Kenmore Elite 79661512211 dryer Parts

On Kenmore Elite dryer model 79661512211, the model number is printed on the rating label, most often on the door opening area (inside the door on the cabinet frame). If it is not there, check the back of the dryer near the top.

• Open the dryer door and look along the cabinet frame (door opening) for a sticker or metal tag
• Check the back panel near the top edge
• Look just inside the door opening on the left or right side
• If your dryer is stacked, you may need to pull it forward to see the rear label

The model/serial label is usually a white sticker or silver tag. It typically lists:

• Model number (for example, 79661512211)
• Serial number
• Electrical rating information
• Sometimes the manufacturing date code

We use the exact model number to match the correct Kenmore Elite dryer parts and diagrams. Even one digit off can lead to ordering the wrong heating, drum, or control components.

For model-specific identification details and care information, use the 79661512211 owner's manual.

Last updated: January 2026

In Kenmore Elite dryer model 79661512211, the moisture sensor is typically mounted inside the drum area at the lint screen housing, with the sensor bars accessible from the front opening after removing the lint screen and its grille. Confirm the exact access steps in the 79661512211 owner's manual.

On this style of Kenmore Elite dryer, the moisture sensor is usually positioned so wet clothes can rub across it during tumbling.

• Inside the drum opening, near the lint filter duct/housing
• Behind the lint screen area (you often remove the lint screen first)
• Secured with screws to a small holder or bracket
• Connected with two wire leads (commonly white wires)

Always disconnect power before opening panels.

1. Remove the lint screen.
2. Remove the lint screen grille/duct cover screws.
3. Lift out the grille/cover to expose the sensor holder.
4. Locate the sensor bars and the wire connector.

If the sensor is damaged or heavily corroded, the correct replacement for this model is the dryer moisture sensor 6500EL3001A.

The sensor helps the control detect remaining moisture so Auto Dry cycles can stop at the right time.

A dirty or misplaced moisture sensor can make the dryer “think” clothes are dry when they are not, which leads to short cycling, inconsistent results, and longer overall laundry time.

Last updated: January 2026

The model number for this Kenmore Elite dryer is 79661512211. You will typically find it on the model and serial number label on the cabinet opening (door area) or on the frame behind the door; our 79661512211 owner's manual also points you to the identification label location.

Check these common label locations on Kenmore Elite dryers like model 79661512211:

• On the door opening (cabinet front) when you open the dryer door
• On the inner door frame or door jamb area
• On the cabinet side panel near the front edge
• On the rear panel (less common, but possible)

For Kenmore Elite dryers, the model number is a long numeric string. Use the full number exactly as shown on the label.

We use the exact model number to match the correct Kenmore Elite 79661512211 dryer parts and diagrams. Even a one-digit difference can change the correct heating circuit, drum support roller style, or belt routing.

Before ordering common wear items, confirm the model number first, then match the part to the symptom:

• Squealing or thumping: often a roller or idler pulley
• Drum not turning: often a belt or idler issue
• No heat or overheating: often a thermostat or thermistor

Last updated: January 2026

To reset your Kenmore Elite dryer model 79661512211, we recommend a simple power reset: unplug the dryer (or switch off the breaker) for about 1 to 5 minutes, then restore power and try a normal cycle. This clears many temporary control glitches.

• Hard reset (power reset): Unplug for 1 to 5 minutes, then plug back in.
• Breaker reset: Turn the dryer breaker OFF for 1 to 5 minutes, then ON.
• Control lock reset: If the display shows a lock indicator (often “CL” or “LOC”), press and hold the Control Lock button (or the button labeled for lock) for about 3 seconds.
• Cycle reset: Turn the cycle selector to OFF, wait 10 seconds, then select a timed dry cycle and press Start.

For the exact button sequence your control panel uses, follow the steps in the 79661512211 owner's manual.

A dryer that will not start, stops mid-cycle, or will not heat often has an airflow or safety cutout issue that a reset will not solve.

• Clean the lint screen and confirm it seats correctly (a damaged screen can reduce airflow).
• Check the vent duct for kinks, crushing, or heavy lint buildup.
• Make sure the door closes firmly; a failed door switch can prevent starting.
• If the drum will not turn, inspect belt and pulley components.
• If heat is inconsistent, temperature-sensing parts can be involved.

A reset clears the control board’s temporary state, but it does not correct mechanical drag, restricted venting, or overheating protection trips. Fixing airflow and worn drive parts helps prevent repeat shutdowns and long dry times.

Last updated: January 2026
