Kenmore 110C62332511 electric dryer Parts

On the Kenmore 110C62332511 electric dryer, the AF code means restricted airflow. In practice, it points to a clogged lint screen, blocked vent duct, or a crushed or kinked vent that is preventing the dryer from moving air properly.

What to check first (fast airflow fixes)

• Clean the lint screen completely (wash off fabric softener residue if present, then dry it).
• Inspect the vent hose behind the dryer for kinks, crushing, or sagging.
• Check the exterior vent hood for a stuck flap, lint buildup, or a bird screen that is clogged.
• Make sure the vent run is as short and straight as possible (too many turns restrict airflow).
• Run a short timed heated cycle and confirm you have strong airflow at the outside vent.

Why AF matters

Restricted airflow makes clothes dry slowly and can cause overheating. When airflow is poor, safety thermostats can trip and the dryer may stop heating until the underlying venting issue is corrected.

Quick symptom guide

What you notice	Most likely cause	What to do
Long dry times	Vent restriction	Clean and shorten vent run; clear exterior hood
Dryer feels very hot	Poor exhaust airflow	Fix venting before replacing parts
AF returns quickly	Lint buildup in ducting	Clean the full vent path (dryer outlet to outside)

If airflow is good but the code keeps coming back

After confirming the venting is clear, the issue can be related to heat management components. For this model, common service parts include the dryer high-limit thermostat WP3977767 and the dryer thermal cut-off fuse kit 279816. Use the wiring and diagnostic guidance in the installation guide to follow safe checks and confirm proper operation.

Last updated: February 2026

For Kenmore electric dryer model 110C62332511, OEM part number 279838 is the dryer heating element. It is the electric heater that warms the air flowing through the drum so clothes dry properly; if the dryer tumbles but does not heat, this is a top suspect.

What part 279838 does

The heating element mounts in the heater housing and converts 240V power into heat during a cycle.

Common symptoms when it fails:

• Dryer runs but produces little or no heat
• Clothes take much longer than normal to dry
• Burning smell or visible break in the element coil
• Heater cycles erratically (often paired with airflow issues)

What to check before replacing the heating element

A failed heating element is common, but we also recommend checking these items because they can cause no-heat or overheating:

• House power: confirm the dryer has full 120/240V supply (a tripped breaker can leave the motor running on 120V only)
• Venting: crushed ducting or a clogged vent can overheat the heater circuit
• Thermal protection: a blown thermal cut-off can stop heat
• High-limit thermostat: can open if temperatures get too high

Related parts for this model (often replaced together)

What it affects	Part on this model	When it’s commonly needed
Heat production	Dryer heating element 279838	No heat, weak heat
Overheat protection	Dryer thermal cut-off fuse kit 279816	No heat after overheating or restricted vent
Temperature limiting	Dryer high-limit thermostat WP3977767	Overheating, cycling heat issues
Burned terminals	Dryer heating element wire kit 279457	Melted or loose heater connections

Why it matters

Using the correct OEM heating element for Kenmore 110C62332511 helps restore normal drying times and prevents repeat failures caused by mismatched fitment or poor electrical connections. For model-specific disassembly and safety steps, follow the installation guide.

Last updated: February 2026

To reset your Kenmore 110C62332511 electric dryer, we recommend doing a simple power reset: unplug the dryer (or turn off the breaker) for 1 minute, then restore power and try a cycle again. This clears many temporary control glitches.

Quick reset steps

• Unplug the dryer, or switch both dryer breakers OFF (electric dryers use 240V).
• Wait 60 seconds.
• Restore power.
• Close the door fully.
• Select a cycle and press and hold PUSH to START until you hear the drum moving.

If it still will not start after a reset

These checks solve the most common “dead” or “won’t run” complaints on this model:

• Confirm the door is fully closed; a failed door switch can prevent starting.
• Check the home electrical supply; electric dryers typically use 2 fuses or 2 breakers.
• Make sure you are getting the correct 240-volt supply.
• Press and hold the PUSH to START button long enough.
• If the dryer sat unused, restart and listen for normal initial thumping.

Parts that commonly affect starting

If power is good and the dryer still will not run, these parts are frequent suspects:

Symptom	What it points to	Example part for this model
No response when door closes	Door switch not closing circuit	Dryer door switch WP3406107
Hums but will not run	Motor issue or a stuck blower/drum	Drive motor 279827
Runs but airflow is weak	Blower wheel slipping or broken	Dryer blower wheel WP694089

Why it matters

A “reset” only helps when the control is confused by a brief power interruption. If the dryer will not run because of a door switch, motor, or power-supply problem, the fix is a targeted check and repair, not repeated resets. For model-specific operating steps and troubleshooting, use the owner's manual.

Last updated: February 2026

Kenmore electric dryer model 110C62332511 is a full-size 110-series platform dryer; the typical drum capacity for this style is about 6.5 to 7.4 cu. ft. For the exact rated capacity for your specific unit, check the specifications section in the 110C62332511 owner's manual.

How to find the exact capacity in the manual

Look for a section labeled “Specifications”, “Features”, or “Product information”.

• Search the PDF for capacity, cu. ft., or cubic feet
• If you see L (liters), convert to cubic feet using the table below
• Use the rating listed for your exact model number: 110C62332511
• If multiple model series are covered, match the series that includes 62332/C62332

Quick conversion: liters to cubic feet

If capacity is listed as	That equals about
184 L	6.5 cu. ft.
198 L	7.0 cu. ft.
210 L	7.4 cu. ft.

Capacity vs. dimensions (common mix-up)

Capacity is the inside drum volume; dimensions are for fit and installation. The 110C62332511 installation guide provides cabinet measurements and clearance guidance for placing the dryer in a closet or recessed area.

• Capacity: affects load size and drying performance
• Dimensions: affects whether the dryer fits your space and venting layout
• Clearances: affects airflow, noise, and service access

Why it matters

Loading to the right capacity keeps clothes tumbling freely, which improves airflow and drying results. Overloading increases dry time and heat stress; underloading can cause uneven drying and wrinkling.

Last updated: February 2026
