Kenmore Elite 79047883604 electric oven Parts

Kenmore is a brand sold by Sears; the Kenmore Elite wall oven model 79047883604 is part of the 790-series that is widely associated with Frigidaire/Electrolux-built ovens. For model-specific identification details (model/serial plate location and documentation), use the owner's manual.

How to confirm who built your specific oven

We confirm the builder by matching the model prefix and the data on the serial plate.

• Check the model number format: 790 is the key identifier for this Kenmore Elite wall oven family.
• Locate the serial plate and record the full model and serial.
• Compare the recorded information to the documentation for your unit.
• Use the parts list for your model to see common OEM part families used on this platform.

Where to find the serial plate on model 79047883604

The Use & Care Guide includes a section for serial plate location.

What to look for	Why it matters
Model number (79047883604)	Confirms the exact Kenmore configuration
Serial number	Helps identify production run and compatible parts
Electrical rating info	Helps ensure safe, correct installation and service

Why it matters

Knowing the original manufacturer helps you choose compatible replacement parts (for example, heating and temperature-sensing components) and follow the correct service procedures for a Kenmore Elite electric wall oven.

Last updated: February 2026

To reset your Kenmore Elite wall oven model 79047883604, clear the control first (STOP/CLEAR), then restore power by turning the breaker off and back on; after power returns, set the clock and reprogram cooking functions as needed. See the reset and power-failure notes in the owner's manual.

The safest reset steps (control and power)

• Press STOP/CLEAR once to cancel a cooking cycle and clear most beeping or fault displays.
• If the control is still unresponsive, turn the oven circuit breaker OFF for 1 to 5 minutes.
• Turn the breaker ON.
• Set the clock; the oven will not program correctly until the time is set after an interruption.
• Try Bake again and confirm the oven heats normally.

If the display is beeping or shows an F code

The manual’s “Before you call” section recommends clearing the alarm first, then checking whether the fault returns.

What you see	What to do	What it means
Beeping with an F code	Press STOP/CLEAR to stop beeping and clear the display	A fault was detected; if it returns, service is typically needed
Display flashing after outage	Set the clock, then reprogram	Normal after power interruption
“Loc” / “Door locked”	Hold the Oven Lockout pad for 3 seconds to toggle	Control lockout is on, not a power problem

When “reset” really means “unlock”

If the oven won’t start but the control works, the Oven Lockout feature may be enabled. Hold the lockout pad for 3 seconds to return to normal operation (the door unlocks and the oven becomes operational again).

Why it matters

A proper reset protects the electronic control and prevents the oven from restarting unexpectedly after a power interruption. It also gets the control back into a programmable state (clock set, functions cleared).

Last updated: February 2026

For the Kenmore Elite wall oven model 79047883604, the installation guide shows two common size classes: 27-inch and 30-inch wall ovens. The overall product dimensions depend on which size class your specific unit is; use the dimension chart in the installation guide to match your oven to the correct measurements.

Product dimensions shown in the installation guide

The installation guide lists these overall product dimensions (not cabinet cutout):

• 27-inch wall oven: approximately 27 in wide, 24 7/8 in high, and 24 5/8 in deep
• 30-inch wall oven: approximately 30 in wide, 28 1/4 in high, and 24 1/2 in deep
• For double-oven configurations, the guide shows an overall height around 50 1/2 in (width and depth still follow the 27-inch or 30-inch class)

How to confirm which size applies to your 79047883604

Because the guide covers both 27-inch and 30-inch versions, we recommend matching your oven to the correct class using one of these checks:

• Measure the front frame width (left to right across the face)
• Compare your measurements to the 27-inch vs 30-inch chart in the guide
• Confirm whether you have a single oven or double oven setup
• If you are measuring for cabinetry, use the cutout dimensions section (different from product dimensions)

Quick comparison (overall product dimensions)

Oven class	Width	Height	Depth
27-inch wall oven	27 in	24 7/8 in	24 5/8 in
30-inch wall oven	30 in	28 1/4 in	24 1/2 in

Why it matters

Using the correct size class prevents fit issues and helps avoid installation problems like insufficient clearance, misaligned trim, or heat buildup from a tight cabinet opening. The installation guide also calls out clearance needs (such as space in front of the door) and support requirements.

Last updated: February 2026

PF on a Kenmore Elite wall oven model 79047883604 means power failure. It shows up after the oven is first powered on or when electrical power is interrupted; the display flashes “PF” until you clear it and reset the clock using the steps in the owner's manual.

How to clear PF and get the oven working again

• Press STOP/CLEAR to clear the PF message.
• Set the clock (the oven may not program correctly until the time is set).
• If the display returns to normal, test Bake at 350°F for a few minutes.
• If PF keeps coming back, check for a loose plug, tripped breaker, or a flickering circuit.
• If the control beeps and shows an F code after a power event, press STOP/CLEAR to stop the beeping and clear the code.

What usually causes PF

Cause	What you may notice	What to do
Brief outage or brownout	PF appears after lights flicker	Clear PF, reset clock
Breaker tripped or weak breaker	Oven goes dead, then PF returns	Reset breaker fully (OFF then ON)
Loose power connection	PF appears randomly	Check cord/terminal connections (power off)
Wiring issue at connection point	Intermittent power, heat discoloration	Inspect and repair wiring/connection

Why it matters

PF is not a cooking-mode failure by itself; it is the oven telling you it lost power. Clearing PF and resetting the clock restores normal operation, and repeated PF events point to a power supply problem that can also damage electronic controls over time.

Parts that can be involved when power is unstable

If you find signs of overheating or looseness at the power connection (power off at the breaker first), the connection hardware is a common fix area:

• Terminal block 5304409888 (power connection point)
• Wiring harness 318370303 (if wiring is damaged)

Last updated: February 2026
