Frigidaire FFEF3018LBB electric range Parts

Yes. For your Frigidaire electric range model FFEF3018LBB, looking up parts by the full model number is the most reliable way to match the correct replacement part, diagrams, and variations by color or feature set; it prevents ordering a similar looking part that will not fit.

Where to find the model number on FFEF3018LBB

Your range’s model and serial information is recorded from the serial plate. On this style of Frigidaire range, the serial plate is typically located:

• In the storage drawer area (open the drawer and look for the plate)
• Behind the lower front panel (some versions)
• In the use and care documentation for reference and recordkeeping

For model-specific locations and product record details, use the FFEF3018LBB owner’s manual.

How we recommend searching parts by model number

Use the exact model number exactly as shown on the data plate (letters and numbers matter). Then narrow by the symptom or the part category.

• Start with the full model number: FFEF3018LBB
• Choose the system you are repairing (cooktop, oven, controls, wiring)
• Match the part by part ID/part number and description
• Confirm the part’s position using the exploded-view diagram
• If your range has multiple element sizes, verify which burner or oven function is affected

Common FFEF3018LBB parts customers look up

These are examples of model-matched parts that are commonly searched when troubleshooting heating or control issues:

Symptom	Common part to check	Example part for this model
Oven will not bake or bakes unevenly	Bake element	Frigidaire range bake element 316075103
Oven temperature seems inaccurate	Oven temperature sensor	Frigidaire range oven temperature sensor 316490000
Surface element will not heat	Surface element control switch	Frigidaire range surface element control switch 316436001
Oven light is out	Appliance light bulb	Appliance light bulb, 40-watt 316538904

Why it matters

Frigidaire ranges often have multiple configurations under similar model families (different cooktop element sizes, control styles, and wiring). Searching by FFEF3018LBB ties your parts list to the correct configuration so the replacement fits, mounts correctly, and connects safely.

Last updated: February 2026

For your Frigidaire electric range model FFEF3018LBB, the model number is printed on the appliance serial plate (rating plate). On this range, the serial plate is located in the storage drawer area on some models, or behind the lower front panel on some models.

Where to find the model and serial plate

Check these locations in order:

• Pull the storage drawer out and look around the drawer opening and frame.
• If your range has a lower front panel (kick plate) instead of a drawer, remove that panel and look behind it.
• Look for a label that includes Model and Serial.
• Use a flashlight and copy the full character string exactly.

For the model-specific “serial plate location” note and other identification details, use the FFEF3018LBB owner’s manual.

What to write down (and common copy mistakes)

Record these items before ordering parts or scheduling service:

• Model number (example format: letters plus numbers)
• Serial number
• Electrical rating (volts/amps)

Quick reference table

Item on the plate	What it’s used for	What to avoid
Model number	Ensures correct part fit	Mixing up O and 0, I and 1
Serial number	Helps match production variations	Dropping the last digit
Electrical rating	Confirms power requirements	Copying only voltage, not the full rating

Why it matters

Frigidaire ranges can look alike across similar series, but parts such as the range bake element 316075103 or the range oven temperature sensor 316490000 can vary by model and production run. Using the exact model number prevents wrong-part orders and speeds up troubleshooting.

Last updated: February 2026

On the Frigidaire FFEF3018LBB electric range, we reset the oven door lock by canceling the lockout feature at the control: press Clear/Off and hold for 3 seconds until the control unlocks the door (allow about 15 seconds for the motorized latch to move). See the steps in the FFEF3018LBB owner's manual.

Quick reset steps (most common)

• Make sure the oven is not running a bake, broil, or clean cycle.
• Press and hold Clear/Off for 3 seconds.
• Watch the display for “Loc” and the Door Locked light behavior.
• Wait about 15 seconds for the latch motor to finish moving.
• Do not pull on the door while the indicator light is flashing.

If the door is locked after self-clean

A self-clean cycle keeps the door locked until the oven cools. We recommend:

• Let the oven cool fully (the latch will not release while it is too hot).
• Press and hold Clear/Off for 3 seconds again.
• If the control is unresponsive, turn off the range at the breaker for 2 to 5 minutes, then restore power and retry the lockout cancel.

When a part is likely needed

If the control shows lock symptoms repeatedly (locks unexpectedly, will not unlock after cooling, or relocks right away), the door lock motor/switch assembly can be the cause. For this model, the matching part is the range oven door lock motor and switch assembly 5304528973.

What you see	What it usually means	What to do first
“Loc” shows when you press keys	Lockout feature is active	Hold Clear/Off 3 seconds
Door Locked light flashing	Latch motor is moving	Wait ~15 seconds; do not open door
Door stays locked after cooling	Latch system or control issue	Power reset, then inspect latch assembly

Why it matters

A motor-driven latch protects you during self-clean and lockout. Forcing the door can bend hinges, damage the latch, or crack door glass, so using the control reset sequence prevents avoidable repairs.

Last updated: February 2026

On the Frigidaire FFEF3018LBB electric range, an F90 code means the control detected a fault condition. We clear it by stopping the beeping, then doing a full power reset; if the code returns, the range needs diagnosis and repair per the service guidance in the FFEF3018LBB owner's manual.

Quick reset steps (most common fix)

• Press Clear/Off to stop the beeping and clear the display.
• Try Bake or Broil again.
• If F90 returns, turn power off at the breaker (or remove the fuse).
• Wait 5 minutes.
• Restore power, then set the clock.
• Try Bake or Broil again.

If F90 comes back after the reset

At that point, treat it as a recurring fault. Record the exact code and what you were doing (Bake, Broil, Self-clean, preheat) and have the range checked.

Common areas a technician checks include:

• Wiring connections between the control and oven components
• Oven temperature sensing circuit (sensor and harness)
• Electronic control issues

Parts that are often involved

What you notice	Common suspect	Example part for this model
Oven heats erratically or shuts off	Temperature sensing circuit	Range oven temperature sensor 316490000
Oven will not heat in Bake	Bake heating circuit	Frigidaire range bake element 316075103
Code appears during/after self-clean and door acts abnormal	Door lock circuit	Range oven door lock motor and switch assembly 5304528973

Why it matters

Continuing to run the oven with a repeating F90 can lead to unreliable temperatures, canceled cooking cycles, or a non-start condition. A proper reset confirms whether it was a one-time glitch or an active electrical/control problem.

Helpful reference

For code definitions and model families, we use the Frigidaire self-cleaning range error codes guide alongside the model-specific troubleshooting in the manual.

Last updated: February 2026

Frigidaire electric ranges (including model FFEF3018LBB) are made under the Frigidaire brand, which is part of the Electrolux family of appliance brands. That means Electrolux is the parent company behind Frigidaire-branded ranges sold in the U.S.

What this means for parts and service

When you’re ordering replacement parts or looking up operating details for your Frigidaire range, you’ll typically see Frigidaire and Electrolux referenced together. For model-specific details, we use the documentation and parts lists tied to your exact model.

• Use your model number (FFEF3018LBB) when searching parts diagrams and manuals.
• Record the model and serial number from the serial plate before ordering parts.
• Follow the safety and operating instructions in the FFEF3018LBB owner's manual.
• Use the FFEF3018LBB installation guide for electrical hookup and anti-tip bracket requirements.

Where to find your model and serial number

On many Frigidaire ranges, the serial plate is located in one of these places:

• Inside the storage drawer (some models)
• Behind the lower front panel (some models)
• On a label you can read after opening or removing the access area described above

What to record	Why it matters
Model number (FFEF3018LBB)	Ensures the part fits your exact range configuration
Serial number	Helps match production changes and correct revisions
Purchase date	Useful for warranty and service history

Why it matters

Frigidaire ranges can look similar across model families, but parts like the bake element, oven temperature sensor, or control board can vary by revision. Using the exact model number from the serial plate helps you get the right Frigidaire-compatible replacement the first time.

Last updated: February 2026
