On a Kenmore dryer model 11064952300, a blown thermal fuse commonly shows up as a dryer that will not run at all, or a dryer that tumbles but has no heat (electric models can still tumble if one house breaker trips). The sure way to know is a continuity test with a multimeter after disconnecting power.

Quick symptoms to look for

• Dryer will not start even though the door is closed and a cycle is selected
• Dryer runs but produces no heat (especially on electric dryers)
• You find the exhaust vent is restricted or the lint screen is heavily clogged (often the root cause)
• The problem appeared suddenly, not gradually

Confirm it with a multimeter (best test)

1. Unplug the dryer or shut off the breaker(s).
2. Access the fuse location using the steps in the 11064952300 owner's manual.
3. Remove at least one wire from the fuse terminal.
4. Check continuity across the fuse.

How to read the result

Meter result	What it means	What to do next
Beep or near 0 ohms	Fuse is good	Keep troubleshooting (door switch, timer, motor circuit, power supply)
No beep or OL/infinite	Fuse is blown	Replace the fuse and fix the airflow restriction

What usually causes the thermal fuse to blow

A thermal fuse is a one-time safety device; it opens when the dryer overheats. Overheating is usually caused by poor airflow.

• Clean the lint screen and confirm it is not damaged (a torn screen can let lint into the duct)
• Check the exhaust duct for kinks, crushing, or heavy lint buildup
• Make sure the outside vent hood opens freely
• Avoid long vent runs and excessive elbows when possible
• If the dryer has no heat, also confirm both household fuses/breakers are good (electric dryers often use two)

Related parts that can mimic a “blown fuse” symptom

If the dryer will not run, these parts can cause similar symptoms:

• Dryer door switch WP3406107 (dryer thinks the door is open)
• Dryer timer WP3976576 (cycle power not being sent correctly)

Why it matters

Replacing a thermal fuse without correcting the venting problem often leads to the new fuse blowing again. Restoring proper airflow helps the dryer heat correctly, dry faster, and reduces overheating.

Last updated: February 2026

Your Kenmore dryer’s model number is printed on the model and serial number label; on Kenmore model 11064952300, that label is located at the top inside the dryer door well. Once you have the full model number, we can match the correct parts, diagrams, and specifications.

Where to find the model number label

Check these common Kenmore dryer locations in this order:

• Top inside the dryer door well (most common for Kenmore 110-series dryers)
• Inside the door opening on the cabinet frame
• On the back panel of the dryer
• Near the lint screen housing (varies by design)

For the exact label location and how it’s shown for this dryer, use the 11064952300 owner’s manual.

How to read a Kenmore model number (quick guide)

Kenmore model numbers often start with a 3-digit prefix that helps identify the manufacturer family. For example, many Kenmore dryers that start with 110 are built on a Whirlpool-manufactured platform, which helps when cross-referencing parts like a heating element, idler pulley, or drum support roller.

What you see on the label	What it means	Why it matters
Full model number (example: 11064952300)	Exact dryer identity	Ensures correct parts fit and wiring matches
Serial number	Unique unit identifier	Helps with production run details and service history
Purchase date (your record)	When you bought it	Useful for maintenance planning

Why the exact model number matters for parts

Even small model-number differences can change the correct part for heating, tumbling, or starting. When you confirm 11064952300, you can confidently choose model-matched parts such as:

• Dryer heating element WP3387747 for no-heat symptoms
• Dryer door switch WP3406107 for a dryer that will not start when the door is closed
• Support WPW10314173 for rumbling or thumping from worn drum rollers

Why it matters

Using the exact Kenmore model number prevents ordering the wrong component and avoids repeat repairs, especially for common wear items like the heating circuit, drum support system, and door safety switch.

Last updated: February 2026

A Kenmore dryer like model 11064952300 typically lasts 13 years with normal household use. Consistent vent cleaning, correct installation, and replacing wear items (belt, rollers, idler pulley) on time are what most often determine whether it reaches that full service life.

What affects lifespan the most

• Airflow and venting: Restricted exhaust overheats the heater and thermostats.
• Load size: Chronic overloading strains the drive motor and drum support system.
• Maintenance frequency: Lint buildup shortens the life of the blower wheel and heating circuit.
• Wear parts: Drum support components and the belt are designed to wear before major parts.
• Electrical supply: Loose terminal connections can cause heat damage and intermittent operation.

Maintenance checklist (high impact, low effort)

Use the schedule in your owner's manual as your baseline; these steps are the biggest lifespan boosters.

• Clean the lint screen before every load.
• Inspect and clean the full vent run regularly (dryer outlet to exterior hood).
• Keep the dryer level to reduce drum and belt wear.
• Stop using the dryer if you smell burning; check for lint blockage and overheating.
• If drying times increase, address airflow first before replacing parts.

Common “end-of-life” symptoms and likely causes

Symptom	Most common cause	Parts often involved
Long dry times, hot cabinet	Vent restriction	Exhaust ducting, lint screen housing
No heat	Failed heater or safety cut-off	Dryer heating element WP3387747, thermal cut-off kit
Squealing or thumping	Worn drum support parts	Dryer repair kit 4392067, idler pulley
Won’t start	Door switch or start switch	Dryer door switch WP3406107, start switch

Why it matters

A dryer that is running hot or taking too long to dry is not just inconvenient; it accelerates wear on the heating element, operating thermostat, and motor. Correct venting and routine lint removal are the fastest way to protect the 13-year lifespan.
