On the GE DDT595SGJ5BB dishwasher, most error codes clear after a control reset: press and hold Start/Reset for about 3 seconds to cancel the cycle, then restore normal operation by starting a new cycle. If the code returns, fix the underlying issue before resetting again using GE electronic dishwasher error codes.

• Cancel/Reset: Press and hold Start/Reset for about 3 seconds.
• Power reset: Turn the dishwasher off at the breaker for 5 to 10 minutes, then turn it back on.
• Clear a stuck float: Remove any debris around the float area inside the tub so it can move freely.
• Check the door closure: Make sure the door closes firmly and latches.
• Start a fresh cycle: After the reset, run a short cycle to confirm the code stays cleared.

An error code usually means the control detected a problem (drain, fill, heating, or wash performance). Address the symptom first, then reset.

Clearing the code gets you running again, but the dishwasher will often re-post the same code if the root cause is still present. Fixing the underlying drain, heat, or wash issue prevents repeat shutdowns and protects the control.

Last updated: January 2026

For the GE DDT595SGJ5BB dishwasher, the most common problems we see are not draining, poor cleaning, not drying, leaking, and not starting. These issues usually trace back to blocked spray arms or filters, a door latch problem, a drain restriction, or an electrical/control issue.

• Dishwasher won’t start: door not fully latched, failed latch switch, or a control/UI issue
• Not draining: kinked/clogged drain hose, blocked pump area, or a weak drain pump
• Not cleaning well: clogged spray arm jets, low water fill, or circulation/diverter problems
• Not drying: heater circuit issue, venting problem, or cycle/option selection
• Leaking: door gasket wear, loose hose connections, or oversudsing from wrong detergent
• Dead or glitchy controls: power interruption, moisture at the control area, or board failure

1. Reset power: turn the breaker off for 1 minute, then back on.
2. Confirm the door latches firmly and the tub isn’t overpacked.
3. Inspect spray arms for clogged holes and free spinning.
4. Check the drain path: sink/disposer connection, high loop/air gap, and hose kinks.
5. Run hot water at the sink for 30 to 60 seconds before starting a cycle.

If the display shows a code or blinking pattern, use our GE electronic dishwasher error codes reference to match the code to the likely failure area (drain, fill, heating, or control).

Dishwasher problems often start as a simple restriction (spray arm jets, drain hose routing) and then turn into repeat wash failures, odors, or standing water. Catching the root cause early helps protect the circulation pump, heating circuit, and control board.

Last updated: January 2026

The model number for your GE dishwasher is printed on the appliance’s rating label. On most GE built-in dishwashers like model DDT595SGJ5BB, that label is found along the tub rim where the door closes; open the door and look around the left or right edge.

Check these common label locations (in order):

• Along the tub opening (top edge or side edge) visible when the door is open
• On the left or right side wall of the tub, near the front
• On the inner door edge (not the outer decorative panel)
• Behind the toe-kick area (lower front panel) if the label is not on the tub rim

We recommend recording the full model and serial information exactly as shown.

• Model number (example format: DDT595SGJ5BB)
• Serial number
• Any suffix letters or revision codes
• Electrical ratings (helpful for troubleshooting)

GE often uses similar-looking dishwasher platforms with different racks, controls, and wash systems. Using the exact model number helps us match the correct parts the first time, such as the dishwasher spray arm, lower WD22X33499 or the configured machine control board WD21X32163.
