Kenmore 11078432700 dryer Parts

To hard reset your Kenmore dryer model 11078432700, we recommend disconnecting power (unplug the dryer or switch off the breaker) for about 1 minute, then restoring power and starting a cycle again. This clears many temporary control and cycle issues and is the safest reset method.

Hard reset steps (safe method)

• Turn the Cycle Selector to Off.
• Unplug the dryer (or turn both dryer breakers off if it is hardwired).
• Wait 60 seconds.
• Restore power.
• Close the door, select a cycle, then press PUSH TO START.
• If the dryer still will not run, follow the “Dryer will not run” checks in the 11078432700 owner's manual.

If the dryer still will not start after resetting

These checks match common “no start” causes and the troubleshooting guidance in the manual.

• Confirm the outlet has power; many dryers use 2 fuses or 2 breakers, so check both.
• Make sure the door fully closes; a failed door switch can prevent starting (see dryer door switch WP3406107).
• Verify the cycle control is not between settings; set it firmly into a cycle.
• Press and hold PUSH TO START for a couple seconds.
• If you have a gas dryer, confirm the gas shutoff valve is open.

Quick symptom-to-part guide

Symptom after reset	Most likely area to check	Example part for this model
Nothing happens when you press start	Door circuit, start switch	Dryer door switch, push-to-start switch
Motor hums but drum will not turn	Belt, idler pulley, drum support	Dryer drum belt, dryer idler pulley
Runs but shuts down or overheats	Airflow, thermostats	Dryer operating thermostat

Why it matters

A hard reset restores the dryer to a clean “power-up” state, but it will not fix a failed safety device or airflow problem. If the dryer will not run after a reset, power supply and door-switch issues are the fastest items to rule out.

Last updated: February 2026

On Kenmore dryer model 11078432700, the front panel comes off after power is disconnected and the top and front fasteners are removed. Once the door area screws are out, we lift the front panel up and off the lower retaining tabs, supporting any wiring as it separates.

Before you start (safety and access)

• Unplug the dryer (or switch off the breaker).
• For gas models, close the gas shutoff valve.
• Pull the dryer forward enough to work comfortably.
• Protect the finish; place a towel on top if you will rest the door or panel there (a method also used in the installation guide).

Steps to remove the front panel

1. Remove the lint screen (if it is on top) and any screws that may be under the lint screen housing (some versions use these).
2. Release and lift the top panel:
   • Insert a putty knife a few inches in from each front corner to release the spring clips.
   • Lift the top and support it.
3. Remove screws at the top of the front panel (inside the cabinet, near the left and right corners).
4. Open the door and remove the screws around the door opening that secure the front panel to the cabinet.
5. Disconnect the door switch wiring (if the harness connector is attached to the front panel).
6. Lift the front panel up and off the lower mounting tabs, then pull it forward and set it aside.

What you can service once the front is off

Symptom	Common area to inspect	Example part for this model
Drum not turning	Belt, idler pulley, motor	Dryer drum belt 341241
Loud squeal or thump	Rollers, idler, bearing surfaces	Dryer repair kit 4392065
Dryer stops when door moves	Door switch	Dryer door switch WP3406107

Why it matters

Removing the front panel correctly prevents cabinet damage and protects wiring connectors. It also gives direct access to the drum support system and drive components, which are the most common sources of noise and no-tumble problems.

For model-specific cabinet fastener locations and any variations, follow the 11078432700 manual.

Last updated: February 2026

If you’re on the Kenmore dryer parts page for model 11078432700, your dryer’s model number is 11078432700. On the appliance itself, we identify it by reading the model/serial label located at the top inside the dryer door well.

Where to find the model number on the dryer

We recommend checking these common locations in this order:

• Top inside the dryer door well (most common for Kenmore 110-series dryers)
• Inside the door opening on the cabinet frame
• On the back panel (less common)
• On a label near the lint screen housing (varies by design)

For the exact label location and how it’s formatted, use the 11078432700 owner's manual.

How to read the label (what to write down)

Record the full model number and serial number exactly as shown. This helps us match the correct parts list, wiring, and specifications.

What to capture	Example format	Why it matters
Model number	11078432700	Ensures correct part fit and diagrams
Serial number	Letters and numbers	Helps identify production series
Purchase date (if known)	Month/Day/Year	Useful for service history

Why the model number matters for parts and troubleshooting

Kenmore dryers can look similar across multiple series, but internal components can differ. Using 11078432700 helps us match the right items such as:

• Wear items like the dryer drum belt 341241
• Start and safety switches
• Heating and airflow components (thermostats, blower wheel)
• Gas ignition parts (on gas versions)

Quick tip if the label is hard to read

• Wipe the label gently with a damp cloth and dry it
• Use a flashlight at an angle to make faded print easier to see
• Take a close-up photo and zoom in

Last updated: February 2026
