Where is the model number on a Kenmore side by side refrigerator?
On Kenmore model 79551733810, the model number is printed on the model and serial number label inside the refrigerator compartment. It is typically on a side wall near the front, or just behind the base grille area where the tech sheet is stored; see the owner's manual.
- Open the fresh food (refrigerator) door and check the left or right interior wall near the front edge
- Look around the crisper drawer area and lower side walls
- Check the ceiling area inside the refrigerator compartment
- If you do not see it inside, inspect behind the base grille at the bottom front (also where the tech sheet is referenced)
The label usually includes both identifiers:
- Model number (for example, 79551733810)
- Serial number (a longer code used to identify the specific unit)
We use the exact model number to match the correct Kenmore side-by-side refrigerator parts for your unit, such as a water filter, ice maker, or door bin. Even small model differences can change which parts fit.
| What you need | Where it’s found | What it’s used for |
|---|---|---|
| Model number | Model/serial label inside refrigerator compartment | Selecting correct replacement parts and diagrams |
| Serial number | Same label as model number | Identifying the specific production unit |
Last updated: February 2026
How to replace an ice maker in a side by side refrigerator?
To replace the ice maker in your Kenmore 79551733810 side-by-side refrigerator, we turn the ice maker off, shut off the water supply, remove the ice bin, swap the mounting and wiring to the new unit, then restore water and power and turn the ice maker back on. See the owner's manual for model-specific access and control details.
- Press the Ice Maker button to OFF and empty the ice bin.
- Shut off the household water supply to the refrigerator.
- Unplug the refrigerator (recommended before working around wiring and moving parts).
- Protect the floor with towels; a small amount of water can drip from the fill tube.
- Avoid contact with the ejector mechanism and heater area while the unit is plugged in.
- Remove the ice bin to access the ice maker.
- Remove the mounting screws holding the ice maker to the freezer wall.
- Disconnect the wire harness plug from the ice maker.
- Transfer any required parts from the old assembly to the new one (for example, a bail arm or small plastic pieces, if your replacement includes them separately).
- Install the new ice maker, reconnect the harness, and reinstall mounting screws.
- Reinstall the ice bin.
- Turn the water back on; check for leaks.
- Plug the refrigerator back in and set the Ice Maker button to ON.
The ice maker will not start making ice until the freezer is cold enough; it typically begins operating once the freezer reaches 15°F (–9°C) or below.
| Item | Normal expectation |
|---|---|
| First ice | After freezer reaches 15°F (–9°C) or below |
| Ice quality | Improves after the first batch or two |
| If no water is connected | Keep Ice Maker set to OFF to prevent damage |
- Confirm the Ice Maker button is set to ON.
- Verify water pressure is in a normal range for filtered systems (commonly 40 to 120 psi).
- Look for a frozen or blocked fill tube.
- If the dispenser and ice maker both have water issues, test the inlet valve; the lg refrigerator water inlet valve AJU72992601 is a common related part on this model.
A correct ice maker replacement prevents leaks, protects the ejector mechanism, and ensures the freezer reaches the temperature needed for reliable ice production.
Last updated: February 2026
Why is my Kenmore side by side refrigerator leaking water?
Water leaking from your Kenmore 79551733810 side-by-side refrigerator usually comes from a clogged defrost drain (water ends up inside the fresh food section) or a leak in the water supply system (water line, filter housing, or inlet valve). Start by identifying where the water shows up.
- Puddle under crisper drawers: defrost drain is iced over or clogged.
- Water on the floor in front: filter not seated, dispenser drip, or tubing connection.
- Water behind the refrigerator: water line connection or inlet valve seepage.
- Leak started after a filter change: filter not fully locked in, or filter head O-ring area is leaking.
- Unplug the refrigerator and dry the area so you can see fresh drips.
- Check the filter seating: remove and reinstall the filter firmly; look for cracks or water around the filter head.
- Inspect the water line: verify the tubing is not kinked and connections are snug.
- Clear a suspected defrost drain clog: thaw any ice and flush the drain opening with warm water until it drains freely to the pan.
| Where you see water | Likely cause | Next action |
|---|---|---|
| Under crisper drawers | Clogged/frozen defrost drain | Thaw and flush drain path |
| At filter cover area | Filter not seated or filter head leaking | Re-seat filter; replace head if leaking |
| Behind unit | Inlet valve or water line fitting seepage | Tighten fittings; replace valve if leaking |
- Lg refrigerator water inlet valve AJU72992601
- Refrigerator water filter head assembly ADQ36011715
- Refrigerator drain tube 5251JA3003D
Leaks can damage flooring and create ice buildup that restricts airflow, which can lead to warm temperatures and ice maker or dispenser problems.
For water line and care guidance specific to Kenmore 79551733810, use the owner's manual.
