Kenmore 11072602101 gas dryer Parts

Replacing a heating element in a Kenmore dryer typically costs $150 to $350 total (part plus labor). For your Kenmore 11072602101 gas dryer, “no heat” problems are usually caused by gas-heat components (igniter, coils, sensor) rather than an electric heating element; confirm the heat system in the 11072602101 owner's manual.

Typical cost breakdown (part vs. labor)

Most service calls include a diagnostic fee plus labor; parts vary by dryer type.

• Service call/diagnostic: $75 to $150
• Labor (element replacement): $75 to $200
• Heating element part (electric dryers): $30 to $150
• Total typical: $150 to $350
• Same-visit extras (common): vent cleaning, thermostat or fuse replacement

Dryer type	What actually makes heat	Most common “heat” part cost	Typical total with labor
Electric dryer	Heating element	$30 to $150	$150 to $350
Gas dryer (like 11072602101)	Burner/ignition system	$25 to $120	$200 to $450

For model 11072602101: what to check before pricing an “element”

Because the 11072602101 is a gas dryer, price the repair around the burner and safety controls.

• If the drum tumbles but there is no heat, start with the ignition system
• If heat starts then stops, suspect gas valve coils
• If the dryer overheats or shuts down, check thermostats and airflow
• If you smell gas or suspect a gas leak, stop using the dryer and have a technician check it

Helpful model-matched parts often used in “no heat” repairs:

• Dryer gas valve coil kit 279834
• Whirlpool dryer burner igniter kit 279311
• Dryer radiant sensor WP338906
• Dryer operating thermostat WP3387134

Why it matters

Pricing the correct component saves time and repeat service calls. Gas dryers do not use an electric heating element, so matching the symptom to the burner system (and verifying venting and settings) gets you to the right repair faster.

Last updated: February 2026

Your Kenmore dryer’s model number is printed on the model and serial number label; on Kenmore model 11072602101, that label is located at the top inside the dryer door well. Write down the full model number and serial number so you can match the correct parts and instructions in the 11072602101 owner's manual.

Where to find the model number label

Look in these common spots first (starting with the one confirmed for this model):

• Top inside the dryer door well (open the door and look along the upper edge inside the opening)
• On the door frame near the latch area
• Behind the lower front access panel (some designs)
• On the rear panel (less common for day-to-day reference)

How to record it correctly (so parts match)

When you find the label, copy the information exactly as shown:

• Model number (example format in the manual: 110.XXXXXXXX)
• Serial number
• Purchase date (helpful for service history)

Quick check table

What you’re looking for	What it’s used for	Why it matters
Model number	Identifies the exact dryer design	Ensures diagrams and parts lists match your dryer
Serial number	Identifies production run details	Helps confirm correct revisions and compatible parts
Purchase date	Ownership record	Useful for maintenance planning

Why it matters

Kenmore dryers can look similar across multiple model numbers, but parts like the dryer drum belt, operating thermostat, or push-to-start switch can vary by design. Using the exact model number helps us point you to the right replacement parts and the correct procedures.

Last updated: February 2026

The average lifespan of the Kenmore gas dryer model 11072602101 is 13 years. Regular vent cleaning, correct installation, and replacing wear items like the drum belt and rollers on time are the biggest factors in reaching (or exceeding) that service life.

What affects lifespan the most

• Airflow and venting: A crushed or kinked vent makes the dryer run hotter and longer.
• Heat system health: Weak ignition or cycling problems increase run time and stress components.
• Drum support wear: Worn rollers, idler pulley, or belt can strain the motor.
• Leveling and setup: A dryer that is not level can increase vibration and wear.
• Routine care: Lint removal reduces overheating and improves drying performance.

Quick maintenance checklist (high impact)

• Clean the lint screen every load; clean the lint chute periodically.
• Inspect and clean the exhaust duct to the outside.
• Confirm the dryer is level and the vent is not kinked (setup steps are in the installation guide).
• If you notice squealing, thumping, or slipping, service the drum support system.
• If heat is inconsistent, troubleshoot the gas ignition system.

Common wear parts to expect over time

These are the parts we most often see replaced as a dryer ages:

Symptom	Common cause	Example part for this model
Drum not turning, burning rubber smell	Worn or broken belt	Dryer drum belt 341241
Squealing or thumping	Worn rollers/idler components	Dryer repair kit 4392065
No heat or heat cuts in and out	Ignition or gas valve coil issue	Dryer gas valve coil kit 279834

Why it matters

A 13-year lifespan assumes normal household use and safe airflow. Poor venting can shorten life and also causes longer dry times and overheating, which accelerates failures in thermostats, the motor, and the burner system.

Last updated: March 2026
