Whirlpool WGD5700SW0 dryer Parts

Yes. For your Whirlpool dryer model WGD5700SW0, searching by the full model number is the most accurate way to get compatible replacement parts because it matches your exact configuration and pulls up the correct diagrams and part list for that dryer.

How to find the model number on this dryer

On WGD5700SW0, the model and serial label is located at the top inside the dryer door well. Confirm the full model number before ordering so you do not end up with a similar looking part that does not fit.

• Open the dryer door and look along the inside door opening
• Write down the complete model number and serial number
• Match letters and numbers exactly (including any trailing digits)
• Use the model number to locate the correct parts breakdown
• Keep the information with your paperwork for future service

Best way to search parts once you have the model number

Use the model number first, then narrow down by the symptom or the part category (belt, door switch, gas burner, thermostat, etc.). For repair and maintenance details specific to this dryer, use the WGD5700SW0 owner's manual.

What you know	What to search	What you get
Full model number	WGD5700SW0	Exact parts list and diagrams
Symptom (example)	“won’t start” or “no heat”	Likely part categories to check
Part name	“door switch” or “drum belt”	Matching options for your model

Common WGD5700SW0 parts customers look up by model

These are frequent wear items and troubleshooting-related parts for this Whirlpool gas dryer:

• Dryer drum belt 341241 (drum turns)
• Dryer door switch WP3406107 (start and door safety)
• Dryer gas valve coil kit 279834 (ignition and heat cycling)
• Dryer operating thermostat WP3387134 (temperature regulation)
• Igniter 279311 (burner ignition)

Why searching by model matters

Whirlpool dryers often have multiple versions that look similar but use different switches, thermostats, or burner components. Searching by WGD5700SW0 helps ensure the part fits, mounts correctly, and connects to the right wiring and gas burner assembly.

Last updated: February 2026

On the Whirlpool WGD5700SW0 dryer, a blown thermal fuse commonly shows up as a dryer that will not start, or a dryer that runs but has no heat. The sure way to confirm is a continuity test with a multimeter; a good fuse shows continuity, a blown fuse reads open.

Quick checks before testing

• Confirm the dryer is plugged into a grounded 3-prong outlet.
• Check the house fuse(s) or circuit breaker(s); many dryers use two.
• Make sure the door is fully closed and Start is pressed firmly.
• Verify you did not select an air or no-heat cycle.
• For gas models, confirm the gas shutoff valve is open.

How to test the thermal fuse (continuity)

1. Disconnect power to the dryer.
2. Access the fuse location using the steps and panel access guidance in the WGD5700SW0 owner’s manual.
3. Remove at least one wire from the fuse terminal.
4. Set your multimeter to continuity or ohms.
5. Test across the fuse terminals.

What the meter reading means

Meter result	What it means	What to do next
Beep or near 0 ohms	Fuse is good	Keep troubleshooting heat or start issues
No beep or OL/infinite	Fuse is blown	Replace the fuse and correct the airflow problem

Why thermal fuses blow (and why it matters)

A thermal fuse is a one-time safety device; it opens when the dryer overheats. Overheating is most often caused by restricted airflow. Your installation instructions emphasize proper outdoor venting and using a 4-inch heavy metal vent; crushed, kinked, or improper venting can trap heat and lint.

Prevent it from happening again

• Clean the lint screen every load.
• Inspect the vent run for kinks or crushing behind the dryer.
• Use 4-inch heavy metal venting (not plastic or foil).
• Avoid screws inside the duct that catch lint; use clamps to seal joints.
• Remove lint buildup from inside the exhaust vent periodically (the manual recommends about every 2 years, more often with heavy use).

Last updated: February 2026

For Whirlpool model WGD5700SW0, replacing the drive motor typically runs $200 to $600 total (parts plus labor). The motor itself is usually $90 to $300, and labor commonly adds $150 to $350, depending on access, diagnosis time, and local rates.

Typical cost breakdown

Item	Typical range	Notes
Drive motor part	$90 to $300	Motor price varies by model and supplier
Labor	$150 to $350	Often 1 to 2 hours plus service call
Total installed	$200 to $600	Higher if additional worn parts are found

What changes the price most

• Diagnosis vs. confirmed failure: a service call and testing can add cost if the motor is not the root cause.
• Extra wear parts: a worn belt, idler pulley, or drum support parts can be replaced at the same time to prevent repeat teardown.
• Vent restriction: overheating from poor airflow can shorten motor life and lead to repeat failures.
• DIY vs. pro repair: DIY saves labor but requires safe disassembly and correct reassembly.
• Warranty status: Whirlpool’s major appliance warranty is typically 1 year from purchase when operated and maintained as instructed (details in the WGD5700SW0 owner's manual).

When a motor replacement makes sense

We recommend replacing the motor when the dryer has good overall condition and the failure is clearly motor-related (hums but won’t start, trips breaker after start attempt, or won’t run even with a good door switch and belt).

Smart “while you’re in there” parts

If the cabinet is already open, these common wear items are often replaced together to reduce future downtime:

• Drive motor 279827 (the motor itself)
• Dryer drum belt 341241
• Dryer idler pulley WP691366
• Dryer repair kit 4392065 (often includes multiple wear components)

Why it matters

A dryer motor is one of the most labor-intensive repairs because it requires significant disassembly. Bundling related wear parts and correcting airflow issues helps the repair last longer and keeps drying times consistent.

Last updated: February 2026

If your Whirlpool WGD5700SW0 dryer runs but clothes stay damp, the most common fixes are restoring airflow (clean lint screen, correct a crushed or clogged vent) and confirming the dryer is actually heating (run a full-heat test and verify the gas shutoff valve is open). See the WGD5700SW0 owner's manual for cycle and care guidance.

Quick checks that solve most “not drying” problems

• Clean the lint screen before every load.
• Make sure the exhaust vent behind the dryer is not crushed or kinked.
• Check the outside vent hood for a stuck flap, lint buildup, or a blockage.
• Avoid overloading; heavy loads restrict airflow and extend dry time.
• Use an appropriate heat cycle (not an air-only cycle) for towels and jeans.

Confirm the dryer is heating (gas model)

Use this simple heat check from the installation procedure:

1. Set the dryer to a full heat cycle (not an air cycle) and start it.
2. After about 5 minutes, open the door and feel for heat.
3. If there is no heat, check that the gas supply line shutoff valve handle is parallel to the gas pipe (open position). If the valve is open and there is still no heat, service is needed.

Parts that commonly cause “runs but no heat” on gas dryers

If airflow is good and the dryer still will not heat consistently, these parts are common suspects:

Symptom	What it often points to	Example part for WGD5700SW0
Igniter glows but burner will not stay lit	Weak gas valve coils	Dryer gas valve coil kit 279834
No ignition sequence or intermittent ignition	Igniter or flame sensing issue	Igniter 279311
Overheats then stops heating until it cools	Restricted venting or thermostat safety opening	Dryer high-limit thermostat W11050897

Why it matters

Poor airflow is the number one reason a dryer “won’t dry”; it also makes cycles run longer and can cause overheating that shuts heat off. Verifying airflow and heat first prevents unnecessary part replacement.

Last updated: February 2026

For your Whirlpool WGD5700SW0 dryer, we recommend ordering parts using the complete model number and matching the part to the correct diagram; if the dryer is in-warranty, have your proof of purchase ready because Whirlpool may require it for service or parts support. Use the WGD5700SW0 owner's manual to confirm where the model and serial label is located.

Fastest way to order the right part

• Find the model and serial label (it’s typically at the top inside the dryer door well).
• Write down the complete model number: WGD5700SW0.
• Identify the failed part by symptom (no heat, won’t start, noisy, etc.).
• Match the part to the correct location in the parts diagram for your dryer.
• Order using the exact part ID and description to avoid look-alike parts.

Common WGD5700SW0 parts customers order

If you’re troubleshooting a specific symptom, these are frequent replacements for this model:

Symptom	Common part to check	Example part for this model
Drum won’t turn or squeals	Belt and idler pulley	Dryer drum belt 341241, dryer idler pulley WP691366
Dryer won’t start when door closes	Door switch	Dryer door switch WP3406107
Gas dryer won’t heat consistently	Gas valve coils	Dryer gas valve coil kit 279834

Why it matters

Ordering by the exact model number and part ID helps ensure proper fit and safe operation. It also reduces returns and repeat repairs, especially on gas dryers where correct venting and component matching are critical.

Helpful documentation to keep handy

• Use the WGD5700SW0 installation guide for venting requirements and installation rules (for example, exhausting outdoors and using a 4-inch heavy metal vent).

Last updated: February 2026

Common problems we see on Whirlpool dryers like model WGD5700SW0 include a dryer that will not start, a drum that will not tumble, no heat or weak heat (gas ignition issues), and long dry times caused by restricted venting. Many symptoms trace back to airflow, door switch, belt, or burner components.

Most common symptoms and what they usually mean

• Won’t start: door not fully closed, failed door switch, timer/control issue, or power supply problem.
• Not spinning (motor runs or hums): broken belt, worn idler pulley, seized drum support, or a failing drive motor.
• No heat on a gas dryer: weak igniter, failed gas valve coils, or a bad radiant sensor.
• Takes too long to dry: crushed/long vent run, lint buildup, blocked hood, or a damaged blower wheel.
• Overheats or shuts off: restricted venting causing high temperatures and safety thermostat trips.

Quick checks we recommend first (fast, high-impact)

• Clean the lint screen and confirm strong airflow at the outside exhaust hood.
• Use 4-inch heavy metal venting and exhaust outdoors; avoid plastic or foil vent.
• Make sure vent joints are clamped and not screwed through (screws catch lint).
• Confirm the door closes firmly and the switch clicks.
• If you are above 10,000 ft elevation, gas burner output must be reduced per the installation instructions.

Parts that commonly fix these issues on WGD5700SW0

Symptom	Common part involved	Example part for this model
Drum won’t turn	Belt or idler pulley	Dryer drum belt 341241
Won’t start when door closes	Door switch	Dryer door switch WP3406107
No heat (ignites then stops)	Gas valve coils	Dryer gas valve coil kit 279834
Long dry times, poor airflow	Blower wheel	Dryer blower wheel WP694089

Why it matters

Dryer performance and safety depend heavily on proper venting. Restricted airflow can cause long dry times, overheating, and repeated shutdowns; the installation requirements in the WGD5700SW0 installation guide help prevent those problems.

Last updated: February 2026

A Whirlpool dryer like model WGD5700SW0 typically lasts 10 to 13 years with normal household use. Regular airflow maintenance (lint removal and proper venting) and avoiding overloads are the biggest factors that keep the drum, motor, and heat system running longer.

What affects dryer lifespan the most

• Venting and airflow: Restricted exhaust makes the dryer run hotter and longer.
• Lint buildup inside the cabinet and vent: The manual recommends removing lint from inside the cabinet and exhaust vent about every 2 years (more often with heavy use). See the WGD5700SW0 owner’s manual.
• Load size and cycle choice: Overloading strains the drum belt, idler pulley, and drive motor.
• Heat system health (gas models): Weak ignition or cycling heat increases run time and wear.
• Installation quality: The installation guide calls for 4-inch heavy metal venting exhausted outdoors; poor vent materials or routing shortens life. See the WGD5700SW0 installation guide.

Typical lifespan by usage pattern

Usage pattern	Typical lifespan	What to focus on
Light (1 to 3 loads/week)	12 to 15 years	Keep vent clear; don’t overdry
Average (4 to 7 loads/week)	10 to 13 years	Clean lint path; avoid overloads
Heavy (8+ loads/week)	7 to 10 years	More frequent vent cleaning; watch wear parts

Parts that commonly limit “how long it lasts”

If the dryer still heats but gets noisy, won’t tumble, or takes longer to dry, these wear items are common on many Whirlpool dryers:

• Dryer drum belt 341241 (drum won’t turn, squealing, slipping)
• Dryer idler pulley WP691366 (squeal, thump, belt tension issues)
• Drive motor 279827 (hums, won’t start, intermittent running)
• Dryer gas valve coil kit 279834 (heats briefly then stops heating)

Why it matters

A dryer that runs with restricted airflow or worn drive parts often needs longer cycles, which increases heat stress and can lead to repeated breakdowns. Keeping venting correct and lint under control is the simplest way to extend the service life of your WGD5700SW0.

Last updated: February 2026
