Kenmore 79578302804 refrigerator Parts

On Kenmore refrigerator model 79578302804, adjust the two front leveling screws to level the cabinet and help the doors close properly. Turn the leveling screw clockwise to raise that side and counterclockwise to lower it; the screw stays in place and simply changes height (see the 79578302804 owner's manual).

Step-by-step: leveling the front of the refrigerator

1. Move the refrigerator into its final spot and plug it into a grounded outlet.
2. Open the doors and locate the two front leveling screws (left and right).
3. Tip the cabinet slightly (or have someone push gently against the top) to take weight off the screws.
4. Turn the leveling screw:
   • Clockwise: raises that side
   • Counterclockwise: lowers that side
5. Recheck door closing; the front should be slightly higher than the rear to aid door closing.
6. If doors still do not close easily, turn both leveling screws clockwise the same amount to tilt slightly more to the rear.

Quick checks while you adjust

• Rock the cabinet gently; it should not wobble.
• Confirm both fresh food doors close without needing a push.
• Keep the refrigerator pulled straight out when repositioning to protect flooring.

What “level” should look like

What you notice	What it usually means	What to do
Doors swing open or do not seal	Front is too low or cabinet is twisted	Raise the front slightly (clockwise)
Cabinet wobbles	One front corner is low	Raise the low side until stable
Doors close hard or misalign	Cabinet tilt needs fine-tuning	Adjust both screws in small, equal turns

Why it matters

Proper leveling reduces vibration, helps the door gasket seal, and improves temperature stability. On bottom-mount designs like the 79578302804, a slightly higher front also helps the doors self-close more reliably.

Last updated: January 2026

Kenmore bottom-mount refrigerator model 79578302804 is a full-size bottom-freezer design; most refrigerators in this class are about 33 inches wide, 30 to 34 inches deep, and 67 to 70 inches tall. For the exact cabinet and door-swing dimensions for your unit, use the 79578302804 owner's manual.

How to get the exact measurements (fast)

Use these steps so you measure the same way installers do:

• Measure width at the widest point (usually the cabinet, not the handles).
• Measure height from floor to the top hinge cover area.
• Measure depth two ways: cabinet-only and with doors/handles.
• Add clearance for door swing and air circulation behind the unit.
• If the refrigerator is not level, level it first; a tilt can change height readings slightly.

Typical size ranges for this model type

These ranges help you plan a space when you do not have the exact spec sheet in front of you.

Measurement	Typical range for 33-inch class bottom-mount	What can change it
Width	32 3/4 to 33 1/2 in.	trim, hinge covers
Height	67 to 70 in.	leveling legs, hinge cover
Depth	30 to 34 in.	handles, door style

Why it matters

Correct sizing prevents installation problems like doors hitting walls, drawers not pulling out fully, and restricted airflow that can raise temperatures and increase compressor run time.

Related help

If you are troubleshooting display messages while planning a move or reinstall, use Kenmore 795 model bottom freezer refrigerator error codes.

Last updated: January 2026

Common problems we see on Kenmore Elite refrigerators like model 79578302804 include warm temperatures from dirty condenser coils or airflow issues, frost buildup from door seal or defrost problems, water leaks from a clogged drain, and clicking or buzzing noises from the compressor start circuit.

Most common symptoms and what they usually mean

• Not cooling or weak cooling: condenser coils are dirty, vents are blocked, or a fan is not moving air.
• Freezer or refrigerator too warm: controls need adjustment; wait 24 hours between changes.
• Frost or ice buildup: door not sealing, door left open, or a defrost system issue.
• Water puddles or dripping: defrost drain is restricted or the drain tube is out of position.
• Doors not closing: unit not level, bins or shelves out of place, or gaskets sticking.
• Odd tastes or odors in ice: old ice, unwrapped food odors, or water quality issues.

Quick checks we recommend first (safe DIY)

Unplug the refrigerator before cleaning or repairs, and use these fast checks before replacing parts:

• Clean the condenser coils (dirty coils reduce heat transfer and make the compressor work harder).
• Confirm doors close fully; push bins and drawers all the way in.
• Clean the door gasket sealing surfaces; if gaskets stick, a thin coat of paraffin wax after cleaning helps.
• Make one temperature adjustment at a time; re-check after 24 hours.
• If you have water under the unit, inspect and clear the defrost drain path.

Parts that commonly relate to these issues on 79578302804

If symptoms point to a specific failure, these model-matched parts are common suspects:

Symptom	Likely area	Example model-matched part
Interior lights act up or door alarm behavior is odd	Door switch circuit	Lg refrigerator door switch 6600JB1010A
Water leaking inside or under refrigerator	Defrost drain path	Refrigerator drain tube 5251JA3003D
No water to dispenser or ice maker	Water supply valve	Refrigerator water valve AJU55759303
Clicking, hard starting, intermittent cooling	Compressor start circuit	Compressor start relay (match by model diagram)

Why it matters

Catching the root cause early protects food temperatures, reduces compressor run time, and prevents repeat issues like recurring frost, leaks, and door sealing problems.

For model-specific troubleshooting steps and care instructions (including condenser coil cleaning, door gasket care, and the troubleshooting guide), use the 79578302804 owner's manual.

Last updated: January 2026
