Kenmore 59679533019 refrigerator Parts

For Kenmore model 59679533019, match the water filter to your exact model number and the filter style it uses. This model’s compatible replacement is the Kenmore refrigerator water filter (9084) EDR4RXD1, so buying that filter ensures proper fit, water flow, and filtration performance.

Quick ways to confirm you have the right filter

• Check the model number on the rating label inside the fresh food compartment: it must read 59679533019.
• Match the filter ID to the model’s parts list: EDR4RXD1.
• Compare the old filter’s printed ID (if readable) to EDR4RXD1.
• If the filter will not seat or lock in, stop and re-check the filter ID before forcing it.
• If you recently replaced the filter head, confirm the head matches the filter style used by this model.

What to buy for model 59679533019

What you need	Correct match for this model	When to consider it
Refrigerator water filter	EDR4RXD1	Routine replacement, bad taste/odor, slow dispensing
Refrigerator water filter head	W11346623	Filter will not lock in, leaks at the filter area, damaged housing

Why it matters

Using the correct Kenmore refrigerator water filter helps prevent leaks, protects the water inlet valve and dispenser flow, and keeps ice and drinking water tasting clean. A mismatched filter can cause poor fit, restricted flow, or bypass issues.

Helpful tip for replacement

After installing a new filter, dispense and discard several batches of water to clear air and carbon fines. For step-by-step guidance, use how to replace the water filter in a Kenmore refrigerator.

Last updated: February 2026

Yes. We still carry replacement parts for Kenmore refrigerators, including the Kenmore 59679533019 bottom-mount refrigerator. You can match parts by model number and then choose the exact component you need, such as a water filter, door gasket, control board, or evaporator fan motor.

How to find the right part for model 59679533019

Use your model number (59679533019) to stay on the correct parts list, then confirm the part by name and ID.

• Find the symptom or the broken item (leak, warm fridge, torn seal, no ice).
• Match the part name and part ID to your parts list.
• Check whether you need a left or right door part (gaskets and panels are side-specific).
• Compare your original part’s label numbers to the listing when possible.
• Order the part and keep your model number handy for reference.

Commonly replaced Kenmore 59679533019 parts we stock

Here are examples of parts available for this model:

What you’re fixing	Part you may need	Part ID
Bad taste or slow water flow	Kenmore Refrigerator Water Filter (9084)	EDR4RXD1
Frosty or warm fresh food section	Refrigerator Evaporator Fan Motor	WPW10128551
Door not sealing, moisture, frost	Whirlpool Refrigerator Door Gasket (gray)	W10443320
No water to dispenser or ice maker	Refrigerator Water Inlet Valve Assembly	WPW10420083

Helpful part links for this model:

• Kenmore refrigerator water filter (9084) EDR4RXD1
• Whirlpool refrigerator door gasket (gray) W10443320

Why it matters

Kenmore refrigerators use model-specific parts. Ordering by the exact model number (59679533019) helps ensure proper fit, correct electrical connections (for items like an electronic control board), and reliable sealing and cooling performance.

DIY help for common Kenmore refrigerator needs

If you’re replacing a filter, our guide walks through the typical steps and what to expect after installation: how to replace the water filter in a Kenmore refrigerator.

Last updated: February 2026

To tell what model Kenmore refrigerator you have, we look for the model/serial tag on the cabinet (not on a removable drawer). On Kenmore refrigerators like model 59679533019, it’s usually inside the fresh food section on a side wall or ceiling, or behind the toe grille (kick plate) at the bottom front.

Where to look first (fastest checks)

• Inside the refrigerator compartment on the left or right side wall
• On the ceiling of the fresh food compartment
• Behind or beside the crisper drawers (check the cabinet wall after pulling drawers out)
• Behind the toe grille (kick plate) at the bottom front
• On the back exterior panel near the lower area

What the model number looks like

Kenmore model numbers are typically a long number string (often 10 to 12 digits). For example, 59679533019 is a Kenmore bottom-mount refrigerator model number.

What you find	What it’s used for	Why you need it
Model number	Identifies the exact design	Ensures parts diagrams match your refrigerator
Serial number	Identifies the production unit	Helps confirm version changes and compatibility
“596” prefix (common)	Indicates the manufacturing source family	Helps narrow down correct parts and procedures

Tips if the sticker is hard to read

• Take a clear photo with your phone and zoom in
• Wipe the label gently with a damp cloth (do not soak it)
• Copy the full number exactly, including any leading zeros
• If a drawer blocks the label, remove the drawer and look at the cabinet wall behind it

Why it matters

Using the correct model number prevents ordering the wrong parts (filters, gaskets, control boards) and helps you match the right diagrams for your exact Kenmore refrigerator.

If you’re identifying the model so you can replace a common maintenance item, the parts list for this model includes the Kenmore refrigerator water filter (9084) EDR4RXD1.

Last updated: February 2026

If your Kenmore 59679533019 bottom-mount refrigerator isn’t cooling and you hear repeated clicking, the compressor may be failing, but many “bad compressor” symptoms are actually caused by airflow, defrost, or control issues. We confirm compressor trouble by checking temperatures, fan operation, and the start/run behavior.

Quick signs that point toward a compressor problem

• Fridge and freezer are both warm, even though the unit runs often
• You hear a click every few minutes (start device tries, then trips off)
• The compressor is very hot to the touch after running attempts
• You don’t hear the normal steady compressor hum, only brief tries
• Frost pattern looks abnormal (little to no frost on the evaporator when running)

Rule out common look-alikes first (most important)

Before blaming the compressor, check these high-frequency causes of poor cooling:

• Evaporator fan: If it’s not moving air, the refrigerator warms up even with a good sealed system. Consider the refrigerator evaporator fan motor WPW10128551 if the fan is noisy, stalled, or intermittent.
• Temperature sensing: A bad sensor can misread temps and cause odd run times. The refrigerator thermistor W10316760 is a common fix for inaccurate temperature control.
• Control issues: A failing board can prevent proper compressor operation. If diagnostics point there, the refrigerator electronic control board WPW10317076 is one of the control options listed for this model.
• Condenser airflow and cleanliness: Dirty coils or blocked airflow can mimic sealed-system trouble.

What you can safely check at home

1. Set controls to normal (not warmest) and give it 24 hours.
2. Listen at the back: steady hum (running) vs. click and silence (failed start).
3. Check freezer back wall: heavy frost suggests a defrost/airflow issue, not a compressor.
4. Verify the evaporator fan runs when the door switch is held closed.

Symptom-to-likely-cause guide

What you notice	More likely cause	Compressor likely?
Clicking every few minutes, no cooling	Start/run problem or compressor locked	Medium to high
Freezer cold, fridge warm	Damper/airflow issue	Low
Heavy frost on freezer back wall	Defrost failure	Low
Warm everywhere, fans run, long run time	Sealed system or compressor	Medium

Why it matters

Compressors are part of the sealed system and are more complex to diagnose than items like a thermistor, fan motor, or control board. Ruling out airflow and control problems first prevents unnecessary, expensive repairs.

Last updated: February 2026

Water at the bottom of your Kenmore 59679533019 bottom-mount refrigerator is usually caused by a clogged or frozen defrost drain, a drain pan that is out of position or cracked, or a door gasket that is leaking warm air and creating excess condensation. Fixing the drain path solves most leaks.

Most common causes (and what to check first)

• Defrost drain clogged: Water from defrost cannot flow to the drain pan, so it spills into the fresh food section and runs down.
• Defrost drain frozen: Ice blocks the drain hole and causes overflow during defrost.
• Drain pan problem: The pan can be shifted, overflowing, or cracked.
• Door gasket not sealing: Warm, humid air enters, creating heavy condensation and water pooling.
• Water system leak (if you have an ice maker or dispenser): A loose connection or valve seep can drip and track to the bottom.

Quick troubleshooting steps we recommend

1. Unplug the refrigerator and remove items from the bottom shelves/crispers.
2. Look for ice or debris at the drain trough under the evaporator cover (rear interior panel). Melt ice with warm water.
3. Flush the drain with hot water using a turkey baster until it flows freely to the pan underneath.
4. Inspect the door seal for gaps, tears, or areas that do not grip paper when the door is closed.
5. Check for water supply leaks behind the unit; look for slow drips at the valve and tubing.

Parts that commonly fix bottom leaks

If you find a specific failure, these parts on this model’s parts list are common solutions:

Symptom you see	Likely issue	Part to consider
Puddle inside fridge bottom after defrost	Drain backing up (often from icing)	(Clear the drain first; parts usually not needed)
Water dripping from back/bottom near supply line	Valve seep or internal leak	Refrigerator water inlet valve assembly WPW10420083
Heavy condensation, water near door edge	Poor seal letting humid air in	Refrigerator door gasket W10443320 or refrigerator door gasket W10830162

Why it matters

A recurring leak can lead to ice buildup, temperature swings, and water damage under the refrigerator. Clearing the defrost drain and restoring a tight door seal prevents repeat puddles and helps the evaporator fan and cooling system run normally.

For step-by-step DIY guidance that applies to many Kenmore refrigerators, use our article how to get rid of refrigerator puddles.

Last updated: February 2026
