Craftsman 917251550 tractor Parts

For Craftsman tractor model 917251550, we find the model and serial number on the model plate under the seat. Lift the seat and look on the frame area beneath it; record both numbers so you can match the correct parts list and owner’s manual.

• Lift the seat and look for a metal or adhesive model plate on the frame
• Write down the model number and serial number exactly as shown
• If the plate is dirty, wipe it clean so every digit is readable
• Take a photo of the plate for reference when ordering parts

Your tractor and engine use different model numbers. For model 917251550:

Using the correct model number prevents ordering the wrong parts for your Craftsman front-engine lawn tractor, especially for items that vary by build such as belts, switches, and steering or ground drive components.

Use the exploded views and identification info in the 917251550 owner’s manual to confirm the plate location and recordkeeping details before you shop for parts.

Last updated: February 2026

For the Craftsman lawn tractor model 917251550, use SAE 10W-30 4-cycle engine oil for temperatures above 32°F, and SAE 5W-30 for temperatures below 32°F (API SF/SG). This viscosity match helps protect the engine during both hot mowing and cold starts; see the owner's manual for the full viscosity chart and service intervals.

Use this quick guide for your engine oil selection:

Your 917251550 engine oil capacity is:

• With oil filter: 4.2 pints
• Without oil filter: 3.7 pints

If you are doing an oil change with a filter, we recommend replacing the filter at the same time; the oil filter 12-050-01-s1 listed for this model is a common maintenance item.

• Use 4-cycle (4-stroke) engine oil (not 2-cycle mix).
• Choose oil that meets API SF/SG performance listed for this tractor.
• Check oil level on level ground before each use.
• Do not overfill; fill only to the FULL mark on the dipstick.
• For seasonal temperature changes, switch viscosity (10W-30 to 5W-30) to match conditions.

Correct oil viscosity reduces wear on internal engine parts, improves lubrication at startup, and helps control operating temperature. Using the right oil for the weather is one of the simplest ways to extend the life of a Craftsman riding mower engine.

Last updated: February 2026

Your Craftsman riding mower model is identified by the product identification label on the tractor. For Craftsman model 917251550, the label is typically found under the seat area; match the full model number exactly to be sure you’re ordering the right parts and using the correct specs from the owner's manual.

Check these common locations on riding mowers and lawn tractors:

• Underside of the seat or on the seat pan (lift the seat and look for a sticker or metal tag)
• Frame rail near the rear wheels
• Under the hood near the engine compartment
• Near the footrest area on the chassis
• On the fender deck close to the seat

Use the label details to confirm the exact match:

Craftsman tractors often share similar looks across multiple model numbers, but parts like belts, pulleys, switches, and steering components can vary by model. Using the exact model number helps prevent ordering the wrong items and speeds up troubleshooting.

When you confirm the model number, you can confidently match parts such as:

• PTO switch (example: switch 582107601)
• Starter solenoid (example: solenoid 532146154)
• Drive belt and deck belt routing (use the diagrams in the manual)
• Ignition key style (example: molded ignition key 532140403)

Last updated: February 2026

Craftsman model 917251550 was produced in multiple runs; the model number alone does not identify a single build year. The reliable way to get the exact year for your tractor is to read the product ID label and match it to the specifications and parts breakdown in the 917251550 owner's manual.

Check the tractor itself first, then use the manual to confirm what you have.

• Locate the product ID label (commonly under the seat, on the frame rail, or near the rear fender pan).
• Write down the serial number and any date code printed on that label.
• Check the engine identification tag; the manual shows a Kohler CV22-PS67515 configuration for this model.
• Compare your tractor’s deck and chassis to the illustrated parts sections to confirm the configuration.
• If the label is missing or unreadable, use distinctive parts (PTO switch style, wiring layout, deck hardware) to narrow the production version.

The documentation for this Craftsman tractor ties these details directly to model 917.251550.

The build year and production version affect parts fit, especially for electrical and drive components. For example, a no-start or no-crank issue often traces to the PTO circuit; matching your switch style to the correct replacement (such as the switch 582107601) prevents ordering the wrong part.
