Kenmore Elite 79681473210 dryer Parts

A Kenmore dryer like model 79681473210 typically lasts 10 to 13 years. With consistent lint and vent cleaning, correct load sizes, and quick repairs when noises or heat problems start, many dryers reach 15 years or more before major component replacement becomes common.

What affects dryer lifespan the most

• Airflow and venting: restricted venting overheats the heater and thermostats
• Lint control: clogged lint paths strain the blower and raise temperatures
• Load habits: chronic overloading wears the drum belt, rollers, and idler pulley faster
• Heat management: repeated overheating shortens the life of thermostats and the heating element
• Moisture sensing: dirty sensor bars can cause long run times and extra wear

Maintenance checklist (best return for the effort)

Use the steps in the 79681473210 owner’s manual as your baseline, then keep this routine:

• Clean the lint screen every load
• Vacuum lint from the lint screen housing area monthly (as accessible)
• Inspect and clean the vent duct at least every 6 to 12 months
• Avoid overfilling; leave room for clothes to tumble freely
• Stop using the dryer if you hear squealing, thumping, or grinding and address it early

Common “wear parts” that often decide whether a dryer feels worn out

Symptom	Likely wear area	Example part for 79681473210
Drum not turning, motor runs	Belt or idler system	Dryer drum belt 4400EL2001F
Thumping or rumbling	Drum support rollers	Dryer drum support roller (roller set)
Squealing	Idler pulley or rollers	Dryer idler pulley
Long dry times, overheating	Lint path or venting; thermostats	Dryer high-limit thermostat

Why it matters

A dryer usually does not “die” all at once; it becomes inefficient first (longer dry times, hotter cabinet, louder operation). Keeping airflow strong and replacing wear items early helps protect higher-cost parts like the motor and heating system.

Last updated: February 2026

To hard reset your Kenmore Elite dryer model 79681473210, we recommend disconnecting power for 1 to 5 minutes, then restoring power and starting a normal cycle. This clears many temporary control glitches and can remove a stuck control lock or an unresponsive keypad; use the 79681473210 owner's manual for the exact control panel steps.

Hard reset steps (safe and effective)

• Turn the dryer OFF.
• Unplug the power cord (or switch the breaker OFF).
• Wait 1 to 5 minutes.
• Restore power.
• Press Power, select a cycle, and press Start.
• If the panel is still unresponsive, toggle Control Lock/Child Lock (if enabled) and try again.

If the dryer still will not run after a reset

A reset only clears the control; it does not fix a failed safety device or switch. Check these common causes next:

• Door not fully closed or a failed door switch (the dryer will not start if it thinks the door is open)
• Restricted airflow from lint buildup (can trigger overheating protection)
• Moisture sensor bars dirty (auto cycles may end early or act erratic); see dryer moisture sensor 6500EL3001A
• Overheating protection opening due to heat issues; inspect the dryer high-limit thermostat 6931EL3003D
• Drive system problems (motor runs but drum does not turn); inspect the dryer drum belt 4400EL2001F and idler pulley

Quick symptom guide

What you see	What it usually means	What to do next
Display works, Start does nothing	Door switch or control lock	Confirm door closes firmly; disable control lock; check door switch wiring
Runs but no heat	Heating circuit or airflow issue	Clean venting; check thermostats and heating element
Stops early on sensor cycles	Moisture sensor issue	Clean sensor bars; check sensor and harness
Loud thumping/squeal	Roller, idler, or belt issue	Inspect rollers, idler pulley, and belt condition

Why it matters

Resetting is a fast first step because it clears false error states in the electronic control. If the same symptom returns right away, the dryer is usually reacting to a real input (door switch, moisture sensor, or overheating protection) rather than a one-time glitch.

For code-related issues, match the exact code and symptom using Kenmore elite dryer error codes.

Last updated: February 2026

On the Kenmore Elite dryer model 79681473210, the model number is typically printed on a rating label inside the door opening. Open the dryer door and check the cabinet frame around the opening first; that is the most common location.

Most common label locations to check

• Inside the door opening on the top cabinet frame
• Inside the door opening on the left or right cabinet frame
• On the back panel of the dryer cabinet
• Along the door’s inner edge (less common)
• Behind the lower access panel (some designs)

What the label looks like

The model/serial label is usually a white or silver sticker or metal plate. It often includes:

• Model number (for example, 79681473210)
• Serial number
• Electrical ratings (volts/amps)
• Sometimes a barcode

Quick checklist so you find it faster

1. Open the door and run your hand along the cabinet frame (top, left, right).
2. Use a flashlight and look for a sticker that may be partially worn or covered by lint.
3. If you do not see it, check the back of the dryer cabinet next.

Where you look	How to access it	Why it’s there
Door opening frame	Open door	Easy to read during service
Back panel	Pull dryer forward	Common alternate placement
Lower front area	Remove access panel (if equipped)	Protected from wear

Why it matters

We use the exact model number to match Kenmore-compatible parts and diagrams, so you get the right items the first time (for example, a belt, idler pulley, or heating component).

For label examples and model identification tips, use the 79681473210 owner’s manual.

Last updated: February 2026

Yes. Kenmore Elite is Kenmore’s higher-end line, and the Kenmore Elite dryer model 79681473210 is positioned above standard Kenmore models with more premium design and feature sets. For the most accurate feature list and cycle options for your exact unit, use the 79681473210 owner's manual.

What “high end” means for Kenmore Elite dryers

Kenmore Elite typically focuses on upgrades that affect convenience, performance, and fit and finish, such as:

• More cycle and temperature selections (including specialty fabric cycles)
• Larger capacity designs common in premium laundry pairs
• More advanced dryness control (sensor-dry style operation)
• Quieter operation features (better airflow design, insulation, or drum support)
• More refined styling and control layouts

Quick comparison: Kenmore vs Kenmore Elite (typical)

Category	Standard Kenmore	Kenmore Elite
Cycles and options	Basic to mid-range	Expanded, more specialty cycles
Dryness control	Timed and some sensor	Sensor-focused, more control
Fit and finish	Practical	More premium look and feel
Repair parts cost	Often lower	Often higher for some assemblies

Why it matters when buying parts or troubleshooting

“Elite” models often use different sensors and control strategies than entry models, so matching parts to the exact model number matters. For example, if you are diagnosing heat or drying performance, components like the dryer thermistor AGM30045804 can play a key role in temperature sensing and cycle behavior.

How we recommend confirming what your model includes

• Check the feature and cycle descriptions in the 79681473210 owner's manual
• Compare your control panel labels to the manual’s cycle chart
• Use the full model number 79681473210 when ordering replacement parts
• If you see an error code, reference a Kenmore Elite-specific guide such as Kenmore elite dryer error codes

Last updated: February 2026

Kenmore Elite dryer error codes are fault messages that help us pinpoint what the dryer thinks is wrong (power, control board, keypad, heater relay, or temperature sensing). For Kenmore Elite model 79681473210, start by matching the exact code on the display to the list in the 79681473210 owner's manual.

Common Kenmore Elite dryer codes (examples)

These are some of the most common codes customers see on Kenmore Elite dryers:

• PF: Power failure during a cycle (outlet, breaker, cord, or a brief outage)
• F:01: Main electronic control board problem
• F:02: Keypad or user interface problem
• F:20: Heater relay problem
• F:22 / F:23: Outlet thermistor (temperature sensor) problem
• F:24 / F:25: Inlet thermistor (temperature sensor) problem

What to do first (safe, quick checks)

Before replacing parts, we recommend these steps:

• Unplug the dryer (or switch off the breaker) for 2 to 5 minutes, then restore power and recheck the code.
• If you see PF, verify the outlet is solid, the cord is tight, and the breaker is not tripping.
• Clean the lint screen and confirm strong airflow at the outside vent.
• Avoid overloading; heavy loads can trigger heat and airflow related faults.
• If the code returns immediately, troubleshoot that specific circuit (control, heater, or sensor).

Code-to-system quick guide

Code family	What it usually points to	What we check next
PF	Power interruption	Outlet, breaker, cord, house power stability
F:01 / F:02	Controls and user interface	Loose connections, control board, console/keypad
F:20	Heating control	Heater relay circuit, wiring, heating system
F:22 to F:25	Temperature sensing	Thermistor, wiring, airflow restrictions

Why it matters

Using the correct error code list for 79681473210 prevents unnecessary part replacement and speeds up repair. Heat and thermistor codes are often caused by restricted venting, while F:01 and F:02 more often involve the control or console.

For a model-specific list and any reset steps, use the Kenmore elite dryer error codes reference alongside the 79681473210 owner's manual.

Last updated: February 2026

The model number for this Kenmore Elite dryer is 79681473210. You’ll use 79681473210 to look up the correct Kenmore parts (like a drum belt, thermistor, or heating element) and to match the right troubleshooting and maintenance instructions in the 79681473210 owner’s manual.

Where to find the model number on the dryer

On most Kenmore dryers, the model/serial tag is typically located in one of these spots:

• Inside the door opening on the cabinet frame
• On the back panel of the dryer
• Along the side of the door opening (near the lint screen area)
• Behind the control panel area (less common)

Why the exact model number matters

Kenmore model families can look similar, but parts and wiring can differ by revision. Using 79681473210 helps us match the correct fit and function for common repairs.

What you’re doing	Why the model number matters	Example for this model
Ordering replacement parts	Prevents wrong fit or wrong electrical rating	Dryer drum belt 4400EL2001F
Following service steps	Ensures correct disassembly order and safety steps	79681473210 owner’s manual
Diagnosing display issues	Points you to the right error code list	Kenmore elite dryer error codes

Quick tips before ordering parts

• Copy the model number exactly: 79681473210
• If your tag also lists a serial number, keep it handy for production-date variations
• Match the part by description and ID, not just a similar-looking photo

Why it matters

A single digit difference in a Kenmore Elite model number can change the correct drum belt, thermostat, or sensor. Starting with 79681473210 saves time and avoids returns.

Last updated: February 2026
