Kenmore 79565002401 bottom-mount refrigerator Parts

Your Kenmore bottom-mount refrigerator model 79565002401 has a total capacity of 21.8 cu. ft.; it breaks down to 14.3 cu. ft. for the fresh food (refrigerator) section and 7.5 cu. ft. for the freezer. You can confirm these specs in the 79565002401 owner's manual.

Here is the storage volume for this model:

• Total capacity: 21.8 cu. ft.
• Refrigerator (fresh food): 14.3 cu. ft.
• Freezer: 7.5 cu. ft.
• Usable space: slightly less once shelves, bins, and the ice bin are installed

If you want to verify it on the appliance itself, check these common locations:

• Rating label inside the fresh food compartment (often on a side wall near the crisper area)
• Model and serial tag area near the door opening
• Specification section of the manual for the 795.6500 model family

Knowing the exact cubic feet helps you compare refrigerators accurately and plan storage. It also helps when choosing interior parts such as shelves, drawers, and door bins that match the space and layout for 79565002401.

Last updated: February 2026

Kenmore model numbers tell us the product platform and the exact configuration so we can match the correct parts and documentation. For Kenmore bottom-mount refrigerator model 79565002401, the 795 prefix identifies the manufacturer family, and the remaining digits identify the specific version.

On Kenmore 79565002401, the model and serial number are printed on an identification label on the right-hand side of the refrigerator compartment (fresh food section). This location is shown in the 79565002401 owner's manual.

• Open the fresh food (upper) door
• Check the right interior wall near the front edge
• Record the full model number and serial number
• Use the full model number (not just the 3-digit prefix) when ordering parts
• Keep the numbers with your purchase date for service reference

Most Kenmore model numbers use a 3-digit prefix plus additional digits that define the series and features.

The prefix helps identify the platform, but the full model number ensures the right fit for shelves, gaskets, sensors, and electronics.

Parts that commonly vary by full model number include:

• Light and door-activated circuits such as the refrigerator door push-button switch 6600JB1010A
• Temperature sensing parts such as the refrigerator thermistor 6500JB2002T
• Door sealing parts such as the refrigerator gasket assembly ADX73350922

Using the exact model number reduces wrong-part returns and speeds up troubleshooting for issues like warm temperatures, door seal leaks, and control or sensor problems.

Last updated: February 2026

On Kenmore model 79565002401, a “bad compressor” usually shows up as poor cooling with the unit trying to run (often a repeated clicking or long run times) but temperatures never recover. Before condemning the compressor, we check power, airflow, and defrost related issues because those problems can mimic compressor failure; see the 79565002401 owner's manual.

• Confirm the refrigerator control is not set to OFF and the unit has power (cord, breaker, fuse).
• Listen for normal operating sounds; modern high-efficiency compressors can run longer and sound different than older units.
• Check whether the refrigerator is simply running more due to warm room temperature, frequent door openings, or a large food load.
• Verify the condenser area is not blocked by dust buildup and the unit has proper air circulation.
• Look for signs of a defrost problem (frost buildup on the freezer back wall, weak airflow).

A compressor issue is more likely when you see several of these together:

• Clicking every few minutes (start attempt, then shutoff)
• No steady hum/vibration from the compressor after a start attempt
• Warm refrigerator and freezer even though the unit “runs” a lot
• Compressor very hot to the touch after repeated start attempts
• Condenser fan runs but cooling does not improve

The manual notes that clicking (controls/defrost timer), gurgling (refrigerant movement), and fan airflow sounds can be normal. Use this as a guide:

Replacing a compressor is a sealed-system repair; it is more expensive than common fixes like a sensor, fan, or door seal. Ruling out airflow and defrost issues first prevents unnecessary sealed-system work.

• For model-family diagnostics, use Kenmore 795 model bottom freezer refrigerator error codes.

Last updated: February 2026

A Kenmore Elite refrigerator typically lasts 10 to 15 years with normal household use and basic maintenance. For your Kenmore bottom-mount refrigerator model 79565002401, keeping airflow clear, cleaning condenser coils, and maintaining good door seals are the biggest factors in reaching that range (or longer); see the 79565002401 owner's manual for model-specific care steps.

Most modern refrigerators fall into a similar life range, but these items most strongly influence how long a Kenmore Elite unit runs reliably:

• Condenser coil cleanliness (dust buildup makes the compressor work harder)
• Door gasket condition (warm air leaks increase run time and frost)
• Proper air circulation inside the cabinet (blocked vents cause uneven temps)
• Stable temperatures (avoid frequent warm-ups from long door openings)
• Power interruptions and surge events (can stress controls)

We recommend these routine steps for Kenmore bottom-mount refrigerators:

• Vacuum and brush the condenser coils regularly
• Keep food from blocking interior air vents
• Clean and inspect door gaskets; replace if torn or not sealing
• Confirm doors close fully and stay aligned
• If equipped, replace the water filter on schedule

A refrigerator that runs longer than necessary uses more electricity and puts extra wear on the sealed refrigeration system. Simple upkeep (especially coils and gaskets) reduces run time, improves temperature stability, and helps the compressor last.

Last updated: February 2026

Your Kenmore refrigerator’s model number is printed on the appliance ID label; on Kenmore bottom-mount units like model 79565002401, that label is typically inside the fresh food compartment on a side wall or near the ceiling, or on the door frame. Use that exact model number to match parts and manuals.

Check these common locations first (in order):

• Inside the refrigerator (fresh food) compartment on the left or right interior wall
• Inside the refrigerator compartment near the top (ceiling area)
• On the door frame (open the refrigerator door and look around the perimeter)
• Behind the base grille or kick plate at the bottom front
• On the back exterior panel (less common, but worth a quick look)

The label usually includes multiple identifiers. Record them exactly as shown:

• Model number (this is what we use to match parts)
• Serial number (helps identify production run details)
• Electrical ratings (volts/amps) and sometimes a barcode

Kenmore model numbers can look very similar, and even one digit difference can change the correct door gasket, shelf, thermistor, or control board. Matching the exact model number prevents ordering the wrong refrigerator parts.

For model-specific feature and location diagrams, use the 79565002401 owner's manual.

Last updated: February 2026

For Kenmore bottom-mount refrigerator model 79565002401, the right water filter is the cartridge style that matches your refrigerator’s filter housing and connection type (twist-in, push-in, or an inline filter on the water line). Use the 79565002401 owner’s manual to confirm the exact filter style and replacement procedure for your unit.

Use these quick checks before ordering a replacement:

• Find the filter location: inside the fresh food compartment, in the base grille, or as an inline filter behind the refrigerator
• Read the old filter’s printed number (often on the end cap or label)
• Match the connection style: quarter-turn twist, push-button release, or 1/4-inch tubing inline
• Confirm you have a water filter installed (some units are “if equipped”)
• After replacement, flush water to clear air and carbon fines

This model’s water system guidance calls out different pressure ranges depending on whether a filter is used.

If your refrigerator does not have a built-in cartridge filter, an inline filter installed in the supply line near the refrigerator is a common setup. The manual’s water line section also recommends leaving extra tubing slack so you can pull the refrigerator out for service.

• Use a cold water supply line
• Leave extra coiled tubing behind the unit for movement
• Use proper compression nuts and ferrules on 1/4-inch tubing
• Check for leaks after turning the water back on

For step-by-step filter replacement tips, use how to replace the water filter in a Kenmore refrigerator.

Using the correct filter style for 79565002401 prevents leaks at the housing, protects the water inlet valve from debris, and keeps normal water flow for the dispenser and automatic ice maker.

Last updated: February 2026

On Kenmore bottom-mount refrigerator model 79565002401, water leaking from the bottom is usually caused by defrost water not draining correctly (a clogged or frozen defrost drain) or by a water supply connection issue for the icemaker. Start by checking for ice or debris in the drain path and signs of dripping near the water line.

• Look for a sheet of ice on the freezer floor or water under the crisper drawers (common with a blocked defrost drain).
• Check the drain pan area for overflow and confirm the pan is seated correctly.
• Inspect the water line connection and shutoff valve for slow drips.
• If the leak happens during/after defrost, listen for normal water draining into the pan (the manual notes water can run into the drain pan during defrost).
• If you have an icemaker, confirm the water supply line is not kinked or rubbing.

If you find the leak is related to door sealing or interior condensation, these model-matched parts are commonly involved:

• Refrigerator gasket assembly ADX73350922 (torn, warped, or not sealing evenly)
• Refrigerator door push-button switch 6600JB1010A (light staying on can add heat and increase condensation)
• Refrigerator defrost sensor assembly 6615JB2005C (defrost control issues can lead to heavy frost and drain freeze-ups)

A small leak can turn into ice buildup, warm temperatures, and compressor run time increases. Fixing the drain path or a slow water-line drip early helps protect flooring and keeps the freezer and fresh food sections cooling normally.

For the exact access steps, door alignment procedure, and the troubleshooting guide for model 79565002401, follow the 79565002401 owner's manual.

Last updated: February 2026

On your Kenmore 79565002401 bottom-mount refrigerator, the water dispenser stops working when water cannot reach the dispenser (shutoff closed, kinked or frozen line, clogged filter) or when the dispenser is not being enabled (door switch or control issue). Use the steps below; the 79565002401 owner's manual covers water line setup and troubleshooting.

• Confirm the household shutoff valve is fully open.
• Check the supply line behind the refrigerator for kinks or crushing.
• Replace the water filter if flow is weak or stopped; a clogged filter is the most common cause.
• Dispense water for 2 to 3 minutes total after a filter change to purge air.
• If the dispenser behaves differently with the door open vs. closed, suspect a door switch issue.

A frozen water tube inside the door can block dispensing.

• Raise the freezer temperature slightly for 24 hours.
• Warm the dispenser area gently with low heat and constant movement.
• Avoid repeatedly forcing the lever; fix the restriction first.

Restoring normal water flow prevents strain on the water inlet valve and helps the ice maker fill properly, so you avoid repeat no-dispense problems.

Last updated: February 2026
