Kenmore Elite 79571329410 refrigerator

Kenmore Elite 79571329410 refrigerator Parts

Here are the diagrams and repair parts for Kenmore Elite 79571329410 refrigerator, as well as links to manuals and error code tables, if available.

By Schematic
By Part
SELECT DIAGRAM
?

This is the number corresponding to the part on the diagram / schematic

Browse Parts for 79571329410 Refrigerators

Kenmore Elite Refrigerator 79571329410 FAQs

Most Kenmore Elite refrigerators, including model 79571329410, typically last 10 to 15 years with normal household use. Regular maintenance and quick repairs of cooling or water system issues can help you reach the high end of that range.

What affects lifespan the most
  • Condenser coil cleanliness (dust buildup makes the compressor work harder)
  • Door seal condition (warm air leaks increase run time and frost)
  • Ice maker and water system health (leaks and clogs can create secondary damage)
  • Airflow inside the cabinet (overpacking blocks vents and stresses cooling)
  • Room conditions (hot garages and tight enclosures shorten component life)
Maintenance that helps you get closer to 15 years

Use the 79571329410 owner's manual for the exact care and cleaning guidance for your refrigerator.

  • Vacuum or brush condenser areas on a regular schedule
  • Keep door gaskets clean and check for gaps or tearing
  • Replace the water filter on schedule to protect water flow and taste
  • Keep freezer drawers closing fully and rails moving smoothly
  • Set stable temperatures and avoid frequent, large adjustments
Quick “what to do” guide
Symptom Most common cause Good first step
Warm fridge or freezer Airflow issue, dirty coils, fan problem Clean coils; listen for fan operation
Clicking, then no cooling Compressor start device issue Check the start components and wiring
Slow water flow or bad taste Clogged filter Replace the filter
No ice Ice maker or water supply issue Confirm water supply; inspect ice maker
Why it matters

A refrigerator’s most expensive wear items are in the sealed cooling system and airflow system. Simple upkeep (coils, seals, filter changes) reduces run time and heat load, which helps protect the compressor and fans.

If you are maintaining the water system, the genuine Kenmore refrigerator water filter 9690 AGF80300801 is the model-matched filter option listed for 79571329410.

Last updated: January 2026

To raise a Kenmore Elite refrigerator model 79571329410 off the floor, we level it by turning the front leveling legs down to lift the cabinet, then fine-tune the rear (if equipped) so the refrigerator sits stable and the doors close on their own.

Safe way to raise and level the refrigerator
  • Unplug the refrigerator or switch off power at the breaker.
  • Remove the toe grille or lower cover (if your model has one) to access the leveling legs.
  • Use a wrench or pliers to turn the front leveling legs clockwise to raise the front.
  • Raise the front just enough so the cabinet is not rocking and the doors align.
  • If the rear height is adjustable on your unit, adjust the rear leveling mechanism per the 79571329410 owner's manual.
  • Recheck door swing: the doors should close smoothly without slamming.
Quick checks after you lift it

Use these checks to confirm the refrigerator is properly supported and not stressing the cabinet:

  • The refrigerator does not rock when you push on the corners.
  • Doors are even at the top and the center mullion lines up.
  • Door gaskets seal all the way around (no gaps).
  • The freezer drawer opens and closes without rubbing.
  • The unit has a slight backward tilt so doors self-close.
Common adjustments and what they change
Adjustment What it does When to use it
Front leveling legs Raises or lowers the front Door won’t close, cabinet rocks
Rear leveling (if equipped) Balances rear height Unit leans, uneven floor
Shims under rollers/feet Adds lift where legs cannot Very uneven tile or grout lines
Why it matters

Proper leveling prevents door seal leaks, reduces vibration noise, and helps the compressor run efficiently. A refrigerator that sits unevenly can also cause ice maker and dispenser issues over time.

Last updated: January 2026

Common problems on the Kenmore Elite 79571329410 bottom-mount refrigerator include warm temperatures (airflow or sealed-system issues), ice maker or water dispenser trouble (filter or supply problems), frost buildup (defrost or door sealing issues), and unusual noises (fan or compressor-related). Use the 79571329410 owner's manual to match symptoms to the correct checks.

Most common symptoms and what usually causes them
  • Not cooling or weak cooling: dirty condenser coils, blocked vents, evaporator fan not running, or a temperature sensor issue
  • Ice maker not making ice: clogged filter, low water pressure, frozen fill tube, or ice maker failure
  • Water dispenser slow or not dispensing: restricted filter, air in the line after a filter change, or supply valve issues
  • Frost or ice buildup: door not sealing, frequent door openings, or a defrost system problem
  • Buzzing, clicking, or rattling: evaporator fan noise, compressor start/overload issues, or items vibrating inside
Quick checks we recommend before replacing parts
  1. Set temperatures to typical targets: 37°F fresh food and 0°F freezer.
  2. Make sure vents are not blocked by food packages.
  3. Clean condenser coils and confirm the condenser fan (if equipped) runs when the compressor runs.
  4. If water or ice is weak, replace the filter and purge air by dispensing several cups of water.
  5. Listen for where noise comes from: freezer (evaporator fan area) vs. back/bottom (compressor area).
Parts that commonly solve these issues (when symptoms match)
Symptom Common part involved Example for this model
Slow water, bad taste/odor, ice issues Water filter Genuine Kenmore refrigerator water filter 9690 AGF80300801
Warm temps, loud freezer noise Evaporator fan motor Lg refrigerator evaporator fan motor 4681JB1027C
No ice production Ice maker assembly Lg refrigerator ice maker assembly model AEQ72909603 AEQ72909603
Clicking at compressor, intermittent cooling Overload protector Refrigerator compressor overload protector 6750CL0001D
Why it matters

Catching airflow and water-supply problems early helps prevent food spoilage, reduces frost buildup, and can keep the compressor from running excessively (which increases wear and energy use).

For model-specific troubleshooting steps and any diagnostic modes, use Kenmore 795 model bottom freezer refrigerator error codes.

Last updated: January 2026

Yes. Kenmore Elite is Kenmore’s premium line, positioned above standard Kenmore models; for the Kenmore Elite refrigerator model 79571329410, that typically means upgraded design, higher feature sets (like filtration and ice features), and stronger overall fit and finish than entry-level refrigerators.

What “high end” means for Kenmore Elite refrigerators

Kenmore Elite is generally considered “high end” within the Kenmore brand because it focuses on premium convenience and performance features that many shoppers want without stepping into true luxury, built-in pricing.

Common Kenmore Elite upgrades include:

  • More precise temperature control and better food preservation features
  • Enhanced ice and water dispensing features (model-dependent)
  • Higher-capacity storage layouts and more adjustable shelving
  • Quieter operation compared with basic models
  • More premium exterior styling and interior lighting
How to judge if your specific Elite model is “high end”

For model 79571329410, the best way to confirm the exact feature set is to compare what your refrigerator has to what’s typical in standard lines.

Use this quick checklist:

  • Does it have a built-in water filtration system?
  • Does it have an in-door ice maker or upgraded ice production?
  • Does it have electronic controls and multiple temperature zones?
  • Does it have premium bins, drawers, and door storage?
  • Does it run quietly with steady temperatures?
What you compare Standard Kenmore Kenmore Elite
Feature set Basic to mid-range Mid-range to premium
Fit and finish Good Better materials, more refinement
Parts cost Lower Often higher for premium components
Why it matters

“High end” usually means more convenience and better performance, but it can also mean higher-cost components when you replace parts like a water filter or ice maker.

Helpful references for this model:

Last updated: January 2026
