Kenmore 11064212200 dryer Parts

Your Kenmore dryer’s model is printed on the model and serial number plate. For Kenmore model 11064212200, that plate is the official identifier we use to match the correct parts, wiring, and installation requirements.

Where to find the model number plate

Check these common locations on Kenmore dryers:

• Inside the dryer door opening (on the cabinet frame)
• On the back panel of the dryer
• Near the lint screen housing (depending on the design)
• On the inside of the front panel area (less common)

Use the exact model number as shown, including all digits.

How to record it correctly

We recommend writing down both numbers from the plate:

• Model number (example: 11064212200)
• Serial number (unique to your specific dryer)
• Date of purchase (helpful for service history)

The 11064212200 owner's manual also references the model and serial number plate and includes a “Product Record” section you can use.

Why the model number matters for parts and troubleshooting

Kenmore dryers can look similar across different series, but parts can vary by model. Using the correct model number helps us match items like:

• Drive components (belt, idler pulley, drum support)
• Heating system parts (heating element, thermostats, thermal cut-off)
• Door and start components (door switch, push-to-start switch)

Examples of model-matched parts for 11064212200

Dryer symptom	Common related part	Example part for this model
Drum not turning	Drum belt	Dryer drum belt 341241
No heat or weak heat	Heating element	Dryer element 279838
Overheating or shuts off	Thermal safety kit	Dryer thermal cut-off fuse kit 279816

Quick tip before ordering

Compare the model number on your plate to the model number on your parts list. One missing digit can lead to the wrong Kenmore dryer parts.

Last updated: February 2026

An F1 code on a Kenmore dryer typically points to a problem with the electronic control, such as a stuck key on the console or a failing control board. On Kenmore model 11064212200, start by resetting power, then check the console and wiring before replacing parts.

What to do first (quick checks)

• Unplug the dryer (or switch off the breaker) for 5 minutes, then restore power and try a cycle.
• Press each button once; make sure none feel stuck or stay “pressed in.”
• If the code returns immediately, stop using the dryer until you complete the checks below.
• Confirm the dryer is installed correctly and safely vented; see the 11064212200 owner's manual.

Common causes of an F1 code

In most Kenmore electronic-control dryers, F1 is triggered by a control sensing an invalid input or internal failure.

• Stuck or shorted user interface (console) key
• Loose or damaged wire harness connection at the control
• Control board failure (internal relay or circuit fault)
• Moisture or corrosion at connectors (especially after a vent restriction or high humidity)

Basic troubleshooting steps (safe DIY)

1. Disconnect power.
2. Access the console/control area using the disassembly steps in the 11064212200 installation guide.
3. Reseat wire harness plugs at the control (unplug, inspect, reconnect firmly).
4. Look for pinched wires, overheated terminals, or discoloration.
5. Restore power and test.

If the dryer also overheats or shuts off

A restricted vent can contribute to heat-related shutdowns and electrical stress. Make sure you are using 4-inch heavy metal venting and exhausting outdoors, as specified in the installation instructions.

When a part replacement is likely

If the F1 code returns right after a reset and the keypad is not stuck, the control electronics are usually the issue.

Symptom	Most likely area	What we recommend
F1 appears immediately at power-up	Control board or UI	Inspect harness, then replace the failed control component
F1 appears only when pressing certain keys	Keypad/UI	Check for stuck key, replace console/UI if defective
F1 plus intermittent operation	Loose connection	Reseat connectors, inspect wiring

Why it matters

An F1 code is the dryer telling you it cannot reliably read commands or run safely. Addressing it early helps prevent no-start conditions, repeated shutdowns, and damage to wiring or controls.

For more Kenmore code help, use our Kenmore 110 series electronic control model dryer error codes reference.

Last updated: February 2026

To hard reset your Kenmore dryer model 11064212200, disconnect power by unplugging the dryer (or switching the breaker off) for at least 1 minute, then restore power and try starting a cycle again. This clears many temporary control and cycle issues and is the safest reset method.

Hard reset steps (recommended)

• Turn the Cycle Selector (timer) to OFF.
• Unplug the dryer (or turn OFF the dedicated breaker).
• Wait 1 to 5 minutes.
• Restore power.
• Close the door fully, select a heated cycle, and press PUSH TO START.
• If the dryer still will not start, confirm the controls are set to an On/running position and the Start button is pressed firmly (these are common setup misses).

If it still will not start after the reset

A reset does not fix a failed part; it only clears a stuck state. On the Kenmore 11064212200, the most common next checks are airflow, door closure, and overheat protection.

• Clean the lint screen and confirm strong airflow at the outside vent hood
• Check that the vent is not crushed or kinked behind the dryer
• Verify the door closes and latches consistently (a bad door switch or latch can prevent starting)
• If the dryer ran hot or stopped mid-cycle, test the thermal safety devices
• If the drum will not turn but the motor hums, inspect the belt and idler system

Symptom after reset	Most likely area to check	Example part for this model
Won’t start at all	Door circuit, start circuit, power supply	Door switch WP3406105
Runs but no heat	Heating circuit, thermostats, thermal cut-off	Dryer thermal cut-off fuse kit 279816
Runs but drum won’t tumble	Belt, idler pulley, drum support	Dryer drum belt 341241

Why it matters

Resetting is a quick way to clear a stalled cycle or control condition, but dryers also stop or refuse to start when airflow is restricted. Keeping the venting clear helps prevent overheating that can trip thermal cut-offs and cause repeat shutdowns.

For cycle operation details and normal start/stop behavior, follow the steps in the 11064212200 owner's manual.

Last updated: February 2026
