Kenmore 11076662500 dryer Parts

Your Kenmore dryer “series” is identified by the model number prefix on the model/serial label. For Kenmore model 11076662500, the 110 prefix is the key series identifier, and you’ll find the full model number on the label at the top inside the dryer door well (door opening area). See the 11076662500 owner's manual for the exact label location and how to record it.

Where to find the model number (fastest method)

Look for the model/serial label in these common spots on Kenmore dryers:

• Top inside the dryer door well (most common on 110-series)
• Inside the door opening on the cabinet frame
• On the back panel (less common)
• On the side panel near the door opening

How to read the “series” from the model number

For Kenmore dryers, the first 3 digits typically indicate the series or source platform.

What you see	What it usually means	Example
First 3 digits (prefix)	Kenmore series identifier	110 = 110-series
Full model number	Exact configuration for parts and manuals	11076662500
Serial number	Production identifier (not used for “series”)	Varies

Why the series matters

The series helps narrow down the correct parts diagrams, troubleshooting steps, and compatible replacement parts. For example, if your 11076662500 dryer stops tumbling, the drum belt is a common wear item; matching by model avoids ordering the wrong belt length or style (see dryer drum belt 341241 if you’re diagnosing a no-tumble issue).

Tips to avoid mix-ups when ordering parts

• Copy the full model number exactly: 11076662500
• Use the model number, not the marketing name (like “Elite”)
• If the label is worn, check the door well with a flashlight and take a photo
• Match parts by model first, then confirm symptoms (heat, tumble, noise)

Last updated: February 2026

Kenmore “500 series” is a series name, not a single capacity. For your Kenmore dryer model 11076662500, the installation guide shows a 27-inch class cabinet (about 27 inches wide), which typically falls in the 6.5 to 7.0 cu. ft. range for full-size dryers; check the exact capacity in the 11076662500 owner's manual.

How to get the exact capacity for your dryer

We recommend confirming capacity by model-specific documentation or the rating label.

• Look in the specifications section of the 11076662500 owner's manual
• Check the model/serial rating plate in the door opening (door well)
• If you see multiple “series” labels in ads, rely on the model number (11076662500) for accuracy
• Use cabinet width as a quick clue: 27-inch class dryers are usually full-size

What “500 series” usually means (and why it varies)

Retailers often group dryers into “series” based on features (cycles, controls, finishes), not drum volume. Capacity can differ within the same series depending on the exact model and platform.

Label you see	What it identifies	What it does not guarantee
“Kenmore 500 series”	Feature family/lineup	A single fixed cu. ft. capacity
Model number 11076662500	Your exact dryer build	N/A
27-inch class width	Physical size class	Exact drum volume

Why it matters

Choosing venting, installation space, and load size expectations is easier when you know whether you have a compact, 27-inch class, or 29-inch class dryer. Your 11076662500 dimensions in the installation guide confirm it is in the full-size category, so it is built for larger loads than compact units.

Last updated: February 2026

To hard reset your Kenmore dryer model 11076662500, we recommend disconnecting power for a few minutes, then restoring power and restarting a cycle. This clears many temporary control and start-up issues and is the safest first step before testing parts or disassembling the dryer; see the 11076662500 owner's manual.

Hard reset steps (safe, no tools)

• Turn the cycle selector to OFF.
• Unplug the dryer (or switch both dryer breakers OFF if it is hardwired).
• Wait 3 to 5 minutes.
• Restore power.
• Close the door firmly.
• Select a Timed Dry cycle and press PUSH TO START.

If the dryer still will not start after a reset

The manual’s basic “won’t run” checks are the fastest next steps.

• Confirm the power cord is fully plugged in.
• Check the home electrical supply; many dryers use 2 breakers or 2 fuses, and one can trip/blow.
• Make sure the door is fully closed; a failed door switch can prevent starting.
• Try a different cycle setting, then press PUSH TO START again.
• If the motor hums but the drum will not turn, inspect the belt and idler system.

Quick symptom-to-part guide

What you notice	Most common cause	Example part for this model
No start when door is closed	Door switch not closing	Dryer door switch WP3406107
Motor runs but drum does not tumble	Broken/slipped belt	Dryer drum belt 341241
Button pressed, nothing happens intermittently	Start switch issue	Dryer push-to-start switch WP3977456

Why it matters

A hard reset rules out a temporary control “glitch” and helps you avoid replacing good parts. If the dryer still will not run, the next most productive path is verifying power, door closure, and the start circuit, then checking common wear items like the belt.

Last updated: February 2026
