Kenmore 11173035910 bottom-mount refrigerator Parts

To tell what model Kenmore refrigerator you have, look for the model and serial number on the appliance identification label. For Kenmore bottom-mount refrigerators like model 11173035910, the label is typically inside the fresh food (refrigerator) compartment on the interior liner; confirm the exact location in the 11173035910 owner's manual.

Where to look for the model number label

Check these common spots first (in this order):

• Inside the refrigerator compartment on a side wall (interior liner)
• Near the crisper drawers (often on the wall behind or beside them)
• On the ceiling of the fresh food compartment near the light housing
• Inside the freezer compartment side wall (less common on bottom-mount units)
• Behind the lower front kick plate or grille (some designs)

What you should write down (and why)

We recommend recording both numbers exactly as shown on the label:

• Model number (used to match parts and diagrams)
• Serial number (used to identify production run details)
• Date of purchase (helpful for warranty and service history)

Quick reference table

Item	What it’s used for	Example format
Model number	Finding correct parts and manuals	11173035910
Serial number	Identifying the unit’s build series	Letters and numbers
Date of purchase	Service and warranty records	Month/day/year

Why it matters

Kenmore model families can look similar, but parts like the water filter, door bins, control board, and icemaker components can vary by model and serial range. Using the exact model number prevents ordering the wrong refrigerator parts.

Related help if you’re troubleshooting

If you’re trying to identify the model because the display is showing a code, use our Kenmore 111 model bottom freezer refrigerator error codes guide to match the code to likely causes and next steps.

Last updated: February 2026

Common Kenmore Elite refrigerator problems include warm temperatures (often from frequent door openings, hot-room installation, or airflow issues), ice maker and water dispensing problems (commonly a restricted water supply line or an exhausted water filter), and door sealing or leveling issues. For Kenmore model 11173035910, use the troubleshooting steps in the 11173035910 owner’s manual to match symptoms to fixes.

Most common symptoms we see (and what to check first)

• Refrigerator or freezer too warm: allow up to 24 hours after installation for temps to stabilize; reduce long door openings.
• Unit in a hot location: do not operate above 110°F ambient temperature.
• Food freezing in fresh-food section: keep high-water foods away from air vents; adjust the temperature one step at a time.
• Ice maker not making enough ice: confirm freezer is set to 0°F; make sure doors close fully.
• Slow water dispensing: replace the water filter about every 6 months or when the indicator turns on.

Quick troubleshooting checklist (model 11173035910)

1. Confirm settings: freezer at 0°F, refrigerator at your normal setting.
2. Check door closure: dirty or sticky gaskets can prevent a good seal; clean and recheck.
3. Look for airflow blockage: avoid packing items tight against vents.
4. Inspect the water line: a kinked supply tube can reduce flow to the ice maker and dispenser.
5. Give it time after changes: temperature adjustments and loading changes take hours to stabilize.

Symptom-to-cause guide

Symptom	Most likely cause	Best first action
Fresh food too warm	Doors opened often, hot food added, hot room	Reduce door openings; cool food before loading
Food freezing	Items near vent, control set too cold, cold room	Move items; adjust temp one increment
Low ice production	Freezer too warm, doors not closed, kinked line	Set 0°F; fix closure; straighten tubing
Slow water	Exhausted filter	Replace filter; flush water line

Why it matters

Cooling, ice, and water issues usually trace back to temperature stability, airflow, and water flow. Fixing those basics first prevents unnecessary part replacements and helps the compressor and fans run normally.

Related DIY help

• Use Kenmore 111 model bottom freezer refrigerator error codes if your display shows an error.
• Follow how to replace the water filter in a Kenmore refrigerator to restore water flow and ice production.

Last updated: February 2026

Water under your Kenmore 11173035910 bottom-mount refrigerator usually comes from a clogged defrost drain, a mispositioned or overflowing drain pan, or a water supply connection issue (if the ice maker is on). We use the troubleshooting steps in the 11173035910 owner's manual to narrow it down fast.

Quick checks that solve most leaks

• Look for ice or water on the freezer floor: this points to a defrost drain that is frozen or clogged.
• Check the drain pan underneath: make sure it is seated correctly and not cracked.
• Inspect the water line connection (if connected): loose fittings can drip and run under the cabinet.
• Confirm the refrigerator is level: an unlevel cabinet can cause water to miss the drain pan.
• Check door gaskets: warm air leaks can create excess frost that later melts into a puddle.

What to do based on where the water is

Where you see water	Most likely cause	What to do next
Under the front center	Drain pan overflow or cabinet not level	Re-seat pan; level the unit
Under left or right rear	Water line or inlet valve seepage	Tighten fittings; inspect tubing
Inside freezer bottom, then leaking out	Clogged or frozen defrost drain	Thaw and clear the drain path

Model-specific notes for 11173035910

• If your refrigerator is connected to a cold water supply for the ice maker, the manual calls out that plumbing issues like water hammer can contribute to leaks; correcting that protects the water line and fittings.
• The manual also specifies typical supply water pressure of 30 to 125 psi; pressure problems can worsen dripping at connections.
• Use the leveling-leg procedure in the manual to keep condensate and defrost water flowing where it should.

Why it matters

A small leak can turn into floor damage, ice buildup in the freezer, and poor cooling if airflow gets blocked by frost. Fixing the drain or water line early keeps the evaporator area and drain pan working normally.

Related help: how to get rid of refrigerator puddles

Last updated: February 2026

If your Kenmore 11173035910 is warm at the bottom, cold air is usually not circulating correctly from the evaporator area into the fresh food section. We fix this by restoring airflow (unblocked vents, good door seal) and confirming the temperature settings and operating conditions listed in the 11173035910 owner's manual.

Quick checks that solve most “warm at the bottom” complaints

• Wait after installation or a power outage: the manual notes it can take up to 24 hours for compartments to reach the set temperature.
• Reduce door openings: frequent or long openings let warm, humid air in and raise temperatures.
• Check for blocked air vents: keep packages and bins from covering return vents and supply vents.
• Do not load hot food: let food cool to room temperature before storing.
• Confirm room temperature: the manual advises not operating the refrigerator above 110°F.

Airflow and loading tips (bottom area focus)

Cold air often enters higher in the refrigerator and returns lower; when the return path is blocked, the bottom can stay warm.

What you see	Most likely cause	What we do first
Bottom shelves warm, top OK	Return vent blocked by food/bins	Clear space around vents; reorganize items
Warm after grocery load	Too much warm food added	Allow several hours; avoid overpacking
Temps swing with use	Doors opened often	Shorten openings; verify doors close fully
Warm in hot kitchen/garage	Ambient too hot	Move to cooler location or improve ventilation

Why it matters

Poor circulation makes the compressor run longer, can cause uneven food temperatures, and increases moisture that leads to frost and odors. Restoring airflow protects food quality and helps the cooling system maintain stable temperatures.

When to go deeper

If airflow is clear and conditions are normal but the bottom stays warm for more than 24 hours, the issue is typically in the cooling system airflow path (evaporator fan, frost buildup, or damper control). Use the troubleshooting steps in the 11173035910 owner's manual, and if your display shows a fault, reference the Kenmore 111 model bottom freezer refrigerator error codes guide.

Last updated: February 2026
