Kenmore 11067751600 dryer Parts

A blown thermal fuse in your Kenmore dryer model 11067751600 usually shows up as a dryer that will not run at all (no motor) even though the door is closed and the Start button is pressed. The most reliable way to confirm is a continuity test with a multimeter.

Before testing parts, we verify the basics listed in the troubleshooting steps in the 11067751600 owner’s manual:

• The dryer door is firmly closed
• The Start button is pressed firmly
• A cycle is selected (not sitting in an Off position)
• Power is connected; the dryer is plugged in
• Household fuses are intact or the circuit breaker has not tripped (electric dryers often use two fuses/breakers)

1. Disconnect power (unplug the dryer or shut off the breaker).
2. Access the thermal fuse (commonly on the blower housing or exhaust duct area, depending on configuration).
3. Pull one wire off the fuse terminal (so you do not read through the circuit).
4. Set your multimeter to continuity (or the lowest ohms setting).
5. Touch a probe to each terminal.

• Good fuse: continuity (beep or near 0 ohms)
• Blown fuse: no continuity (no beep, OL, or very high resistance)

A thermal fuse usually opens because the dryer overheated from restricted airflow. We correct airflow issues before running the dryer again.

• Clean the lint screen and lint screen housing
• Inspect and clear the vent duct to the outside
• Check for crushed, kinked, or overly long venting
• Confirm the outside vent hood opens freely
• If drying is slow or heat seems weak/erratic, inspect the blower area; a damaged wheel like the dryer blower wheel WP697772 can reduce airflow

The thermal fuse is a safety device; if it is open, the dryer may not run. Replacing the fuse without fixing a blocked vent often leads to repeat failures and longer dry times.

Last updated: February 2026

Yes, a Kenmore dryer like model 11067751600 is usually worth repairing when the cabinet and drum are solid and the problem is a common wear item (heat, drum support, belt drive, or door switch). If you are facing repeated major failures, replacement is typically the better value.

We look at the type of failure, how often it has happened, and whether the fix is a normal maintenance repair.

• Repair is a good choice when the dryer:
  • Still tumbles smoothly and the drum is in good shape
  • Has a single clear symptom (no heat, squeal, won’t start)
  • Has not needed multiple repairs in the last year
  • Has good airflow after vent cleaning (short dry times)
  • Only needs common parts like a thermostat, roller, or heating element
• Replace is a better choice when the dryer:
  • Has frequent breakdowns or multiple symptoms at once
  • Has severe rust, a damaged drum, or a failing motor plus other issues
  • Still dries poorly after the venting and lint path are cleaned

These are typical repairs that often restore performance without replacing the dryer.

A dryer that is maintained and repaired with the right parts can run for years; the manual also calls out routine care like cleaning the lint screen every load and keeping the exhaust area clear, which directly affects drying time and component life. Use the 11067751600 owner’s manual for model-specific care and troubleshooting steps.

• Clean the lint screen and confirm strong airflow at the outside vent
• Check for a crushed, kinked, or overly long vent run
• Match the symptom to one likely failure (heat, start, noise) before ordering
• Follow the safety guidance in the manual (unplug power before servicing)

Last updated: February 2026

On Kenmore dryer model 11067751600, the model and serial label (where you’ll find the identifying numbers you need for parts) is located at the top inside the dryer door well. Use that label information when ordering replacement parts or looking up diagrams in the 11067751600 owner's manual.

The label typically includes several identifiers; for parts ordering, these are the most useful:

• Model number (for this dryer: 11067751600)
• Serial number (unique to your specific dryer)
• Purchase date (often recorded in the manual, not always on the label)
• Sometimes a type or electrical rating line (helpful for service)

1. Open the dryer door.
2. Look around the door opening (door well) near the top edge.
3. Find the sticker or metal tag with printed numbers.
4. Write down the full model number and serial number exactly as shown.

Use this as a quick reference when you’re searching for Kenmore dryer parts:

Using the exact label information prevents ordering the wrong component. Kenmore dryers can share similar looks across series, but internal parts (like a heating element, timer, or door switch) can differ by model and production run.

If you’re chasing a specific replacement, matching by model number helps you land on the correct listing, such as the support WPW10314173 used in the drum support system.
