Kenmore 11088752794 washer/dryer laundry system Parts

For Kenmore laundry centers like model 11088752794, the model number is printed on the appliance’s model and serial tag. On stacked units, it’s commonly found behind the washer lid area, inside the dryer door opening, or on the cabinet frame near the control panel.

Where to look on a Kenmore stacked laundry center

Check these spots in order (they are the most common locations):

• Washer section: under the washer lid, around the tub opening rim
• Dryer section: inside the dryer door opening on the front frame
• Cabinet frame: side panel edge or near the control console
• Back panel: near the power cord entry or service access area
• Behind the access panel: some tags are visible after removing the small service panel

Use the location diagrams and labeling notes in the 11088752794 owner's manual.

What the model number looks like (and why it matters)

Kenmore model numbers often start with 110 and are typically 11 characters (or longer). Using the exact model number helps us match the correct Kenmore parts, diagrams, and repair instructions for your washer/dryer laundry system.

What you see on the tag	What it means	Use it for
Model number (example: 11088752794)	Exact product identity	Ordering parts, manuals, diagrams
Serial number	Production identifier	Warranty and manufacturing info
Type or code	Internal build info	Technician diagnostics

Tips to read the tag correctly

• Copy the model number exactly, including all digits
• Use uppercase for any letters (if present)
• Take a clear photo before ordering parts
• If the tag is worn, try a flashlight at an angle to make the print stand out

Why it matters

Kenmore laundry centers can use different timers, drain pumps, couplings, and dryer components depending on the exact model. Matching the model number first prevents ordering the wrong replacement part and saves time on repairs.

Last updated: February 2026

For the Kenmore 11088752794 stacked laundry center, the most common problems are washer not draining or spinning, washer agitation issues, and dryer not heating or not starting. These symptoms usually trace to a few high-wear parts and basic airflow, lid/door, or load-balance conditions.

Common symptoms and what they usually mean

• Washer won’t drain: clogged pump, jammed impeller, or a blocked drain hose.
• Washer won’t spin: lid switch not closing, drive coupling wear, clutch wear, or an out-of-balance load.
• Washer agitator won’t move or “slips”: worn agitator dogs or a loose agitator bolt.
• Dryer runs but doesn’t heat: heating circuit issue, wiring/terminal damage, or restricted venting.
• Dryer won’t start: start switch issue, door switch/strike alignment, or power supply problem.

Parts that commonly fix these issues

If your symptoms match, these model-compatible parts are frequent solutions:

• Washer drain pump WP3363394 for no-drain or slow-drain complaints
• Coupling 285753A for no-agitate or no-spin after a sudden stop or overload
• Washer lid switch assembly WP3355806 for no-spin when the lid is closed
• Agitator dog 80040 for weak or one-direction agitation
• Dryer push-to-start switch WP3977456 for a dryer that won’t start

Quick checks before replacing parts

• Confirm the lid closes firmly and the load is balanced (especially bulky items).
• Check the drain hose for kinks and verify the standpipe is not backing up.
• Clean the lint screen and make sure the exhaust vent is not crushed or clogged.
• Reset power: unplug for 2 minutes, then retry a cycle.

Symptom-to-part cheat sheet

Symptom	Most likely area	Common part example
Won’t drain	Pump or blockage	WP3363394
Won’t spin	Lid switch, coupling, clutch	WP3355806, 285753A
Poor agitation	Agitator drive	80040
Won’t start (dryer)	Start circuit	WP3977456

Why it matters

Catching these issues early prevents secondary damage, like motor strain from a stuck pump, or overheating risk from poor dryer airflow. For model-specific cycle behavior and safety steps, follow the owner's manual.

Last updated: March 2026

The Kenmore laundry center model 11088752794 is a 24-inch wide stacked washer-electric dryer. Dryers in this 24-inch laundry center class are typically about 3.4 to 4.0 cu. ft.; use the published spec for your exact unit in the 11088752794 owner's manual.

How to confirm the exact capacity for your unit

Use the model-specific documentation and the model/serial label so you match the correct configuration.

• Check the specifications section in the 11088752794 owner's manual
• Verify the model/serial label location: top inside the dryer door well
• Compare only to other 24-inch laundry centers, not 27-inch full-size dryers
• If you see multiple spec tables, use the one that matches your power type (electric dryer)
• Keep loads sized for good tumbling; capacity is about drum volume, not weight

Typical capacity ranges (what most owners see)

These ranges help you set expectations when shopping for replacement parts or comparing machines.

Dryer type	Typical capacity range	What it handles well
24-inch stacked laundry center dryer (like 11088752794)	3.4 to 4.0 cu. ft.	Everyday loads, smaller bedding
27-inch full-size dryer	6.5 to 7.4+ cu. ft.	Large towels, comforters

Why it matters

Capacity affects airflow and tumbling space. When the drum is overfilled, clothes cannot lift and drop properly; drying times increase and items can come out damp or wrinkled even when heat and venting are normal.

Last updated: February 2026
