Kenmore 79071442601 gas range Parts

A Kenmore gas range like model 79071442601 typically lasts 15 years with normal household use. Keeping burners clean, ensuring proper flame adjustment, and addressing ignition or temperature issues early helps you reach that lifespan; see the 79071442601 owner's manual for routine care guidance.

Most ranges reach their full service life when heat, gas flow, and ignition stay consistent.

• Heavy daily cooking shortens lifespan; light use extends it
• Grease and spills around burner heads can cause poor ignition and uneven flames
• Weak igniters can delay oven lighting and strain components
• Incorrect low-flame settings can cause burners to go out or soot
• Overheating from blocked airflow can stress controls and wiring

Use these habits to keep your Kenmore 79071442601 running reliably:

• Clean surface burner heads and caps regularly to keep ports clear
• Verify each surface burner lights promptly and the flame stays steady on LOW
• Replace a failed oven light promptly to avoid working “blind” around hot surfaces
• If baking seems off, check the oven temperature sensor and calibration steps in the manual
• Keep the area around the range clean and dry to reduce corrosion and electrical issues

These parts are frequently replaced during a range’s life:

A gas range often “fails slowly”; small issues like delayed ignition, unstable low flames, or temperature drift can increase cooking times and stress components. Catching those early helps you get the full 15-year lifespan.

Last updated: February 2026

To change a spark electrode igniter on your Kenmore gas range model 79071442601, we remove the burner cap and burner head, disconnect the electrode wire, swap the electrode into the orifice holder, then reassemble and test ignition (each burner should light within about 4 seconds after air is purged). See the 79071442601 installation guide for burner and igniter checks and safe setup steps.

• Turn all burner knobs to OFF and let the cooktop cool.
• Shut off the gas supply at the range shutoff valve.
• Unplug the range (or switch off the breaker) before touching wiring.
• Keep spills, cleaners, and debris out of the gas orifice holder opening.
• Keep burner caps and burner heads installed whenever burners are in use.

1. Lift off the burner grate, then remove the burner cap and burner head.
2. Locate the electrode at the burner; remove the retaining screw (if used on your burner style).
3. Carefully pull the electrode up enough to access the wire connection.
4. Disconnect the wire from the old electrode; connect it to the new electrode terminal.
5. Insert the new electrode into the orifice holder and secure it.
6. Reinstall the burner head and cap (alignment matters for proper lighting).
7. Restore power and gas; test ignition.

After restoring power and gas, push in and turn the knob to LITE. You should hear sparking; the selected burner should ignite when gas reaches it.

Your installation instructions describe adjusting the LOW flame setting using a thin-bladed screwdriver in the valve stem after removing the knob. Use the 79071442601 installation guide for the correct procedure and flame target.

A properly installed electrode and correctly seated burner head/cap help the burner light quickly, prevent delayed ignition, and keep flame size stable from LITE down to LOW.

Last updated: February 2026

On the Kenmore gas range model 79071442601, taking the top off typically means removing the cooktop surface so you can access burner heads, igniters, and the manifold area. We start by removing the grates and burner caps, then release any burner-base screws or front hold-down screws before lifting the top.

• Turn all burner knobs to OFF and let the range cool completely.
• Shut off the gas supply at the external manual shut-off valve.
• Unplug the range (or switch off the breaker) before touching wiring or igniters.
• Never use an open flame to check for gas leaks.
• If you smell gas: do not operate switches; follow the safety steps in the 79071442601 owners manual.

1. Remove the grates.
2. Lift off the burner caps.
3. Remove the burner heads/bases if your version uses screws to hold them down.
4. Look for screws at the front lip of the cooktop (under the front edge) or near burner bases; remove them.
5. Lift the cooktop from the front and support it (some tops hinge up; others lift off once released).
6. If the top is tethered by wiring (spark module/igniters), do not pull hard; set it on a protected surface.

Removing the cooktop the right way prevents cracked porcelain, stripped screws, and damaged spark igniter wiring. It also gives you safe access for cleaning spills, clearing clogged burner ports, or replacing parts like a range surface burner head 316212400.

Last updated: February 2026

On the Kenmore 79071442601 gas range, a bad igniter typically shows up as a burner that will not light, lights very slowly, or keeps sparking without ignition. For the oven, the igniter should glow and the burner should light within about 30 to 60 seconds; longer delays often point to a weak igniter.

• Surface burner: Turn the knob to LITE; you should hear sparking and the burner should light within about 4 seconds after air is purged from the gas line.
• Oven burner: Set BAKE; the igniter should glow like a light bulb and the burner should ignite within about 60 seconds.
• Watch the igniter: No glow (or a very dim glow) during an oven heat call usually indicates failure.
• Listen and smell: Repeated clicking with no flame, or a gas smell without ignition, indicates an ignition problem that needs attention.
• Check burner parts placement: Misaligned burner head/cap or a dirty orifice area can prevent lighting even when the igniter is working.

For model-specific lighting behavior and burner setup details, follow the steps in the installation guide.

If the oven is slow to light or will not light at all, the most common repair is replacing the oven igniter: frigidaire range oven burner igniter 5303935066.

If the surface burner will not light but you do hear sparking, also inspect and reseat the burner head and cap; a damaged head can be replaced with range surface burner head 316212400.

A weak igniter can delay ignition, cause uneven heating, and in some cases allow gas to flow without immediate ignition. Restoring normal ignition timing helps the range light reliably and heat consistently.

Last updated: February 2026

A Kenmore 79071442601 gas range oven is built around a gas burner and valve system that creates heat, plus ignition, temperature sensing, and door and lighting components that make baking and broiling safe and consistent. For diagrams and names used for your exact model, use the 79071442601 owner's manual.

• Oven burner: mixes gas and air and produces the bake flame.
• Hot surface igniter: glows, then triggers the gas valve to open so the burner lights.
• Oven gas valve: opens to release gas to the burner when the igniter is hot enough.
• Temperature sensor (probe): tells the control how hot the oven is.
• Oven control and overlay: lets you select bake/broil and manages temperature cycling.
• Oven door and seal: holds heat in; a worn seal causes heat loss and uneven baking.
• Oven light system: bulb and socket to illuminate the cavity.

When you set BAKE, current flows to the igniter and it glows. After about 30 to 60 seconds, the oven valve opens and the burner lights; the igniter cycles on and off to maintain temperature.

Knowing the core parts helps you troubleshoot faster. For example, a glowing igniter with no flame often points to a weak igniter or a gas valve issue, while inaccurate temperatures commonly trace back to the sensor.

Last updated: February 2026

On Kenmore gas range model 79071442601, the model and serial number are printed on the serial plate located on the right side of the oven front frame, typically inside the storage drawer or lower panel compartment. The exact spot is shown in the 79071442601 owner's manual.

Check these common label locations on 79071442601:

• Pull out the storage drawer and look on the right-hand front frame
• If your range has a lower panel instead of a drawer, check inside that compartment
• Look for a metal or foil identification plate (not a paper sticker)
• Record both the model number and serial number before ordering parts
• Also note any lot number or letter printed on the identification plate

1. Turn the oven off and let it cool.
2. Open the storage drawer (or remove the lower panel).
3. Use a flashlight and look along the right side of the oven front frame.
4. Write down the model and serial numbers exactly as shown.

The identification plate is more than a model tag; it helps us match the correct Kenmore parts and specifications for your exact build.

Kenmore model numbers can look similar across multiple gas range series. Using the exact model and serial from the plate prevents ordering the wrong igniter, oven probe, burner head, or control overlay.

Last updated: February 2026

On Kenmore gas range model 79071442601, the oven typically won’t ignite when the igniter is weak, the oven controls are not set correctly (including the clock/time-of-day), the range has no electrical power, or the gas supply/regulator valve is OFF. Use the normal 30 to 60 second ignition delay as your baseline.

• Confirm the range has power; electric ignition will not operate during a power failure.
• Set the clock/time-of-day; many ranges require it before the oven will run.
• Verify the oven is set to BAKE or BROIL correctly per the 79071442601 owner’s manual.
• Allow 30 to 60 seconds for the igniter to glow and the burner to light.
• Make sure the gas supply and regulator valve are ON (gas shutoff open).
• If the igniter glows but the burner never lights, the igniter is typically too weak to open the gas valve.

When you start BAKE, current flows to the igniter and it should glow like a light bulb. Once it gets hot enough, the oven gas valve opens and the burner lights.

• Frigidaire range oven burner igniter 5303935066: most common cause when the igniter glows but won’t light the burner.
• Frigidaire range oven gas valve 3203459: suspect if a known-good igniter still won’t open the valve.
• Oven probe 316233903: can cause temperature and cycling issues; less common for a total no-ignite.

A weak igniter can glow but still fail to draw enough current to open the oven gas valve, so the oven never lights. Checking power, settings, and the normal ignition delay prevents unnecessary part replacement.

Last updated: February 2026

If your Kenmore 79071442601 gas range bakes normally but will not broil, the most common causes are a broil setting or door-position issue, a weak/failed igniter for the broil burner circuit, or a gas supply/regulator problem affecting that burner. Use the broil steps in the 79071442601 owner's manual to confirm correct operation, then troubleshoot the ignition and gas flow.

• Confirm you selected BROIL (HI or LO) and started the cycle; some models let you adjust broil level in increments.
• Make sure the oven door is closed during broiling (an open door can prevent proper broil performance).
• Verify the range has gas supply and the gas regulator valve is ON.
• Check the broiler drawer is not being used for storage; stored items can interfere and create a hazard.
• If the unit was stored in cold conditions, let it sit above 32°F for several hours before use.

On many gas ranges, bake and broil use separate ignition and burner paths. If bake works, power and gas supply are generally present, but the broil side can still fail.

• If the oven burner ignition is weak, replacing the igniter is a common fix; for this model we list the frigidaire range oven burner igniter 5303935066.

Broil uses very high heat. When ignition is delayed or incomplete, you can get poor cooking results, excessive smoke, or unsafe flare-ups. Correct broil operation also depends on using the broiler pan and insert properly (no foil over the insert).

Last updated: February 2026
