Kenmore 11066722694 electric dryer Parts

Your Kenmore dryer’s model number is printed on the model and serial number plate; on model 11066722694, it’s typically found in the door opening area. Once you have the full model number, we can match the correct parts, wiring, and operating specs for your exact dryer.

Where to look for the model number plate

Check these common locations on Kenmore electric dryers:

• Inside the dryer door opening (on the cabinet frame)
• On the back panel of the dryer
• Around the lint screen housing area (depending on design)
• On a metal plate or durable sticker labeled “Model” and “Serial”

For the exact location and how it’s labeled, use the 11066722694 owner's manual.

How to read the number (and why it matters)

Kenmore model numbers are long on purpose; each section helps identify the platform and the correct replacement parts.

What you see	What it tells us	Why you need it
Full model number (example: 11066722694)	Exact dryer configuration	Ensures parts fit and wiring matches
Serial number	Production run details	Helps confirm compatible revisions
“110” prefix (common on many Kenmore units)	Platform family identifier	Narrows down diagrams and parts lists

Tips to avoid ordering the wrong parts

Before you shop for items like a heating element, door switch, or drum belt, we recommend:

• Write the model number exactly as shown (all digits, no spaces)
• Record the serial number too (helpful for service and compatibility)
• Compare the model number on the plate to any paperwork you have
• Use the model number when selecting parts such as the drum belt 341241 or dryer element 279838

Why it matters

Kenmore dryers often look similar across multiple series, but internal parts (like the heating circuit, thermostat style, or belt routing) can differ. Using the correct model number keeps repairs accurate and prevents repeat breakdowns.

Last updated: February 2026

To open the control panel on a Kenmore electric dryer model 11066722694, we typically unplug the dryer first, then remove the console mounting screws and lift the console up and back to access the timer and wiring. Use the steps and screw locations shown in the 11066722694 owner's manual.

Before you start (safety and prep)

• Unplug the dryer (or switch off the breaker) before removing any panels.
• Pull the dryer forward enough to work comfortably without crushing the vent.
• Keep a small container for screws so none get lost.
• Take a quick photo of wire connections before disconnecting anything.
• Wear cut-resistant gloves; console edges can be sharp.

Typical steps to open the console

On most Kenmore 29-inch electric dryers like model 11066722694, the console is held by screws at the back or inside the end caps.

1. Disconnect power.
2. Remove console mounting screws. Look for screws along the back edge of the console (often 1/4-inch hex-head).
3. Lift the console. Lift up from the back, slide it slightly, then lift it off or hinge it up (depending on console style).
4. Support the console. Rest it so it does not hang by the wiring.
5. Access components. You can now reach items like the timer and start switch area.

What you can access once it’s open

Area in console	What you’ll see	Common reason to open it
Timer/control area	Timer body and wiring	Knob issues, timer not advancing
Start switch area	Push-to-start switch wiring	Dryer will not start
Harness connections	Wire terminals/connectors	Loose connection, intermittent operation

Why it matters

Opening the control panel is often the first step for diagnosing a no-start condition (for example, checking the push-to-start circuit and door switch wiring) and for safely routing wires back exactly as designed.

Last updated: February 2026

The average lifespan of the Kenmore 11066722694 electric dryer is 13 years with normal use and routine maintenance. Keeping airflow strong (lint screen and venting) and addressing wear items early helps this model reach its full service life.

What affects lifespan the most

• Vent restriction and lint buildup; overheating shortens heater and thermostat life
• Load size and cycle choices; frequent heavy loads increase drum and motor wear
• Preventive cleaning; lint inside the cabinet should be removed periodically by a qualified service person
• Wear parts condition; belt, idler pulley, and drum support parts wear over time
• Electrical health; loose or damaged wiring can cause intermittent heating or shutdowns

Maintenance schedule we recommend

The owner's manual for model 11066722694 includes vent-cleaning guidance and safety notes about lint accumulation.

Task	Frequency	Why it matters
Clean lint screen	Every load	Improves airflow and drying time
Check and clean exhaust vent to the hood	Every 6 to 12 months	Reduces overheating and long dry times
Remove accumulated lint inside dryer cabinet (qualified service person)	Every 2 to 3 years	Lint can be fuel for a fire; also improves airflow
Inspect drum support and drive system for noise/slip	As symptoms appear	Prevents secondary damage

Parts that commonly wear before the dryer is “done”

Replacing normal-wear parts can restore performance and extend life.

• Drum belt 341241 if the drum will not turn or you hear squealing
• Dryer idler pulley WP691366 if the belt slips, squeals, or the drum binds
• Dryer blower wheel WP694089 if airflow is weak or you hear rattling/humming
• Dryer operating thermostat WP3387134 if temperatures are inconsistent
• Dryer element 279838 if the dryer runs but does not heat

Why it matters

Most “end of life” dryer complaints are really airflow, heating, or drive-wear issues. On the 11066722694, keeping the vent clear and replacing a belt, idler, or heater component as needed is often the difference between a short lifespan and a full 13-year run.

Last updated: March 2026
