Kenmore Elite 11087731700 dryer Parts

Kenmore model 11087731700 does not encode an exact manufacture year in the model number itself; the year is determined from the serial number on the dryer’s ID tag. Use the serial number format and location shown in the 11087731700 owner's manual to identify the production date.

Where to find the information you need

Look for the model and serial tag on the dryer cabinet (commonly inside the door opening or on the door frame area). Once you have the serial number, you can decode the date.

• Locate the model and serial tag on the dryer
• Write down the full serial number exactly as shown
• Note any letters at the start of the serial number (they often matter)
• Compare the serial format to the identification info in the manual
• If the tag is worn, take a clear photo and zoom in to confirm characters

How year decoding typically works (Kenmore 110 / Whirlpool-built dryers)

For many Kenmore 110-series dryers, the serial number (not the model number) contains a date code. The exact positions vary by serial format, so we use the manual and the tag to avoid guessing.

What you have	What it tells you	What to do next
Model number (11087731700)	Series and configuration	Use it to match parts and documentation
Serial number	Production date (year and week/month)	Decode using the tag format
Purchase date	When it was bought	Use as a cross-check only

Why it matters

Knowing the correct production year helps us match the right Kenmore Elite dryer parts (like a heating circuit component or drum support parts) and avoid ordering a look-alike part that does not fit your exact build.

Last updated: February 2026

For Kenmore Elite dryer model 11087731700, the most common display codes include PF (power failure), F service codes (such as F1, F2, F20), plus diagnostic codes like L2 (power supply issue affecting heat) and AF (restricted or crushed vent). Use the 11087731700 owner's manual to match the code to the exact fix.

Common codes and what they mean

• PF: Power failure interrupted the cycle; press and hold START to restart.
• F1 / F2 / F20: Service codes tied to control or heater relay issues; schedule service.
• L2: The drum may turn but the heater may not; home power supply problem is preventing heat.
• AF: Airflow restriction; vent is crushed, blocked, or too long.

What to do first (fast checks)

1. Clear PF: Press and hold START.
2. For L2:

• Check for a tripped breaker or blown fuse (electric dryers use two fuses/breakers).
• Confirm the power cord is installed correctly.
• Run a Timed Dry heated cycle (not Air Only) and recheck.

3. For AF:

• Check the vent run behind the dryer for crushing or kinks.
• Clean lint from the duct and the exterior vent hood.
• Verify the vent length and number of elbows meet the manual’s guidance.

Quick reference table

Code	Category	What it points to	What we do next
PF	Interruption	Power loss during cycle	Restart cycle; check outlet power
F1/F2/F20	Service	Control or heater relay related	Arrange service/diagnosis
L2	Diagnostic	Supply issue preventing heat	Check both breakers/fuses; cord; retest
AF	Diagnostic	Vent restriction	Inspect, clean, shorten venting if needed

Why it matters

These codes protect the dryer from unsafe heating and poor drying performance. L2 and AF are especially important because they directly affect heat and airflow, which drive dry times and energy use.

For additional code lists and explanations, use Kenmore elite dryer error codes.

Last updated: February 2026

On the Kenmore Elite dryer model 11087731700, a blown thermal fuse commonly stops the dryer from running at all; on some failures, the drum may still turn but the heater will not energize. Use the checks in the 11087731700 owner's manual to confirm the symptom before replacing parts.

What you will usually see when the thermal fuse blows

• Dryer will not start (no motor run)
• Dryer starts and tumbles but produces no heat
• Cycle ends early because the dryer cannot maintain temperature
• A burning smell or repeated overheating happened before the failure

Quick checks we recommend first (before replacing parts)

1. Reset the home power: electric dryers often use two fuses or breakers; one can trip and leave the drum turning with no heat.
2. Confirm the door is latching: if the door is not fully closed, the dryer may not run.
3. Run a Timed Dry heated cycle (not Air Only) to separate a heat problem from an auto-sensing issue.
4. Inspect airflow: a crushed or blocked vent can overheat the dryer and contribute to thermal fuse failure.

Thermal fuse vs. other common “no heat” causes

Symptom	More likely cause	What to check
Tumbles, no heat	House fuse/breaker issue or heater circuit problem	Verify both breakers/fuses, then test heater circuit
No run at all	Thermal fuse, door switch, or start circuit	Check for power, door latch, then test safety devices
Overheats, shuts down	Restricted venting	Clean lint screen, ducting, and outside vent hood

Parts that are often involved in heat and overheating complaints

If testing shows a heater circuit issue, these model-compatible parts are commonly replaced during repair:

• Dryer heating element WP8544771 (heat source)
• Dryer high-limit thermostat WP8557403 (overheat safety)
• Dryer thermistor WP8577274 (temperature sensing)

Why it matters

A thermal fuse is a one-time safety device; if it blows and you only replace the fuse without fixing the airflow or overheating cause, the new fuse can blow again quickly.

Last updated: February 2026

On the Kenmore Elite dryer model 11087731700, the model number is printed on the model and serial number label attached to the dryer cabinet; you’ll typically see it when you open the door and look around the door opening and frame. Confirm the exact label location in the 11087731700 owner's manual.

Where to look first (fast checklist)

• Open the dryer door and inspect the cabinet frame around the door opening.
• Check the upper inside edge of the front panel (near the lint screen housing on many Elite models).
• Look along the left and right inner door jamb areas.
• Inspect the inside face of the door (less common, but possible).
• Use a flashlight; the label print can be small or slightly faded.

What the label includes (and why you need it)

The label normally lists the model number and serial number. We use the model number to match the correct Kenmore parts (like a heating element, thermistor, or drum support roller) and to pull the right diagrams and troubleshooting steps.

Why it matters

Using the exact model number prevents ordering a look-alike part that does not fit your dryer’s heater housing, drum support system, or wiring connections.

Quick reference: model vs. serial

Item	What it tells us	When it’s used
Model number	The exact dryer design and parts fit	Ordering parts, diagrams, manuals
Serial number	Production run details	Warranty and service history

If you’re already inside the cabinet

If you’re servicing the dryer and need a common wear item, these parts are frequently replaced on this model family:

• Support WPW10314173 (drum support roller)
• Dryer idler pulley 279640 (belt tension pulley)
• Dryer heating element WP8544771 (electric heat source)

Last updated: February 2026
