Whirlpool ED5LVAXWQ00 refrigerator Parts

The Whirlpool ED5LVAXWQ00 is a full-size side-by-side refrigerator with a typical capacity of about 25 cubic feet. For the exact cabinet dimensions (height, width, depth) and clearance requirements for your specific unit, use the specs section in the ED5LVAXWQ00 owner's manual.

When customers ask how big a refrigerator is, it usually refers to one or both of these:

• Capacity (cu. ft.): how much food it holds
• Overall dimensions: height, width, depth (often different with handles)
• Clearances: space needed for airflow and door swing
• Door style: side-by-side doors need room to open fully

Most Whirlpool side-by-side refrigerators in the ~25 cu. ft. class fall into these common ranges (your ED5LVAXWQ00 can vary by trim and handle style):

We recommend measuring your actual refrigerator and comparing it to the installation specs:

• Measure width at the widest point (often the hinge side)
• Measure height from floor to top of hinge cover
• Measure depth from back to front (note: handles add depth)
• Confirm door swing clearance so drawers and bins can open
• Check for airflow clearance behind and above the cabinet

Correct size prevents common fit problems like doors hitting walls, the unit sticking out past cabinets, or restricted airflow that can cause warm temperatures and longer compressor run times.

Last updated: January 2026

Whirlpool model ED5LVAXWQ00 is a full-size side-by-side refrigerator; most units in this class are about 25 cubic feet total capacity. For the exact, model-specific capacity rating and configuration details, we recommend confirming it in the ED5LVAXWQ00 owner's manual.

Capacity is typically listed on the specification page in the manual, and sometimes on the model and serial tag inside the fresh food compartment.

• Check the specs section in the ED5LVAXWQ00 owner's manual
• Look for the model and serial label on the inside wall of the refrigerator compartment
• If you have the original sales paperwork, capacity is often listed there
• If shelves or bins have been changed, remember that storage layout can affect usable space (not the rated capacity)

If you are comparing models or planning kitchen storage, these are common ranges for side-by-side designs.

Capacity affects grocery planning, shelf and bin fit, and cooling performance expectations. Knowing the rated cubic feet also helps when ordering replacement storage parts like a crisper pan or meat pan.

If you are refreshing water and ice performance while you are checking specs, the correct filter for this model is the refrigerator water filter EDR3RXD1.

Last updated: January 2026

On the Whirlpool ED5LVAXWQ00 side-by-side refrigerator, the defrost timer (or defrost control, depending on the exact configuration) is typically located in the control housing area at the top of the fresh food compartment or behind a small access panel in the temperature control section. Use the ED5LVAXWQ00 owner's manual to confirm the exact access point for your unit.

Before removing panels, unplug the refrigerator to prevent shock and to protect the electronic controls.

• Look inside the fresh food section near the temperature controls (upper interior area).
• Check for a small control box or cover that holds the cold control and defrost components.
• If you see a small module secured to a mounting plate, it may be held by two screws.
• If your refrigerator uses an adaptive defrost control instead of a mechanical timer, the defrost “timer” function is handled by a control board.

Some Whirlpool side-by-side designs use a mechanical timer; others use an electronic adaptive defrost control.

If you determine your ED5LVAXWQ00 uses an adaptive defrost control, the matching part is the refrigerator adaptive defrost control board WPW10366605.

A failed defrost control can cause frost buildup on the evaporator, weak airflow, and warm temperatures. You may also hear normal defrost-cycle sounds such as sizzling or water running as meltwater drains during defrost.

• Confirm the freezer is cold but airflow into the refrigerator is weak (possible frost restriction).
• Listen for the evaporator fan running; poor airflow can mimic defrost problems.
• Make sure door gaskets seal well; warm air leaks increase frost.
• If you have a water/ice system issue at the same time, keep it separate from defrost diagnosis (different circuits and components).

Last updated: January 2026
