safety limit if overheating occurs)
• Dryer radiant sensor WP338906 (detects burner flame)

Typical cost breakdown (part vs. service)

Prices vary by region and diagnosis, but this is the usual range for a gas dryer heat repair.

Cost item	Typical range	Notes
Diagnostic/service call	$75 to $150	Often applied toward repair if you proceed
Common gas heat part	$15 to $60	Igniter, coils, thermostat, sensor
Labor (install + test)	$100 to $250	Accessing burner area, verifying safe operation
Total (most no-heat repairs)	$150 to $350	Higher if multiple parts are replaced

How we recommend confirming the right repair

Before buying parts, we recommend these quick checks because they change the diagnosis:

• Verify the dryer tumbles and has strong airflow at the outside vent.
• Clean the lint screen and check the lint chute for blockage.
• Confirm the gas shutoff valve is fully open.
• Listen for ignition sequence (clicks, whoosh, brief flame) then shutdown.
• If the burner lights once then stops heating, coils are a common cause.

Why it matters

Pricing depends on whether you are replacing an electric heating element (electric dryer) or troubleshooting a gas burner system (gas dryer). For Kenmore 11070212990, choosing gas-heat parts first prevents wasted time and incorrect purchases.

Last updated: February 2026

On Kenmore gas dryer model 11070212990, the “check vent” indicator means the dryer is sensing restricted airflow through the exhaust system. In most cases, cleaning lint buildup and fixing a crushed, kinked, or clogged vent hose restores normal drying and helps prevent overheating.

What to check first (fast airflow fixes)

• Clean the lint screen before every load; replace a damaged or warped screen such as the screen W10874409.
• Pull the dryer out and straighten the vent hose; remove kinks and crushed sections.
• Disconnect the vent from the dryer and clear lint from the outlet and the first few feet of duct.
• Check the outside vent hood; make sure the flap opens fully and isn’t blocked by lint or debris.
• Keep the vent run as short and straight as possible; avoid unnecessary elbows.

Symptoms you may notice with a vent restriction

What you see	What it usually means	What to do
Clothes take 2+ cycles to dry	Low airflow, moisture not leaving drum	Clean vent path end-to-end
Dryer feels very hot	Heat builds up when air can’t move	Stop and clear blockage before using
Lint around door or cabinet	Lint escaping due to poor exhaust flow	Inspect vent connections and seals
“Check vent” comes on quickly	Severe restriction or blocked hood	Check outside hood and duct immediately

Why it matters

Good airflow is what carries moisture and heat out of the drum. When airflow is restricted, drying times increase, energy use goes up, and safety thermostats can trip. If your dryer runs but shuts off early or seems to overheat, a vent restriction is the first thing we address.

If the vent is clear but the light stays on

After confirming strong airflow at the outside hood, common next checks on a gas dryer include the blower system and temperature controls. A damaged blower wheel can reduce airflow; the dryer blower wheel WP694089 is a common wear item.

Last updated: February 2026

Most Kenmore 11070212990 gas dryers are full-size, 27-inch class machines. In many installations, the cabinet measures about 27 inches wide, around 38 to 43 inches tall, and about 26 to 30 inches deep (depth can increase with the door and exhaust elbow).

Typical dimensions you can plan around

Use these common ranges when measuring your laundry space for the Kenmore 11070212990:

• Width: ~27 in
• Height: ~38 to 43 in (varies by control console style and leveling legs)
• Depth: ~26 to 30 in (door closed; vent hookup can add more)
• Door swing clearance: plan extra space in front for loading
• Vent clearance: allow room behind for the duct and elbow

Quick fit check (what to measure)

Measure your space before ordering accessories or moving the dryer:

What to measure	How to measure	Why it matters
Width opening	Wall-to-wall at the narrowest point	Confirms the 27-inch class fit
Height	Floor to lowest obstruction (shelf, cabinet)	Prevents console clearance issues
Depth	Back wall to front edge of door swing	Avoids door and walkway interference
Rear clearance	Space behind dryer to wall	Prevents crushed venting

Why it matters

Correct sizing helps prevent crushed venting (long dry times), door clearance problems, and difficult installs. It also helps when planning repairs that require cabinet access, such as replacing the drum belt 341241 or checking the idler and blower area.

Related DIY help

If you are troubleshooting performance after moving or reinstalling, we recommend reviewing how to use your clothes dryer efficiently for airflow and loading tips that can affect dry time.

Last updated: February 2026
