Whirlpool WGD49STBW2 gas dryer Parts

For your Whirlpool WGD49STBW2 gas dryer, we find cubic feet (capacity) by calculating the drum’s internal volume (width x depth x height) and converting cubic inches to cubic feet. Your WGD49STBW2 installation guide lists exterior dimensions, but capacity is based on the inside of the drum.

How to calculate dryer capacity (cubic feet)

1. Unplug the dryer (and shut off gas if you need to access internal areas).
2. Measure the inside of the drum in inches:
   • Drum diameter (inside wall to inside wall)
   • Drum depth (front inside lip to back inside wall)
3. Convert diameter to radius: radius = diameter ÷ 2.
4. Calculate drum volume in cubic inches (cylinder):
   • volume = 3.1416 x radius² x depth
5. Convert to cubic feet:
   • cubic feet = volume ÷ 1728

Quick example (using sample numbers)

Measurement	Example value
Drum diameter	27 in
Drum depth	20 in
Calculated volume	~11,450 in³
Capacity	~6.6 ft³

Tips for getting accurate measurements

• Measure inside-to-inside only; don’t include the front bulkhead or rear baffles.
• Take measurements in two spots and average them if the drum has contours.
• If you’re not opening the dryer, use the model’s documentation for guidance on access panels and safety steps in the WGD49STBW2 owner’s manual.

Why it matters

Knowing cubic feet helps us match your dryer to the right load size and cycle choices, and it can explain issues like long dry times when loads are consistently too large for the drum.

Last updated: January 2026

On a Whirlpool WGD49STBW2 gas dryer, an F2E2 code typically points to a user interface or control communication problem. We start by resetting power, then checking simple airflow and door-switch basics; if the code returns, the control panel or main control may need service.

Quick reset and safety steps

• Unplug the dryer (or switch off the breaker) for 1 minute, then restore power.
• If the code returns, unplug again before inspecting anything.
• For gas models, keep the area ventilated and avoid working near an active gas smell.

What to check next (most common causes)

• Stuck key or moisture on the console: Wipe the console dry; press each button once to confirm none are stuck.
• Door not registering closed: Make sure the door closes firmly and the latch engages; a failed door switch can trigger odd behavior.
• Loose wiring connection (console to control): If you are comfortable opening the console, reseat connectors per the WGD49STBW2 owner’s manual.
• Airflow restriction: A clogged vent can cause overheating and control issues; check the exhaust hose and outside hood for lint buildup.

Parts that commonly relate to symptoms

If the dryer will not start, stops mid-cycle, or the door status seems inconsistent, these parts are common suspects:

Symptom you notice	Likely area	Example part for this model
Dryer acts like door is open	Door circuit	Dryer door switch WP3406107
Dryer runs but airflow is weak	Venting or blower	Dryer blower wheel (inspect for lint, cracks)
Dryer overheats or shuts down	Airflow or thermal protection	Dryer thermal cut-off fuse kit

Why it matters

F2E2 is often a control-to-console communication issue; clearing it quickly prevents repeated cycle interruptions and helps you avoid unnecessary part swaps. Good venting also protects the burner system and helps drying times stay normal.

For model-specific access steps, wiring routing, and console removal details, use the WGD49STBW2 installation guide alongside the manual.

Last updated: January 2026

The most common problems we see on Whirlpool dryers like model WGD49STBW2 are no heat and won’t start or won’t tumble. In many cases, restricted venting causes overheating and trips safety parts, while normal wear can take out the belt, door switch, or burner components.

Most common symptoms and what usually causes them

• Dryer runs but no heat (gas dryer): gas supply valve closed, burner ignition issue, or a safety device opened from overheating
• Dryer won’t start: door not fully closed, start knob not held long enough, or a failed door switch
• Dryer runs but won’t tumble: broken belt or a seized drum support component
• Long dry times: lint screen clogged, exhaust vent or outside hood clogged, or load too large
• Unusual noises: items caught at drum edges, dryer not level, or normal gas valve clicking

Quick checks we recommend first (WGD49STBW2)

1. Clean the lint screen before every load (this is a top cause of long dry times).
2. Check airflow outside at the vent hood; you should feel strong air movement.
3. Confirm the dryer door closes firmly and the PUSH to START is pressed and held until the drum moves.
4. For gas heat issues, make sure the supply line valve is open.
5. If the dryer overheats or shuts down, inspect and clean the entire vent run.

Parts that commonly fix “won’t start” or “won’t tumble”

Symptom	Common fix	Example part for WGD49STBW2
Won’t start	Door switch	Dryer door switch WP3406107
Won’t tumble	Drum belt	Dryer drum belt 341241
Squealing, thumping, poor tumbling	Worn wear items	Dryer repair kit 4392065

Why it matters

A clogged vent can make a Whirlpool gas dryer dry slowly, run hot, and eventually open safety components. Fixing airflow first often prevents repeat failures and improves drying performance.

For model-specific operating and troubleshooting steps, use the WGD49STBW2 owner’s manual.

Last updated: January 2026
