Kenmore 10672209201 refrigerator Parts

A fridge with the freezer on top is called a top-freezer refrigerator, also commonly called a top-mount refrigerator. Your Kenmore model 10672209201 is this style, with the freezer compartment above the fresh-food compartment and separate side-swing doors.

What “top-freezer” and “top-mount” mean

Both terms describe the same layout:

• Freezer compartment is on the top
• Refrigerator (fresh-food) compartment is on the bottom
• Two separate doors that open from the side
• Cold air circulates between sections through vents, so keeping vents clear helps temperatures stay stable

For model-specific features and layout details, use the 10672209201 owner's manual.

Why it matters when buying parts or troubleshooting

Refrigerator style affects where key components sit and how common problems show up (airflow, frost patterns, door sealing, and ice maker routing).

Style name	Freezer location	Common alternate name
Top-freezer refrigerator	Top	Top-mount
Bottom-freezer refrigerator	Bottom	Bottom-mount
Side-by-side refrigerator	Left side	Side-by-side

Quick tips that apply to top-freezer models

These are common best practices for Kenmore top-freezer units like model 10672209201:

• Do not block freezer or refrigerator vents with food packages
• Keep doors aligned and closing tightly to prevent moisture and temperature swings
• Expect normal operating sounds (gurgling, popping, fan airflow) during cooling and defrost
• Wrap foods tightly to reduce odor transfer between compartments
• If you have ice maker issues, confirm the water supply and inlet valve operation before replacing parts

Related DIY help

If you are troubleshooting a display or diagnostic issue on Kenmore 106-series units, use the Kenmore 106 model refrigerator error codes reference.

Last updated: January 2026

The Kenmore refrigerator model 10672209201 has a total capacity of 21.9 cubic feet. This number represents the combined storage space of the fresh food compartment and the freezer, and it helps you compare overall usable space across top-mount refrigerators.

How to use the 21.9 cu. ft. capacity

• Plan grocery storage: larger capacity supports bulk shopping and bigger platters.
• Compare models: cubic feet is the fastest way to compare overall size across brands.
• Set expectations: capacity is total volume; shelves, bins, and the ice maker reduce usable space.
• Match household needs: most families do well in the 18 to 22 cu. ft. range for a top-mount.

Quick reference: what “cubic feet” means

Spec	What it tells you	What it does not tell you
Total capacity (cu. ft.)	Overall interior volume (fridge + freezer)	Exact shelf layout, bin sizes, or door storage
Fresh food capacity	Space for refrigerated items	How tall items fit on your shelf configuration
Freezer capacity	Space for frozen items	How much is taken up by an ice bin or shelves

Where to confirm model details

We recommend checking the capacity listing and other specifications in the 10672209201 owner's manual. The model and serial label is typically located on the inside wall of the refrigerator compartment, which is also helpful when ordering Kenmore parts.

Why it matters

Capacity affects day-to-day convenience: it influences how much food you can store, how you organize items, and whether add-ons like an ice maker fit your needs. If you are adding or troubleshooting ice production, the ice maker assembly 4317943 is a common related component for this model.

Last updated: January 2026

Common problems we see on Kenmore top-mount refrigerators like model 10672209201 include warm temperatures from poor airflow, frost buildup from a defrost or door-seal issue, water or moisture problems tied to the water supply or filter, and unusual fan or compressor noises. Use the owner's manual troubleshooting section to match symptoms to the right checks.

Most common symptoms and what usually causes them

• Not cooling or weak cooling: blocked air vents, dirty condenser coils, failed evaporator fan motor, or sealed-system/compressor issues.
• Excessive frost or ice buildup: defrost system problem (heater, thermostat, timer/control) or a door gasket not sealing.
• Water leaks or puddles: clogged defrost drain, cracked water tube, or a leaking water inlet valve.
• Low water flow at dispenser (if equipped): water shutoff valve not fully open, kinked supply line, or a clogged/incorrectly installed filter.
• Door not closing well: refrigerator not level, sticky gaskets, or door alignment problems.

Quick checks we recommend before replacing parts

1. Confirm airflow: keep packages away from interior vents so cold air can circulate.
2. Check door sealing: clean the gasket and the cabinet surface it touches; if it sticks, apply a thin coat of paraffin wax after cleaning.
3. Verify water supply (if you have an ice maker or dispenser): make sure the shutoff valve is on and the supply line is not kinked.
4. Listen for fan noise: a grinding or squealing sound often points to the evaporator fan area.

Parts that commonly solve these issues on 10672209201

Symptom	Common part involved	Example part for this model
Warm fridge, noisy freezer area	Evaporator fan motor or fan blade	Refrigerator evaporator motor WPW10189703, fan blade WP2163777
Frost buildup, warm temps	Defrost thermostat (bi-metal)	Defrost bi-metal WP4387503
No ice or water leaks at back	Water inlet valve or water tube	Refrigerator inlet valve WPW10498990, refrigerator water tube W10823511
Door sweating, frost near door	Door gasket not sealing	Gasket panel (white) 2159061

Why it matters

Catching airflow, gasket, and water-supply problems early helps prevent food spoilage, reduces frost buildup, and avoids extra strain on the compressor and sealed refrigeration system.
