Kenmore Elite 79048123801 wall oven Parts

For Kenmore Elite model 79048123801, the most reliable “reset” is a power reset: turn the oven off, shut off power at the breaker for 1 to 5 minutes, then restore power and reset the clock and any cooking function per the 79048123801 owner's manual.

Quick reset options (start here)

• Cancel a cycle: Press STOP/CLEAR to end cooking, silence beeps, or clear many display messages.
• Power reset (hard reset): Turn OFF the circuit breaker, wait 1 to 5 minutes, then turn it back ON.
• After an outage: If power was interrupted, reset the clock before trying to program Bake, Broil, or Timer.
• If an F-code appears: Press STOP to clear the display, then reprogram the oven; if the code returns, service is typically needed.

What to do after you restore power

When power returns, the control may flash and the oven may not accept programming until the clock is set.

Situation	What you’ll see	What to do
Power interruption	Display flashing	Set the clock, then select your cooking mode
Beeping with an F-code	“F” error code (example: F11)	Press STOP, reprogram; if it returns, plan a repair
Self-clean won’t start	Door open message (example: d=O)	Close the door fully and restart the cycle

Why it matters

A breaker reset clears temporary control glitches and restores normal programming after a power interruption. Setting the clock is especially important because the oven control logic can block cooking functions until time-of-day is stored.

Parts that commonly relate to “reset” symptoms

If the oven still will not heat or keeps throwing errors after a proper reset, these parts are common suspects for this model:

• Frigidaire wall oven relay control board 316443910 (control logic and power switching)
• Frigidaire range oven temperature sensor 316217002 (temperature feedback to the control)
• Terminal block 5304409888 (power connection point)

You can order replacement parts for model 79048123801 from the parts list for this appliance, or search by model number on Sears PartsDirect.

Last updated: February 2026

An electric wall oven like Kenmore Elite 79048123801 is built around heating elements, controls, airflow parts, and door and lighting components. In this model family, the manual highlights items such as the broil element, oven vent, convection fan (some models), oven racks, oven light, door lock, and electronic controls.

Core parts you will find in most electric wall ovens

• Bake element: primary heat source for baking (usually bottom of the oven cavity)
• Broil element: high-heat element at the top for broiling
• Electronic oven controls: clock, timer, temperature selection, and mode selection
• Oven temperature sensor: tells the control board the actual oven temperature
• Convection fan system (some models): circulates hot air for more even baking
• Cooling fan (some models): cools electronic components and can run after the oven turns off
• Door system: door glass, handle, hinges, and door lock (self-clean models)
• Oven light system: light bulb, socket, and lens/cover

Parts on this model that commonly get replaced

These are examples of parts available for Kenmore Elite 79048123801 that match common oven components:

Oven system	Example part on this model	What it does
Lighting	Range oven light bulb 316538904	Illuminates the oven cavity
Temperature sensing	Frigidaire range oven temperature sensor 316217002	Helps regulate temperature accuracy
Heating	Frigidaire range bake element 318254902	Provides bake heat
Air movement	Fan blade 318398302	Moves air for convection (when equipped)
Cooling	Range oven cooling fan assembly 318073028	Cools controls and wiring

Why it matters

Knowing the major oven parts helps you troubleshoot faster. For example, uneven baking often points to a bake element or convection fan issue, while temperature swings often point to the sensor or control.

Where to confirm what your oven has

Feature sets can vary by configuration (single vs. double, convection vs. non-convection). We recommend checking the feature diagram and safety notes in the owner's manual and using your model number to match the correct parts list on Sears PartsDirect.

Last updated: February 2026

On the Kenmore Elite wall oven model 79048123801, the NCAL code indicates the oven control has lost calibration. Reset power to clear it; if NCAL returns, the control system needs service, and the most common fix is replacing the relay/control board.

What to do first (safe reset)

• Press STOP/CLEAR to stop beeping and clear the display.
• Turn power off at the breaker for 1 minute (preferred over unplugging for a wall oven).
• Restore power and set the clock.
• Run a quick bake test (for example, 350°F) to see if the code returns.

If NCAL comes back

When the code reappears after a reset, we treat it like a persistent electronic control fault.

• Record exactly what you see (NCAL, any F-code, beeping pattern).
• Avoid self-clean until the issue is resolved (control faults can interrupt a cycle).
• Check for obvious wiring issues at the junction box only if you are qualified and power is off.
• Plan for control repair; on this model, that typically means replacing the control/relay board.

Helpful part to consider: wall oven relay control board 316443910.

Quick decision guide

What you see	What it usually means	What we recommend
NCAL appears once, then clears after reset	Temporary control glitch	Reset power and monitor
NCAL returns repeatedly	Control calibration fault	Replace control/relay board
Any F-code keeps returning	Stored control fault	Record code, service control circuit

Why it matters

A control that loses calibration can mismanage bake/broil timing and temperature regulation, and it can also trigger nuisance beeping or shutdowns. Fixing the control issue restores reliable heating performance and normal operation.

For control features, error behavior, and operating steps specific to your oven, use the 79048123801 owner's manual. If you need to confirm safe power connection and grounding requirements for a wall oven installation, use the 79048123801 installation guide. You can also search by model number on Sears PartsDirect if you are comparing part options.

Last updated: February 2026

If your Kenmore Elite wall oven model 79048123801 is not working at all, the most common causes are a power supply issue (breaker, wiring, clock not set after an outage) or a control fault that needs to be cleared and rechecked. Use the troubleshooting steps in the 79048123801 owner's manual to pinpoint the failure.

Quick checks we recommend first

• Set the clock if the display is flashing after a power interruption; the oven may not program until the clock is set.
• Check the house breaker or fuse; reset the breaker fully (OFF then ON).
• Confirm the junction box connection is secure (wall ovens are hardwired; loose connections can stop all functions).
• Press STOP/CLEAR to cancel any active mode and try a basic BAKE cycle again.
• If an error code such as F11 appears, press STOP to clear it; if it returns, the control is detecting a fault.

If the oven has power but will not heat

Heating problems are usually tied to a failed sensor, element, or control.

• If baking is weak or inconsistent, the oven temperature sensor is a common suspect: consider testing or replacing the range oven temperature sensor 316217002.
• If the oven will not bake, inspect the bake element for visible damage; replacement for this model is the range bake element 318254902.
• If broil does not work but other functions do, the broil circuit or element may be involved (also check settings).

If the display is on but the oven seems “locked out”

Some settings can make the oven appear unresponsive.

What you see	What it usually means	What to do
Display flashing	Power was interrupted	Set the clock, then retry BAKE
Error code (example: F11)	Control detected a fault	Press STOP; retry; if it returns, service is needed
Oven shut off after outage	Normal safety behavior	Restart cooking after power returns

Why it matters

Wall ovens pull high voltage and rely on correct wiring and control logic. A simple issue like a tripped breaker or an unset clock can stop the entire oven, while a recurring fault code points to an electronic control or wiring problem that should be addressed before it worsens.

Parts and ordering notes

If troubleshooting points to a failed component, you can order model-matched replacement parts from the parts list for 79048123801, or search by model number on Sears PartsDirect.

Last updated: February 2026
