Kenmore Elite 79577556600 refrigerator Parts

For Kenmore Elite refrigerator model 79577556600, the exact exterior dimensions and total capacity are listed in the product specifications section of the owner's manual. This model is a bottom-freezer style (often described as bottom-mount), so it typically fits a 33-inch-wide refrigerator opening.

Where to find the exact size for model 79577556600

We use the model-specific specs in the manual to confirm the correct measurements for your exact color code and configuration.

• Check the “Refrigerator installation” and specifications sections
• Look for overall dimensions (width, depth, height)
• Confirm whether depth is listed with handles and without handles
• Confirm whether height is listed to top of hinge
• Use the model number format shown in the manual (795.77xx series) to match your unit

Typical size ranges for this Kenmore 795 bottom-freezer platform

If you are planning cabinetry or delivery clearance, most Kenmore 795 bottom-freezer refrigerators fall into these common ranges (final numbers vary by exact version):

Measurement	Typical range
Width	32 3/4 to 33 inches
Height	67 to 70 inches
Depth	30 to 35 inches

Why it matters

Using the correct width, depth, and height helps prevent delivery issues, ensures proper door swing clearance, and supports correct airflow around the cabinet (which affects cooling performance and compressor run time).

Parts that commonly relate to fit and clearance

If you are adjusting doors, leveling, or fixing alignment issues that affect how the refrigerator “fits,” these parts are commonly involved:

• Refrigerator door hinge AEH73856207 (door alignment and swing)
• Refrigerator door stop 4620JJ2009A (limits door travel)
• Refrigerator grille MDX63113401 (base area clearance and airflow)

You can also look up additional parts by model number on Sears PartsDirect.

Last updated: February 2026

Common problems we see with the Kenmore Elite 79577556600 bottom-mount refrigerator include warm temperatures from airflow or defrost issues, frost buildup from door sealing or defrost failures, unusual fan or compressor noise, and water leaks from a clogged defrost drain. Use the troubleshooting section in the 79577556600 owner's manual to match symptoms to checks.

Most common symptoms and what they usually point to

• Not cooling or weak cooling: dirty condenser coils, evaporator fan issues, defrost system problems, or sealed system trouble
• Frost or ice buildup: door not closing fully, frequent door openings, or a defrost heater/sensor problem
• Loud buzzing, rattling, or grinding: condenser fan, evaporator fan, or compressor start components
• Water under the refrigerator or in the freezer: clogged/iced defrost drain, cracked drain tube, or water line connection leak
• Ice tastes bad or smells: old ice, unwrapped food odors, or water quality issues (a filter can help)

Quick checks we recommend before replacing parts

1. Confirm settings: refrigerator about 37°F and freezer about 0°F.
2. Make sure doors close tightly; reduce warm, humid air entering the freezer.
3. Clean condenser coils and verify the condenser fan runs when the compressor runs.
4. Look for frost packed on the freezer back wall (often a defrost or airflow clue).
5. Check for a clogged drain by inspecting for ice or water at the freezer floor.

Parts that commonly relate to these problems (for this model)

Symptom	Common area	Example part on this model page
Frost buildup, warm fridge	Defrost system	Refrigerator defrost sensor assembly 6615JB2005H, lg refrigerator defrost heater 5300JK1005D
Water leaking/puddles	Drain system	Refrigerator drain tube 5251JA3003D
No water to dispenser/ice maker	Water supply	Lg refrigerator water inlet valve 5221JB2006K, refrigerator water tubing MJU62070602
Door light issues, door ajar symptoms	Door switch	Lg refrigerator door switch 6600JB1010A

Why it matters

Cooling, frost, and leak symptoms are often connected. For example, a defrost problem can create ice on the evaporator coils, restrict airflow, and make the fresh food section warm. A clogged drain can turn normal defrost water into a leak.

You can order replacement parts for model 79577556600 from the parts list for this refrigerator, or search by model number on Sears PartsDirect.

Last updated: February 2026

Ice on the freezer floor is almost always caused by a defrost drain that is clogged or partially frozen; defrost water can’t flow to the drain pan, so it refreezes at the bottom. For Kenmore Elite model 79577556600, clearing the drain path and restoring airflow typically stops the ice buildup (see the 79577556600 owner's manual).

What to check first (fast, no-parts steps)

• Unplug the refrigerator or switch off power at the breaker before working inside the freezer.
• Remove the freezer drawer/bins and look for a sheet of ice on the floor.
• Find the drain opening under the evaporator cover area (rear panel) and check for ice or debris.
• Melt the ice with warm water (not boiling) and a towel; keep water away from vents.
• Flush the drain with hot water; a small amount of baking soda dissolved in hot water helps break up residue.
• Confirm the door closes tightly and vents are not blocked by food packages.

Why the drain clogs and creates a “freezer floor” ice sheet

When the refrigerator goes into defrost, water should run through the drain tube to the defrost pan where it evaporates. If the drain is blocked, water backs up and freezes on the freezer bottom.

Common causes

Cause	What you’ll notice	Typical fix
Drain hole iced over	Ice returns within days	Fully thaw and flush drain
Food particles/sludge in drain	Slow draining, musty odor	Flush until clear
Door not sealing or opened often	Frost plus ice buildup	Improve sealing habits, reduce humidity
Air vents blocked	Uneven temps, frost patterns	Repack to keep vents clear

Parts that can help if the problem keeps coming back

If you’ve cleared the drain and ice still returns, the drain tube itself can be restricted or damaged. Replacing the drain tube is a common, permanent fix.

• Consider replacing the refrigerator drain tube 5251JA3003D if it’s brittle, kinked, or won’t flush clear.

Why it matters

A clogged drain can lead to recurring ice sheets, water leaks, and poor airflow that makes the freezer work harder. Keeping the drain clear helps maintain stable temperatures and reduces frost.

If you need to order replacement parts for model 79577556600, use the parts list for this model or search by model number on Sears PartsDirect.

Last updated: February 2026

Most Kenmore Elite refrigerators, including model 79577556600, typically last 10 to 15 years with normal household use. Regular maintenance (cleaning coils, keeping door seals tight, and fixing small cooling or water issues early) helps you reach the high end of that range; see the owner's manual for care guidance.

Typical lifespan and what to expect

In our experience, the refrigerator’s lifespan is usually limited by a few high-wear systems: cooling airflow, defrost performance, and water/ice components.

• Average lifespan: 10 to 15 years
• Common “mid-life” repairs (often 5 to 10 years): fans, sensors, water valves, door switches
• Later-life repairs (often 10+ years): sealed system or compressor-related issues

Quick reference table

Item	Typical impact on lifespan	What you can do
Condenser coil cleanliness	High	Vacuum/brush dust regularly
Door gasket seal	High	Keep seals clean, confirm doors close fully
Defrost system health	Medium to high	Address frost buildup quickly
Water/ice system	Medium	Replace filters on schedule, fix leaks early

Maintenance that extends life (high value steps)

• Clean the condenser area and keep airflow clear around the cabinet
• Keep temperatures steady (about 37°F fresh food, 0°F freezer)
• Confirm doors close easily and do not “pop” back open
• Replace clogged filters and correct slow water flow before it strains the system
• Fix frost buildup early to prevent fan damage and warm temperatures

Why it matters

A refrigerator that runs with restricted airflow, poor door sealing, or recurring frost works harder and longer each day. That extra runtime increases wear on components like the evaporator fan, defrost heater, sensors, and compressor.

Parts that commonly come up in lifespan-related repairs

If you are troubleshooting symptoms (warm temps, frost, leaks, or dispenser issues), these model-compatible parts are often involved:

• Refrigerator defrost sensor assembly 6615JB2005H (defrost control feedback)
• Refrigerator temperature sensor 6500JB2001B (temperature regulation)
• Lg refrigerator door switch 6600JB1010A (light and door status)
• Lg refrigerator water inlet valve 5221JB2006K (ice maker and dispenser water supply)

Last updated: February 2026

On Kenmore Elite model 79577556600, dH (often shown as Er dH) indicates a defrost heating problem. The refrigerator is not sensing normal temperature rise during the defrost cycle, so cooling can be affected and frost can build up.

What to check first (quick, safe steps)

• Power reset: unplug the refrigerator (or switch off the breaker) for 5 minutes, then restore power.
• Confirm doors fully close and gaskets seal; warm air leaks can worsen frost and trigger defrost-related errors.
• Look for heavy frost on the freezer back wall; that points to a defrost system issue.
• Make sure vents are not blocked by food packages.
• If the display is unresponsive during the error, restore power first, then recheck.

Parts commonly involved in a dH / Er dH condition

A dH error is usually tied to the defrost circuit: heater, sensor, wiring, or control logic. For this model, these parts are commonly relevant:

• Refrigerator defrost sensor assembly 6615JB2005H
• Lg refrigerator defrost heater 5300JK1005D
• Refrigerator temperature sensor 6500JB2001B

Basic symptom guide

What you notice	What it usually means	What to do next
Frost blanket on freezer panel	Defrost heat not happening	Check heater and sensor connections; test components
Fridge warm, freezer cold	Airflow blocked by frost	Defrost system diagnosis; clear ice buildup
Intermittent error, temps swing	Sensor reading drifting	Inspect/replace sensor; verify wiring

Why it matters

When defrost heat is not working correctly, ice can build up on the evaporator and restrict airflow. That makes the refrigerator section warm, forces longer run times, and can lead to fan noise or poor ice production.

Where to find model-specific guidance

Your control settings, troubleshooting steps, and component locations for model 79577556600 are covered in the 79577556600 owner's manual. For display codes and what they mean on similar Kenmore 795 bottom-freezer models, we also use the Kenmore 795 model bottom freezer refrigerator error codes guide.

If you need to order parts, use the parts list for model 79577556600 on this page, or search by model number on Sears PartsDirect.

Last updated: February 2026
