How to find the exact model of dryer on a dryer?
To find the exact model of your Kenmore dryer, look for the model and serial number plate on the dryer cabinet and copy the full model number exactly as shown (for this unit, it should read 11063102101). The 11063102101 owner's manual explains where to find this plate.
Where to look on the dryer
On Kenmore dryers like model 11063102101, the model and serial number plate is typically on the cabinet opening area where the door closes, or on the door frame. Once you find it, record both numbers for parts lookup and service.
- Open the dryer door and inspect the door opening (cabinet front) edges
- Check the door frame area near the latch side
- Look for a label or metal plate that says “Model No.” and “Serial No.”
- Write the model number exactly, including all digits
- Record the serial number too (it helps confirm production details)
How to use the model number (and why the manual matters)
We use the complete model number to match the correct parts diagrams and compatible replacement parts for your exact configuration. The manual also recommends keeping a record of the model and serial numbers for future reference.
Quick checklist
| What to capture | Example for this dryer | Why it matters |
|---|---|---|
| Model number | 11063102101 | Ensures correct parts fit |
| Serial number | (from the plate) | Helps identify version/production run |
| Purchase date | (your records) | Useful for maintenance history |
Why it matters
Even small model-number differences can change key components like the drive belt, heating circuit, or controls. Using the full model number helps avoid ordering the wrong item and speeds up troubleshooting.
Last updated: February 2026
How do I know if my Kenmore dryer thermal fuse is blown?
On Kenmore dryer model 11063102101, a blown thermal fuse typically shows up as a dryer that will not run at all (no motor) even though the door is closed and the controls are set. The sure way to confirm is a continuity test with a multimeter using the steps in the 11063102101 owner’s manual.
Quick symptoms to look for
A blown thermal fuse often matches one or more of these symptoms:
- Dryer will not start when you press Start.
- You have power at the outlet, but the dryer stays completely dead.
- The door switch feels normal, but the motor never runs.
- The problem started after long dry times or poor airflow (lint buildup).
How to test the thermal fuse (continuity)
- Unplug the dryer (or switch off the breaker).
- Access the thermal fuse (location varies by design; follow the disassembly steps in the 11063102101 owner’s manual).
- Pull one wire off the fuse terminal.
- Set your multimeter to continuity (or the lowest ohms setting).
- Touch a probe to each terminal.
- Good fuse: continuity (beep or near 0 ohms)
- Blown fuse: no continuity (no beep or OL/infinite)
What to check next (so it does not blow again)
A thermal fuse usually opens because the dryer overheated from restricted airflow. Check these items before running the dryer again:
- Clean the lint screen and confirm strong airflow at the outside vent hood.
- Inspect the vent for crushing, kinks, or heavy lint buildup.
- Check the blower area for lint and a loose or damaged wheel.
- If heat problems continue, test the cycling thermostat and high-limit thermostat.
| Test result | What it means | What to do |
|---|---|---|
| Continuity present | Fuse is good | Keep troubleshooting start circuit and door switch; follow the manual’s “Dryer will not run” checks |
| No continuity | Fuse is blown | Replace the fuse and correct airflow restriction before using the dryer |
Why it matters
The thermal fuse is a safety device; if it is blown, the dryer is protecting itself from overheating. Restoring proper venting helps prevent repeat failures and improves drying performance.
Last updated: February 2026
How much does it cost to replace a heating element in a Kenmore dryer?
For Kenmore dryer model 11063102101, the typical cost to replace a heating element is about $150 to $350 total (part plus labor). If you do the repair yourself, the part cost is usually about $50 to $120, depending on the exact element used.
What makes up the total cost?
Replacement cost usually comes down to the heating element price, service call/labor, and whether any heat-related safety parts also need replacement.
- Heating element part: commonly $50 to $120
- Labor: commonly 30 to 90 minutes
- Service call/diagnostic: often added if you hire a technician
- Related parts (sometimes needed): thermal cut-off, high-limit thermostat, wiring terminals
| Scenario | What you pay for | Typical total |
|---|---|---|
| DIY replacement | Part only | $50 to $120 |
| Technician replacement | Part + labor + possible service call | $150 to $350 |
| Heat failure with overheating damage | Element + thermal safety parts | $200 to $450 |
Before you buy a heating element
On this style of electric dryer, “no heat” is not always a bad element. Our 11063102101 manual recommends checking power supply first; many electric dryers use two fuses or breakers, and if one trips the dryer can run but not heat. Use the 11063102101 owner's manual to follow the model-specific checks.
- Confirm the dryer is on a heat cycle (not Air Fluff)
- Check both house fuses/breakers for the dryer
- After 5 minutes of running, open the door and feel for heat
- Inspect venting for restrictions (poor airflow can overheat and blow safety devices)
- If the dryer overheated, consider replacing the thermal cut-off kit along with the element
Parts that are commonly replaced with the element
If the element failed due to overheating or a loose connection, replacing only the element can lead to repeat failures.
- Dryer element 279838 (the heater itself)
- Dryer thermal cut-off fuse kit 279816 (opens if the heater housing overheats)
- Dryer high-limit thermostat (often paired with thermal cut-off service)
- Heating element wire terminals (if burnt or loose)
Why it matters
A dryer that tumbles but does not heat is often a power supply or thermal safety issue, not just the heater. Checking breakers and airflow first helps you avoid buying the wrong part and helps prevent repeat overheating.
Last updated: February 2026
How can you tell the age of a Kenmore dryer?
To tell the age of your Kenmore dryer model 11063102101, use the serial number from the model and serial number plate; the serial number format is what contains the manufacturing date code. The model number identifies the dryer series and configuration. Confirm the plate location in the 11063102101 owner's manual.
Where to find the serial number on model 11063102101
The serial number is printed on the model and serial number plate (also called the model/serial plate). The manual notes you will need the complete model and serial numbers when requesting information.
Check these common locations:
- Open the dryer door; look around the door opening on the cabinet frame
- Inside the door area (edge or inner panel)
- Rear panel of the dryer cabinet
- Behind the lower access panel (on some designs)
How to use the serial number to get the manufacture date
Once you have the serial number, decode it using the date-code format for the manufacturer tied to that serial tag.
Use this process:
- Write down the full serial number exactly as shown (letters and numbers)
- Take a clear photo of the plate for parts ordering and service calls
- Look for a month/year or week/year pattern in the code
- If you have the original receipt, compare it to the date of purchase you recorded
Model number vs. serial number (what each tells you)
| Identifier | What it tells you | Best use |
|---|---|---|
| Model number (11063102101) | Series and configuration | Parts lookup and diagrams |
| Serial number | Manufacturing date code | Determining the dryer’s age |
Why it matters
Knowing the dryer’s age helps us match the correct replacement parts, plan maintenance, and decide whether a repair like a belt, thermostat, or heating element replacement makes sense.
