Kenmore 10651789412 refrigerator Parts

Most Kenmore side-by-side refrigerators are about 33 inches to 36 inches wide; your Kenmore model 10651789412 is in that same typical range. For the exact cabinet width and door-clearance measurements for your unit, use the dimensions section in the 10651789412 owner's manual.

Side-by-side refrigerators are commonly built in a few standard widths. Use these as a planning guide when you are measuring a kitchen opening.

• 33 inches: common for many standard-capacity side-by-sides
• 35 to 36 inches: very common for larger-capacity side-by-sides
• Counter-depth models: often still about 36 inches wide, but shallower front-to-back
• Built-in styles: can be wider, but are less common in Kenmore 106-series designs

To avoid fit issues, we measure more than just the cabinet width.

• Measure the opening width at the top, middle, and bottom
• Leave space for door swing and handle clearance
• Confirm you have room to pull the refrigerator out for service access
• Check the path from the door to the kitchen (hallways, turns, and doorways)
• If you have an ice maker or water dispenser, allow room for the water line behind the unit

A side-by-side that is even 1 inch too wide can bind against cabinets, limit door opening, and make it harder to replace parts later (like a water filter or door bin). If you need replacement parts for your 10651789412, you can order them from the parts list for this model or search by model number on Sears PartsDirect.

Last updated: February 2026

Most side-by-side refrigerators are about 30 to 36 inches wide, 67 to 70 inches tall, and 29 to 35 inches deep. For the exact dimensions and clearance requirements for your Kenmore 10651789412, we recommend checking the specifications section in the owner's manual.

These are the most common exterior dimension ranges for a side-by-side refrigerator like the Kenmore 10651789412:

• Width: 30 to 36 inches
• Height: 67 to 70 inches
• Depth (cabinet): 29 to 35 inches
• Depth with handles: often 1 to 3 inches deeper than the cabinet
• Door swing clearance: plan extra space so doors open fully without hitting walls or cabinets

Use a tape measure and record three numbers; measure at the widest/tallest points.

• Measure width across the front at the widest point (often the hinge caps or doors)
• Measure height from floor to the top (include hinge covers if they stick up)
• Measure depth from the back to the front (note cabinet depth and depth with handles)
• If you are replacing a unit, also measure the opening (niche) and compare

Clearances vary by kitchen layout, but these targets prevent most fit and airflow problems.

Correct sizing prevents installation headaches and helps performance. Tight clearances can restrict airflow around the condenser and compressor, and poor door-swing clearance can make shelves and bins hard to access.

If you are also planning for water and ice, we stock common maintenance items for this model, such as the Kenmore refrigerator water filter 9081; you can also search by model number on Sears PartsDirect.

Last updated: February 2026

On Kenmore side-by-side refrigerators like model 10651789412, the model number is printed on the appliance identification label. You will typically find that label inside the fresh food (refrigerator) compartment on a side wall near the crisper drawers, or on the ceiling near the light.

Look for a sticker or metal tag that lists MODEL and SERIAL. Check these spots first:

• Inside the refrigerator section on the left or right wall (often near the crisper area)
• On the ceiling of the refrigerator section near the light housing
• On the door frame (the vertical frame the door seals against)
• Behind the toe grille or lower front kickplate area (less common)
• On the back exterior panel near the power cord (less common)

For model-specific label location diagrams and wording, use the owner's manual.

The label usually includes several fields. Here is what matters most:

We use the model number to match the correct Kenmore parts and diagrams for your refrigerator, including common maintenance items like the Kenmore refrigerator water filter 9081 and the refrigerator air filter W10311524. Using the full model number prevents ordering a similar-looking part that does not fit.

• Wipe the label gently with a damp cloth; dust and food residue can hide the print
• Use a flashlight and take a close-up photo, then zoom in
• Write down the model number exactly as shown (all digits, no spaces)
• If you are ordering parts, search by model first on this model page; for broader searching, use Sears PartsDirect

Last updated: February 2026

To replace the ice maker in your Kenmore 10651789412 side-by-side refrigerator, we shut off power and the water supply, remove the ice bin and mounting screws, transfer any required bracket/stripper from the old unit, then install and test the replacement ice maker assembly (such as Refrigerator ice maker assembly W10873791). For model-specific access points and screw locations, use the Owner's manual.

• Unplug the refrigerator or switch off the circuit breaker.
• Turn off the household water supply to the refrigerator.
• Empty the ice bin and remove it (most bins lift out once the door is open).
• Protect the freezer floor with a towel to catch any drips.
• Take a quick photo of the wiring connector and fill tube position for reference.

1. Remove the ice bin and any front cover on the ice maker (if equipped).
2. Disconnect the ice maker wiring harness plug.
3. Remove the mounting screws; support the ice maker as the last screw comes out.
4. Transfer the old ice maker’s mounting bracket, shutoff arm, or stripper (if your old unit has them and the new one does not).
5. Install the new ice maker, align it to the mounting slots, and tighten screws.
6. Reconnect the wiring harness.
7. Restore water and power; allow 12 to 24 hours for normal ice production.

• Confirm the freezer temperature is near 0°F (ice makers slow down above about 10°F).
• Make sure the fill tube is not frozen or blocked.
• Verify the water supply valve is fully open and the line is not kinked.
• Replace a restricted water filter if flow is weak (example: Kenmore refrigerator water filter 9081).
• If the ice maker never fills, test the inlet valve (example: Refrigerator water inlet valve WPW10341320).

A correctly installed ice maker must be firmly mounted, properly connected to the harness, and able to receive steady water flow. A loose mount, frozen fill tube, or restricted filter can mimic a “bad ice maker” and delay ice production.

Last updated: February 2026

The most common problems we see on Kenmore refrigerators like model 10651789412 are cooling issues, water leaks, ice maker or dispenser failures, and unusual noises. These usually trace back to airflow restrictions, frost buildup from a defrost problem, or worn water and door-seal components; use the 10651789412 owner's manual for model-specific checks.

• Not cooling or warm temperatures: dirty condenser coil, failed evaporator fan motor, stuck air damper, or defrost system trouble
• Frost buildup in the freezer: defrost thermostat (bi-metal) or other defrost components not doing their job
• Water leaking or puddles: clogged defrost drain, loose water line, or a leaking inlet valve
• Ice maker not making ice: water supply issue, inlet valve problem, or ice maker assembly failure
• Noisy operation: evaporator fan blade rubbing ice, worn fan motor, or airflow blockage

1. Confirm temperatures: set refrigerator to about 37°F and freezer to about 0°F.
2. Check airflow: make sure vents are not blocked by food packages.
3. Inspect for frost: heavy frost on the freezer back panel points to a defrost or airflow problem.
4. Listen for fan noise: squealing, grinding, or intermittent buzzing often points to the evaporator fan area.
5. Check water flow: slow dispenser flow often improves after replacing the water filter.

Cooling, ice, and water issues often share the same root causes: restricted airflow, frost buildup, or inconsistent water supply. Catching the symptom early helps prevent food spoilage, ice jams, and repeated leaks.

For dispenser-related issues and step-by-step guidance, we also recommend how to disassemble a Kenmore refrigerator dispenser. If you need to order parts beyond the list shown for this model, search by model number on Sears PartsDirect.

Last updated: February 2026
