To hard reset a Kenmore Elite dryer model 11086742701, unplug the dryer (or switch off the breaker) for 1 minute, restore power, then press and hold START to resume. If you need to clear the current cycle and settings, press STOP twice as shown in the 11086742701 owner's manual.

Quick reset options (what to use and when)

• Power reset (best for glitches): Unplug for 1 minute, then plug back in.
• Cycle clear (best for wrong settings): Press STOP twice to end the cycle and clear selections.
• Restart after interruption (PF code): Press and hold START to restart the cycle.
• Control lock toggle (if buttons do not respond): Press and hold CYCLE SIGNAL for 3 seconds to lock or unlock.

Step-by-step: hard reset (power reset)

1. Turn the dryer OFF.
2. Unplug the power cord (or turn OFF the dryer breaker).
3. Wait 60 seconds.
4. Restore power.
5. Select a cycle, then press and hold START for about 3 seconds (large loads may need a longer press).

If it still will not run after a reset

Use this quick check list before replacing parts:

• Confirm the door is fully closed and the latch engages.
• Check household power: electric dryers typically need two breakers/fuses; one tripped breaker can let the drum run with no heat.
• If you see L2, check the home power supply and reset the breaker.
• If you see AF, inspect the vent run for crushing, lint buildup, or a blocked exterior hood.

Symptom after reset	Most common cause	What to do next
Dryer runs but no heat	One breaker/fuse tripped	Reset both breakers; verify cord/terminal connection
AF code	Restricted venting	Clean venting and exterior hood
Buttons unresponsive	Control lock enabled	Hold CYCLE SIGNAL 3 seconds

Why it matters

A proper reset clears stuck control logic and cancels an incorrect cycle selection. If the issue is power supply (L2) or airflow restriction (AF), resetting alone will not fix drying performance until the underlying condition is corrected.

Last updated: January 2026

Common problems we see with the Kenmore Elite dryer model 11086742701 include a dryer that will not start, long dry times from restricted airflow, overheating, and a drum that will not turn. Many issues trace back to power supply, door latching, lint buildup, or worn drive components; use the 11086742701 owner's manual to match symptoms to checks.

Most common symptoms and what they usually mean

• Won’t start or won’t run: power supply issue, door not fully latched, Start button not pressed firmly, or a tripped breaker.
• Takes too long to dry: lint screen clogged, vent crushed or blocked, weak airflow at the outside hood.
• Overheats or load feels too hot: restricted venting, lint buildup, or a temperature-sensing problem.
• Drum not turning or stopped spinning: worn belt path parts (idler, rollers) or a motor issue.
• Error codes or beeping: power interruption or a diagnostic/service code.

Quick checks we recommend first (safe, no tools)

• Clean the lint screen before every load.
• Run the dryer 5 to 10 minutes and check for strong airflow at the outside exhaust hood.
• Confirm the door closes firmly; if it does not latch, the control can beep and the cycle will not start.
• For electric dryers, verify a 240-volt supply and check that both household fuses/breakers are OK.
• If the display shows L2, focus on the home power supply because the drum can turn while the heater will not.

Common parts involved (when symptoms point to wear or failure)

Symptom	Often involved part	Example part for this model
Squealing, thumping, drum drag	Drum support rollers, idler system	Support WPW10314173
Drum won’t turn, belt feels loose	Idler pulley	Dryer idler pulley 279640
No heat or poor heat control	Heating circuit or temperature sensing	Dryer thermistor WP8577274

Why it matters

Airflow and power issues are the two biggest causes of “no heat,” long dry times, and overheating. Keeping the vent clear and confirming the correct electrical supply prevents repeat failures and helps protect key parts like the heating element and thermostats.

Last updated: January 2026

A Kenmore dryer typically lasts 13 years with normal household use and basic maintenance. For your Kenmore Elite 11086742701 dryer, consistent lint removal, good airflow, and timely replacement of wear parts (belt, rollers, idler) are what most directly extend service life.

Typical life expectancy (what to expect)

Most full-size Kenmore electric or gas dryers fall into a similar lifespan range; the difference is usually maintenance and venting, not the brand badge.

• Typical lifespan: 13 years
• Common “life extenders”: clean lint screen every load, keep venting clear, avoid overloading
• Common “life shorteners”: restricted exhaust vent, heavy overloading, running with squealing/thumping parts

Maintenance that most affects lifespan

Your manual calls out periodic lint removal inside the cabinet and exhaust system; that maintenance helps prevent overheating and reduces strain on the motor and heater. See the 11086742701 owner's manual for the dryer care schedule and cleaning guidance.

• Clean the lint screen before or after every load
• Keep the exhaust duct run short and unobstructed
• Remove lint buildup from the exhaust venting on a regular schedule
• Have accumulated lint removed from inside the cabinet about every 2 years (more often with heavy use)
• Address new noises early (squeal, rumble, thump) to prevent secondary damage

Wear parts that commonly determine “end of life”

Many dryers reach 13 years but start needing more frequent repairs. If the drum support system is worn, a refresh can restore quiet, efficient operation.

Symptom	Most common wear area	Example part for this model
Squealing or chirping	Idler pulley or rollers	Dryer idler pulley 279640
Thumping or rumbling	Drum support rollers	Support WPW10314173
Multiple noises or long service history	Roller, idler, belt refresh	Dryer repair kit 4392067

Why it matters

A dryer that is vent-restricted or running with worn drum support parts often runs hotter and longer to dry clothes. That extra heat and run time increases stress on the heating system, motor, and controls, which shortens overall life.

Last updated: January 2026

The exact drum capacity (cubic feet) for Kenmore Elite dryer model 11086742701 is listed in the product specifications section of the 11086742701 owner's manual. If you are comparing dryers, most full-size Kenmore 110-series dryers are typically in the 6.5 to 7.5 cu. ft. range.

How to find the cubic feet in your manual

We recommend using the manual’s specs section because it’s the only place that ties capacity to your exact model configuration.

• Open the 11086742701 owner's manual
• Go to the specifications or dimensions area
• Look for terms like capacity, drum volume, or cu. ft.
• If you see multiple model numbers listed together, match 110.86742 style listings to your exact model 11086742701

Quick reference: what the manual does show

Your manual excerpt includes cabinet dimensions (useful for fit and installation), even when capacity is not on the same page.

Spec type	What you can confirm from the manual excerpt	Why it helps
Width	27 in.	Confirms full-size footprint
Depth	31.5 in. (cabinet)	Helps plan closet or laundry room space
Height	39 in. (cabinet)	Helps confirm stacking or clearance needs

Why cubic feet matters

Capacity affects how well the dryer handles bulky loads (comforters, towels) and how evenly clothes tumble. A drum that is too full restricts airflow, which can increase dry time and heat stress on parts like the heating system.

Related parts that affect drying performance

If drying seems slow (often mistaken for “too small capacity”), these common airflow and heat parts are worth checking on model 11086742701:

• Lint screen condition and fit (see screen W10120998)
• Heating performance (see dryer heating element WP8544771)
• Temperature sensing (see dryer thermistor WP8577274)
• Blower airflow (see dryer blower wheel WP697772)
