Kenmore 11066842501 dryer Parts

For Kenmore dryer model 11066842501, replacing the heating element typically costs $50 to $120 for the part, and $150 to $350+ total if a technician does the repair (labor and service call included). If the dryer is not heating, we also check power supply and thermal fuses before replacing parts.

A “no heat” symptom is not always a bad element. The installation instructions for this style of dryer note that an electric dryer can have two household fuses or breakers, and both must be good for heat.

• Confirm the dryer is getting full power (both breakers on, cord seated)
• Run the dryer 5 minutes and check for heat, then stop the cycle
• Inspect and clear venting restrictions (poor airflow can overheat and blow safety fuses)
• Test the heating circuit safety devices (thermal cut-off, high-limit thermostat)
• If the drum turns but there is no heat, then test the heating element

If you are already opening the cabinet, it is smart to consider the safety parts that protect the heater circuit.

• Dryer element 279838
• Dryer thermal cut-off fuse kit 279816
• Dryer high-limit thermostat WP3977767
• Dryer operating thermostat WP3387134

A failed heating element is common, but restricted venting or a blown thermal cut-off can be the real cause of “no heat.” Fixing airflow and the safety devices helps prevent repeat failures and improves drying performance.

For wiring, venting, and electrical requirements specific to Kenmore 11066842501, follow the 11066842501 installation guide.

Last updated: January 2026

To hard reset your Kenmore dryer model 11066842501, disconnect power (unplug the dryer or switch the breaker off) for 1 to 5 minutes, then restore power and start a new cycle. This clears many temporary control or cycle issues and is the safest reset method.

• Turn the Cycle Selector to OFF.
• Unplug the dryer (or turn OFF the circuit breaker).
• Wait 1 to 5 minutes.
• Restore power.
• Close the door fully, select a cycle, then press PUSH TO START.
• If the dryer was mid-cycle, always select a new cycle before restarting.

For model-specific operating and restart instructions, follow the steps in the 11066842501 owner's manual.

A reset will not fix a failed safety device or an airflow problem. Use this quick checklist:

• Confirm the controls are set to a running position (not OFF).
• Push the Start button firmly.
• Verify power at the outlet; check the household fuse or breaker.
• Make sure the dryer door is fully closed and latching.
• Check that the vent is not crushed, kinked, or clogged.

Dryers rely on door switches, thermostats, and thermal cutoffs to prevent unsafe operation. If airflow is restricted, the dryer can overheat and shut down; cleaning the lint screen and ensuring proper venting often restores normal drying better than repeated resets.

Last updated: January 2026

For Kenmore dryer model 11066842501, the correct drum belt is the Dryer drum belt 341241, which is the belt size this model uses. Use your model’s parts breakdown in the 11066842501 owner's manual to confirm routing and access steps before ordering.

On this Kenmore dryer, the belt you want is identified by the part ID 341241 (manufacturer part number 8066065). That part ID is the most reliable way to match fit.

• Match by model number: 11066842501
• Match by part ID: 341241
• Replace if you see cracks, glazing, fraying, or the drum won’t tumble
• If the motor runs but the drum does not turn, the belt is a top suspect

If you are opening the cabinet, it often makes sense to service the wear items at the same time.

• Dryer drum belt 341241
• Dryer idler pulley (belt tensioner)
• Drum rollers and supports (if equipped)
• Lint buildup in the blower housing and vent path

Using the correct belt for 11066842501 keeps proper belt tension and drum speed. A belt that is close but not correct can slip, squeal, overheat, or come off the pulleys, which can lead to repeat failures.

Last updated: January 2026
