Kenmore 11076722695 gas dryer Parts

Kenmore model numbers are read left to right: the first three digits identify the manufacturer, and the remaining digits identify the specific product series and feature set. For Kenmore gas dryer model 11076722695, the 110 prefix indicates a Whirlpool-built Kenmore dryer; the rest narrows down the exact configuration.

Where to find the model number on your dryer

We use the model and serial number plate to match the correct parts and documentation. On Kenmore dryers, it’s typically located:

• Inside the dryer door opening (on the door frame)
• On the cabinet opening behind the door
• Occasionally on the back panel

For the exact location and how it’s labeled, check the owner's manual.

How the number is structured (what each section means)

Kenmore model numbers generally follow this pattern:

• Prefix (first 3 digits): manufacturer code (who built it)
• Middle digits: product platform and series
• Last digits: engineering revisions, options, or production variations

Example using your model

Section	Example	What it tells you
Manufacturer prefix	110	Whirlpool-built Kenmore
Model identifier	767226	Series/platform and features
Variation/revision	95	Version or production variation

Why it matters when ordering parts

Two dryers can look similar but use different parts based on the full model number. Using the complete 11076722695 model number helps us match items like:

• Drum belt 341241 (if the drum won’t turn)
• Dryer door switch WP3406107 (if the dryer won’t start when the door is closed)
• Dryer valve coil kit 279834 or igniter 279311 (common gas heat system service parts)

Quick tips to avoid mix-ups

• Use the full model number, not just “Kenmore 110”
• Match letters and digits exactly (no missing or swapped numbers)
• If you’re checking a part, compare the symptom to the troubleshooting section in the owner's manual

Last updated: February 2026

To test the temperature switch (thermostat) on your Kenmore gas dryer model 11076722695, we use a multimeter to check for continuity at room temperature, then verify it opens or closes as the switch warms or cools (depending on the switch type). Always disconnect power before testing.

Safety first (gas dryer)

Before you access or test any temperature switch:

• Unplug the dryer from the grounded outlet
• Shut off the gas supply valve
• Let the dryer cool completely
• Work in a well-ventilated area
• If you smell gas at any point, stop and contact Sears PartsDirect support

For access panels and component locations, follow the disassembly guidance in the owner's manual.

What you need

• Digital multimeter with continuity (beep) and ohms settings
• Small nut driver or screwdriver (panel screws vary)
• Needle-nose pliers (for tight wire terminals)

How we test a dryer temperature switch (continuity test)

1. Disconnect power (unplug) and access the switch.
2. Label and remove wires from the switch terminals (pull on the connector, not the wire).
3. Set the meter to continuity (audible beep) or the lowest ohms range.
4. Touch one probe to each terminal on the switch.

Interpreting results

Most dryer thermostats and thermal switches behave like this at room temperature:

Switch condition	Typical meter reading	What it means
Closed (normal)	Beep or ~0 to 1 Ω	Switch is passing current
Open	No beep or OL/infinite	Switch is not passing current

Heat-response check (quick functional confirmation)

Some temperature switches are designed to change state at a set temperature.

• Warm the switch body gently (hair dryer on low, a few inches away)
• Watch for the reading to change state (closed to open, or open to closed)
• Let it cool and confirm it returns to its normal state

Why it matters

On model 11076722695, temperature switches help regulate drum temperature and protect against overheating. A failed switch can cause no heat, overheating, or short cycling, which also affects drying time and fabric care.

Last updated: February 2026

Yes. For your Kenmore gas dryer model 11076722695, the practical “reset” is a power reset: turn the dryer off, unplug it (or switch the breaker off) for about 1 minute, then restore power and start a cycle normally. Use the steps in the owner's manual to restart safely.

Quick reset steps (safe and effective)

• Turn the Cycle Selector (timer) to OFF.
• Unplug the dryer (or turn the circuit breaker OFF).
• Wait 60 seconds.
• Restore power.
• Close the door firmly.
• Select a cycle and press PUSH TO START.

If it still will not start after a reset

These checks match the most common “won’t run” causes for this style of Kenmore dryer:

• Make sure the door is fully closed; opening the door stops the dryer.
• Confirm the timer is set to a dry setting (not between positions).
• Press and hold PUSH TO START firmly.
• Check the house fuse or breaker (a tripped breaker can look like a dryer failure).
• If the door feels loose or the dryer stops when you bump the door, test/replace the dryer door switch WP3406107.

What “reset” means on this model

This model uses a mechanical timer and standard start circuit, so “resetting” typically means restoring power and re-setting the controls.

Situation	Best reset/action	Why it works
Dryer is unresponsive	1-minute power reset	Clears a stuck control state and restores power to the start circuit
Dryer stops when door opens	Close door, press PUSH TO START	Door switch interrupts the motor circuit
Timer was moved mid-cycle	Turn timer to OFF, reselect cycle	Ensures controls are in an ON position

Why it matters

A proper reset helps you avoid unnecessary parts replacement and gets you back to a known-good starting point (door closed, timer set, start pressed). If the dryer still will not run, the next step is isolating whether the issue is power, door switch, or a drive component.

Last updated: February 2026

If your Kenmore gas dryer model 11076722695 has power but will not run when you press PUSH TO START (with the door fully closed and the timer set to a drying cycle), the start switch is a prime suspect. Confirm it with a multimeter continuity test.

Quick checks first (no tools)

These match common “will not run” causes for this model.

• Set the cycle selector (timer) to an ON dry setting, not OFF
• Close the door firmly; the dryer will not start with the door open
• Press PUSH TO START firmly
• Check the house fuse or breaker (use a time-delay fuse if applicable)
• Clean the lint screen and make sure airflow is not restricted

For the correct start procedure and control descriptions, use the owner's manual.

How we test the start switch (continuity)

1. Unplug the dryer; shut off the gas supply valve.
2. Access the start switch in the control console.
3. Label and remove the wires from the switch terminals.
4. Set your meter to continuity (or lowest ohms).
5. Check readings:
   • Button not pressed: open (no continuity)
   • Button pressed: closed (continuity)

Interpreting results

Meter result	Meaning	What to do
No continuity when pressed	Contacts not closing	Replace the switch
Continuity all the time	Switch stuck closed	Replace the switch
Changes correctly	Switch OK	Check door switch, timer, motor circuit

Parts that can mimic a bad start switch

• Door interlock: dryer door switch WP3406107
• Timer not sending power: dryer timer WP3976577
• Motor issue (hums or won’t run): motor 279827

Why it matters

Testing prevents replacing the wrong part; a start switch is usually a simpler fix than a timer or drive motor.

Last updated: February 2026
