Kenmore Elite 79681548210 dryer Parts

On the Kenmore Elite dryer model 79681548210, the model number is printed on the appliance identification label. You will usually find that label just inside the dryer door opening on the cabinet frame; some units also place it on the back panel near the top.

• Open the dryer door and look around the door opening on the cabinet frame
• Check the door itself (along the inner edge)
• Look on the back of the dryer near the top (especially if the door area label is worn)
• If your dryer is stacked, check the visible side edges around the door opening first

The label typically includes the model number, serial number, and electrical ratings. For the quickest match, look specifically for a long number like 79681548210.

We use the exact model number to match the correct Kenmore Elite dryer parts and diagrams. Even small model-number differences can change which heating, drum, or control parts fit.

Use the diagrams and identification info in the 79681548210 owner’s manual to confirm you are reading the correct label and recording the full model number.

Last updated: January 2026

Kenmore Elite dryer error codes are the dryer’s way of reporting a specific problem area, such as a power interruption, a control board issue, a keypad problem, or a temperature-sensing failure. For model 79681548210, start by matching the exact code on the display to the list in the 79681548210 owner's manual.

• PF: Power failure or power interruption during a cycle.
• F:01: Main electronic control board problem.
• F:02: Keypad or user interface problem.
• F:20: Heater relay problem.
• F:22 / F:23: Outlet thermistor (temperature sensor) problem.
• F:24 / F:25: Inlet thermistor (temperature sensor) problem.

1. Clear the code: Unplug the dryer (or switch off the breaker) for 1 minute, then restore power.
2. Check power (especially for PF): Confirm the breaker is fully reset and the outlet is supplying correct voltage.
3. Check airflow (important for thermistor and heating-related codes): Clean the lint screen and make sure the vent is not crushed or clogged.
4. Run a timed dry test: If the code returns quickly, it helps narrow the issue to a control, sensor, or heating circuit.

If you’re seeing thermistor or heating-related codes repeatedly, these model-compatible parts are often involved:

Using the correct error code meaning prevents unnecessary part replacement. For example, a thermistor code can be triggered by restricted venting, not just a failed sensor, so airflow checks can save time and cost.

• For a broader list and code definitions, use Kenmore elite dryer error codes.

Last updated: January 2026

On Kenmore Elite dryer model 79681548210, the moisture sensor is typically mounted inside the drum area at the front, near the lint filter housing; you usually access it by removing the lint screen and the lint screen housing to reach the sensor bars and wiring. See the 79681548210 owner's manual for the exact access steps for your configuration.

In most Kenmore Elite (LG-built) dryers, the moisture sensor consists of two metal sensor bars mounted on a small bracket near the front bulkhead, close to where clothes pass as the drum turns.

Common locations you will see it:

• Just inside the drum opening at the front bulkhead (lower front area)
• Attached to or immediately beside the lint screen housing/duct
• Reached after removing the lint screen and the housing screws
• Connected with two wires on the sensor harness

If your dryer has a sensor that is damaged, corroded, or reading erratically, the replacement part for this model is the dryer moisture sensor 6500EL3001A.

Before you start, we recommend these basics:

• Unplug the dryer (or switch off the breaker)
• Remove the lint screen
• Remove the screws securing the lint screen housing (if equipped)
• Carefully pull the housing forward to expose the sensor bracket and wire connector
• Take a photo of wire routing before disconnecting anything

The moisture sensor helps the control board estimate dryness during Auto/Sensor cycles. If the sensor is dirty or not making good contact with wet fabric, the dryer can shut off too soon or run too long.

For cycle behavior that seems tied to sensing, we also recommend checking Kenmore elite dryer error codes to rule out a stored fault.

Last updated: January 2026

To reset your Kenmore Elite dryer model 79681548210, we recommend a hard reset: unplug the dryer (or switch the breaker off) for about 1 to 5 minutes, then restore power and try a normal cycle. This clears many temporary control glitches; if the problem returns, focus on the underlying cause.

• Turn the dryer OFF.
• Unplug the power cord (or turn the dryer breaker OFF).
• Wait 1 to 5 minutes.
• Restore power.
• Select a timed dry cycle and press Start.
• If the control panel is locked, press and hold the Control Lock button (label varies by console) for about 3 seconds.

A reset will not fix a failed safety device or a mechanical problem. These checks solve most “won’t start” complaints on Kenmore Elite dryers:

• Confirm the door is fully closed; a bad door switch can prevent starting.
• Check house power: electric dryers typically need 240V (two breakers); a tripped half-breaker can leave the dryer “on” but unable to heat or run correctly.
• Clean lint screen and verify strong airflow at the outside vent hood.
• Listen for motor hum or drum resistance; a seized drum, roller, or belt issue can stop the cycle.
• If the dryer runs but shuts off quickly, overheating from restricted venting is a common trigger.

Resetting is a fast way to clear a temporary control issue, but repeated lockups, no-start conditions, or overheating symptoms usually point to airflow restrictions or a failing part (belt, thermostat, heating element, or switch). Fixing the root cause prevents repeat shutdowns and improves drying performance.

For model-specific button locations and control lock behavior, follow the steps in the 79681548210 owner’s manual.

Last updated: January 2026
