How to tell if a gas igniter is bad?
On the Magic Chef CGR1425ADW gas range, a bad igniter usually shows up as an oven that won’t light, takes a long time to ignite, or releases a gas smell before ignition. If the igniter is weak, cracked, or not heating properly, it may not open the gas valve reliably; use the CGR1425ADW owner’s manual for model-specific safety and operating guidance.
- Oven burner does not light, or lights only after a long delay
- Igniter glows weakly, flickers, or does not glow at all
- You smell gas during an ignition attempt (turn the oven off and ventilate)
- Burner lights sometimes, then fails on the next bake cycle
- You see visible damage such as cracks, chips, or heavy white buildup on the igniter
Gas and electricity are involved, so keep safety first.
- Turn the oven control to OFF if you smell gas; do not keep retrying ignition
- Never check for gas leaks with a flame; use a non-corrosive leak detection fluid if a gas connection was disturbed
- Verify the range has power (a dead outlet can mimic an igniter problem)
- Inspect wiring to the igniter for heat damage or loose connections
- If the igniter is soiled, clean nearby debris carefully (do not hit or bend the igniter)
Most modern hot-surface igniter systems follow this pattern:
| What you observe | What it usually means |
|---|---|
| No glow at all | Failed igniter, no power to igniter, or wiring/control issue |
| Glows but burner never lights | Weak igniter (not drawing enough current) or gas valve issue |
| Burner lights quickly (typically under 60 to 90 seconds) | Ignition system is generally working normally |
If the oven igniter glows weakly or the oven takes too long to light, replacing the igniter is a common repair on this model family. The model’s listed oven igniter is the whirlpool range oven burner igniter 74007498.
A weak igniter can delay ignition and allow gas to build briefly before lighting, which can cause a “whoosh” ignition and inconsistent baking performance. Restoring proper ignition helps the oven heat predictably and safely.
Last updated: January 2026
How long do gas oven igniters last?
Gas oven igniters typically last 3 to 5 years in normal home use. On the Magic Chef CGR1425ADW gas range, frequent baking and long daily run times can shorten igniter life because the igniter heats up every time the oven cycles to maintain temperature.
Most igniters fail from heat stress and normal wear. These factors usually make them wear out faster:
- Heavy use (multiple bakes per day, long preheats)
- Power quality issues (surges or frequent outages)
- Grease or food spillovers that bake onto the burner area
- Poor airflow or incorrect burner flame setup
- A weak igniter that still glows but no longer draws enough current to open the gas valve
For model-specific operating and safety guidance, use the CGR1425ADW owner's manual.
If you see these symptoms, the igniter is often the first part we check:
- Oven takes much longer than normal to ignite
- You smell gas briefly before ignition (delayed ignition)
- Oven burner lights sometimes, but not consistently
- Igniter glows, but the burner does not light
- Oven temperature is unstable because the burner cycles incorrectly
Here’s a simple way to narrow it down before ordering parts.
| Symptom | More likely cause | Notes |
|---|---|---|
| No bake ignition, igniter does not glow | Igniter or wiring | Check connections and harness condition first. |
| Igniter glows but burner won’t light | Igniter (weak) | Very common end-of-life failure. |
| Oven heats but temperature is off | Sensor or calibration | A sensor issue can cause overheat or underheat. |
If you’re replacing the bake igniter for this range, match it to the correct part listing such as the whirlpool range oven burner igniter 74007498.
A weak igniter can cause delayed ignition, poor baking performance, and repeated failed starts. Replacing it promptly helps the oven light reliably and cycle normally.
Last updated: January 2026
Can I replace a gas stove igniter myself?
Yes, many owners can replace a surface burner igniter on the Magic Chef CGR1425ADW if they’re comfortable with basic disassembly and careful handling of the igniter and wiring. The key is shutting off power, letting everything cool, and reinstalling the burner assembly in the exact original position.
- Unplug the range (spark ignition uses household power).
- Turn all burner knobs to OFF and let the cooktop fully cool.
- Remove grates and burner caps; work on a clean, dry surface.
- Avoid pulling on wires; disconnect using the connector when possible.
- Keep water and cleaners away from the igniter tip; a wet igniter often will not light.
- Remove the grate and burner pieces to access the igniter.
- Note the igniter’s position; the installation instructions recommend marking the ignitor location relative to the main top so the burner assembly goes back to its original position.
- Remove the old igniter (typically held by a screw or clip) and disconnect the wire.
- Install the new igniter, route the wire the same way, and reassemble the burner.
- Restore power and test ignition.
If your issue is only a burner that clicks but won’t light, cleaning the small port beneath the igniter with a straight pin often restores ignition without replacing parts.
| Symptom | Most common cause | What we check/replace |
|---|---|---|
| No spark on one burner | Failed igniter or damaged lead | Range surface burner igniter 74004053 |
| No spark on all burners | Failed spark module or power issue | Spark module 8215557 |
| Oven won’t ignite (bake) | Weak oven igniter | Whirlpool range oven burner igniter 74007498 |
A correctly positioned, clean, dry igniter helps the burner light quickly and prevents delayed ignition. Reinstalling the burner assembly in its original position also helps maintain proper flame and reliable lighting.
For model-specific access steps and burner assembly handling, follow the CGR1425ADW installation guide.
Last updated: January 2026
How much does it cost to replace an igniter in a gas oven?
Replacing the oven igniter on your Magic Chef CGR1425ADW gas freestanding range typically costs $150 to $325 when a technician supplies the part and labor. If you do it yourself, the most common cost is the igniter itself (often $20 to $100+, depending on the exact part and availability).
Costs vary mainly by service call pricing and whether the igniter is a standard hot-surface igniter or a model-specific OEM part.
- DIY parts-only: $20 to $100+
- Service call / diagnostic: commonly $75 to $150
- Labor (if approved for repair): commonly $75 to $175
- Total professional repair: commonly $150 to $325
| Scenario | What you pay for | Typical total |
|---|---|---|
| DIY replacement | Igniter only | $20 to $100+ |
| Pro replacement | Igniter + labor + service call | $150 to $325 |
| Complex visit | Extra troubleshooting or wiring repair | $250 to $400+ |
On the CGR1425ADW, ignition issues can involve the oven igniter itself or related ignition components.
- Oven igniter (bake ignition): Whirlpool range oven burner igniter 74007498
- Surface ignition issues (not the oven): Range surface burner igniter 74004053
- If ignition is weak or inconsistent: wiring connections and harness routing can add labor time
We recommend ruling out simple causes first because they can mimic a failed igniter.
- Confirm the range has power (spark ignition needs electricity)
- If you smell gas, turn the burner off and ventilate before attempting relight
- Inspect for a wet/soiled igniter area and carefully clean around it
- Check burner ports for clogs (a small port near the igniter can block lighting)
- If flames are yellow or lifting, the burner air shutter may need adjustment
A weak or failed igniter can prevent the oven from heating properly, cause long preheat times, or lead to intermittent ignition. Fixing ignition promptly helps restore normal baking performance and reduces nuisance shutdowns.
For model-specific safety steps and access details, follow the CGR1425ADW owner's manual.
Last updated: January 2026
